Stiga MULTICLIP 46 S SVAN User manual

July 4, 2005

Multiclip 46 S Svan Stiga

11-3603-19

MULTICLIP

MULTICLIP 46 S SVAN

A self-propelled lawnmower with the effective Multiclip system.

The Multiclip system cuts and fertilise at the same time and also

makes the lawnmover quieter. You don´t need to rakeor emptying

a collector. You cut the grass about 30 % faster as compared to

collecting.

The standard is very high regarding performance and environment

friendly features.

The lawnmower has rubber coated foldable handle. The cutting

deck is galvanized which gives a better protection against rust.

Cutting width is 46 cm.

The noise effect is very low, only 93 dB(A). A reduction of 3 dB(A)

means a halving of the noise output.

Equipped with an environmental-friendly 4,5 hp motor.

Conforms with the SVAN regulations and the Californian emission

levels.

Multiclip 46 S Svan (11-3603-19)

ENGINE

Brand Honda GCV 135 overhead valve camshaft

Power 4,5 hp, 3,4 kW - 4-stroke

Number of revolutions 2900 rpm

FUEL

Type of fuel Leadfree 95

WHEELS

Type of wheels Wheels with double ball bearings

Wheel size Front 190 mm. Rear 190 mm

Driving Self-propelled, front wheels. Speed 4,4 km/h

CUTTING SYSTEM

Type of cutting system Multiclip

Cutting heights 4 heights, 35-65 mm

Cutting width 46 cm

Cutting height adjustment Individual hight adjustment

VIBRATIONS & SOUND LEVELS

Sound power level 91 dB(A)

CONTROLS

Handlebar Robust fixation of the handle and comfortable soft control

levers

COLOUR & MATERIAL

Material of chassis Steel

MEASURES & WEIGHT

Weight 28 kg

Gross weight 31 kg

Package size WxHxL 775x530x505 mm

Units on pallet 8 pcs

OTHER FACTS

Owner's Manual 71503841/0

EAN bar code 731 332 110 200 5

Other features Carrying handle in front of the engine.

SVAN-approved
