Stiga Park 300 User manual

TOSAERBA CON CONDUCENTE A BORDO SEDUTO

SEKAČKA SE SEDÍCÍ OBSLUHOU

HAVETRAKTOR/HAVETRAKTOR MED FRONTKLIPPER (FM)

ΧΛΟΟΚΟΠΤΙΚΟ ΤΡΑΚΤΈΡ ΜΈ ΈΠΟΧΟΎΜΈΝΟ ΧΈΙΡΙΣΤΉ

RIDE-ON LAWNMOWER WITH SEATED OPERATOR

CORTADORA DE PASTO CON CONDUCTOR SENTADO

ISTUVA JUHIGA MURUNIITJA

PÄÄLTÄAJETTAVA RUOHONLEIKKURI

TONDEUSE À GAZON À CONDUCTEUR ASSIS

SJEDEĆA KOSILICA TRAVE S OPERATEROM

VEZETŐÜLÉSES FŰNYÍRÓGÉP

BALNINĖ VEJAPJOVĖ SU SĖDINČIU OPERATORIUMI

SĒŽOT VADĀMA ZĀLIENU PĻAUJMAŠĪNA

GRASMAAIER MET ZITTENDE BEDIENER

SITTEGRESSKLIPPER

KOSIARKA Z OPERATOREM JADĄCYM, W POZYCJI SIEDZĄCEJ NA MASZYNIE

CORTA-RELVAS PARA OPERADOR SENTADO

ЕЗДОВАЯ КОСИЛКА С СИДЕНЬЕМ

TRAKTORSKA KOSILNICA

ÅKGRÄSKLIPPARE OCH FRÄMRE KLIPPNING (FM)

MANUALE DI ISTRUZIONI.................................IT

INSTRUKTIONSMANUAL.................................CS

INSTRUKTIONSMANUAL.................................DA

GEBRAUCHSANWEISUNG .............................DE

INSTRUCTION MANUAL.................................. EN

USO Y MANTENIMIENT....................................ES

KASUTUSJUHEND.............................................. ET

KÄYTTÖOPAS ...........................................................FI

MANUEL D’UTILISATION.................................. FR

PRIRUČNIK ZA UPORABU .............................. HR

HASZNÁLATI UTASÍTÁS....................................HU

VARTOJIMO INSTRUKCIJA...............................LT

OPERATORA ROKASGRÅMATA.......................LV

GEBRUIKERSHANDLEIDINGNL....................NL

BRUKSANVISNING -VEDLIKEHOLD.........NO

INSTRUKCJE OBSŁUGI......................................PL

MANUAL DE USO ................................................ PT

РУKОВОДСТВО ПО ЭKСПЛУАТАЦИИ.....RU

PRIROČNIK Z NAVODILI ................................... SL

BRUKSANVISNING OCH UNDERHÅLL..... SV

Park series 2WD

Park 300M

Park 300

Type V 302

Type V 302 S

171501260/7 12/2021

A1 B

kW- /min

8 6 9 10 5 4

2 3 7

max xxx N (xxkg)

III

1/3

Full

B D D

[1] Type V302 V302 S

[2] Modello Park 300M Park 300

[3] Motore mod. STIGA ST400

(TRE0702)

STIGA ST450

(TRE0701)

[4] Cilindrata cm3414 432

[5] Trazione 2WD 2WD

[6] Potenza kW 7,1 8,1

[7] Giri motore rpm 3200 3200

[8] Impianto elettrico 12 V 12 V

[9] Batteria tipo VLRA VRLA

[10] Carburante [A] Benzina senza

piombo

[A] Benzina senza

piombo

[11] Capacità serbatoio carburante l 4,1 4,1

[12] Olio motore tipo SAE 10W-30 SAE 10W-30

[13] Olio motore, classe di servizio [A] SJ o superiore [A] SJ o superiore

[14] Capacità serbatoio olio motore l 1,2 1,2

[15] Candela [A] Champion RC92YC

o equivalente.

[A] Champion RC12YC

o equivalente.

[16] Candela, distanza elettrodi mm 0,75 0,75

[17] Pneumatici dim. 160 x 50-8 / 155 x 50-8 160 x 50-8 / 155 x 50-8

[18] Pressione pneumatici anteriore bar

(psi)

bar 1 - psi 15 bar 1 - psi 15

posteriore bar 1 - psi 15 bar 1 - psi 15

[19] Altezza di taglio mm 25 ÷ 85 25 ÷ 85

[20] Velocità di avanzamento (indicativa), in marcia avanti km/h 9 9

[21] Velocità di avanzamento (indicativa), in retromarcia km/h 7 7

[22] Massa kg 174 174

[23] Dimensioni di ingombro

[24] A = Lunghezza mm 1681 1681

[25] A1 = Lunghezza (con assieme dispositivi di taglio) mm 2252 2279

[26] B = Passo mm 800 800

[27] C = Altezza mm 1171 1171

[28] D = Larghezza mm 770 770

[29] D1 = Larghezza (con assieme dispositivi di taglio) mm 991 1023

[30] Livello di potenza sonora misurato dB(A) 99 99

[31] Incertezza dB(A) 0,75 0,66

[32] Livello di potenza sonora garantito dB(A) 100 99

[33] Livello di pressione sonora dB(A) 87 85

[34] Incertezza dB(A) 0,8 0,81

[35] Valore delle vibrazioni al posto di guida m/s² 0,6 0,6

[36] Incertezza m/s² 0,3 0,17

[37] Valore delle vibrazioni al volante m/s² 2,4 1,9

[38] Incertezza m/s² 0,85 0,34

ITALIANO

(Istruzioni Originali)

0 TABELLA DATI TECNICI

[39] ACCESSORI A RICHIESTA

[40] Descrizione Type

[41] Rimorchio 45-03453-997 / ST-1405

[42] Raccogli foglie e erba 45-03313-997

[43] Fertilizzatore 45-03153-997

[44] Assieme del dispositivo di taglio 85C QF

95C E QF

[45] Spazzatrice frontale SWR 1504

[46] Spalaneve a lama SNB 1505

[47] TABELLA PER LA CORRETTA COMBINAZIONE DEGLI ACCESSORI

[48] ACCESSORI POSTERIORI

Accessorio

[50]

[41] [42] [43]

[49] ACCESSORI FRIONTALI

[44]



[45]

- - 

[46]

- - 

IT ITALIANO (Istruzioni Originali)

0 TABELLA DATI TECNICI
