StarTech.com PCI1394MP User manual
Manual Revision: 01/30/2012
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
PCI1394MP
4 port PCI 1394a FireWire Card
- 3 External 1 Internal
*actual product may vary from photos
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected
names and/or symbols of third-party companies not related in any way to StarTech.com.
Where they occur these references are for illustrative purposes only and do not represent an
endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to
which this manual applies by the third-party company in question. Regardless of any direct
acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges
that all trademarks, registered trademarks, service marks, and other protected names and/or
symbols contained in this manual and related documents are the property of their respective
holders.
Instruction Manual i
Table of Contents
Introduction........................................................................................................................................................1
System Requirements ............................................................................................................................1
Packaging Contents ................................................................................................................................1
Installation............................................................................................................................................................2
Hardware Installation..............................................................................................................................2
Driver Installation......................................................................................................................................2
Verifying Your Installation ....................................................................................................................2
Specications.....................................................................................................................................................3
Technical Support...........................................................................................................................................4
Warranty Information....................................................................................................................................4
Instruction Manual 1
Introduction
Thank you for purchasing a StarTech.com PCI FireWire card. This card allows you to instantly
connect your video camera, image scanner, digital still camera, or any other IEEE-1394 FireWire
device to your PC and is perfect for experienced users who are looking for a no-nonsense way to
add FireWire to their computers.
Features
• Compatible with most digital video camcorders including Sony, Canon, Panasonic, JVC,
Samsung, and others
• Supports hard disk drives, DVD drives, CD-R/RW drives, printers, and more
• Data transfer rates up to 400 Mbits/sec.
• Allows the connection of internal FireWire peripherals
System Requirements
• One available PCI slot
• Microsoft® Windows® 2000/ XP(32/64-bit)/ Server 2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-
bit), or Linux®, or Apple® Mac OS® 8.6 and up
Packaging Contents
• 1 x PCI FireWire card
• 1 x Low Prole Bracket
• 1 x Instruction Manual
Instruction Manual 2
Installation
WARNING! PCI cards, like all computer equipment, can be severely
damaged by static electricity. Be sure that you are properly grounded
before opening your computer case or touching your PCI card. StarTech.
com recommends that you wear an anti-static strap when installing any
computer component. If an anti-static strap is unavailable, discharge
yourself of any static electricity build-up by touching a large grounded
metal surface (such as the computer case) for several seconds. Also be
careful to handle the PCI card by its edges and not the gold connectors.
Hardware Installation
1. Make sure that your system is unplugged and you are grounded.
2. Remove the cover of your system (see your computer’s user manual for details, if necessary)
and gently turn your computer onto its side.
3. Locate an empty PCI slot (usually white in color) and remove the metal plate that covers the
rear bracket. You may need a Phillips screwdriver to perform this step.
Retain this screw! You will need it to secure the card later.
4. Gently insert the PCI card into the empty slot, making sure it is rmly seated.
5. Secure the card in place using the screw you removed in Step 3.
6. Put the computer case back on.
Driver Installation
Once you have connected your FireWire card, the next time you turn on your computer Windows
will automatically detect that you have installed new hardware. Follow the instructions below to
install the required software drivers.
Windows 2000
Windows 2000 will automatically locate and install the required drivers.
Windows XP
Windows XP will automatically locate and install the required drivers.
Verifying Your Installation
Windows 2000/XP
1. Go to Start > Settings > Control Panel.
2. Double click System.
3. Click the Hardware tab and choose Device Manager.
4. If the card does not appear with a red x or yellow exclamation point (!) next to it, Windows has
not detected a problem with the installation and the card should function normally.
Instruction Manual 3
Specications
Host Interface 32-bit PCI v2.1 (5V)
Form Factor Full/ Low Prole
Chipset Texas Instruments TI-TSB12LV26
Connectors 4 x 6-pin FireWire Female
(1 internal, 3 external)
Supported Standards IEEE-1394/ IEEE-1394A (FireWire 400)
Maximum Data Transfer Rate 400 Mbits/sec.
Compatible Operating Systems
Windows 2000/ XP(32/64-bit)/ Server
2003(32/64-bit)/ Vista(32/64-bit)/ 7(32/64-
bit), Linux, Mac OS 8.6 and up
Instruction Manual 4
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
Warranty Information
This product is backed by a lifetime warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for
the periods noted, following the initial date of purchase. During this period, the products may
be returned for repair, or replacement with equivalent products at our discretion. The warranty
covers parts and labor costs only. StarTech.com does not warrant its products from defects or
damages arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers,
directors, employees or agents) for any damages (whether direct or indirect, special, punitive,
incidental, consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss,
arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If
such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old and
new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need
to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to
the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and
to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
