SOLTEK SL-75DRV-X User manual
R
The Soul Of Computer Technology
SL-75DRV/75DRV-X
USER MANUAL v1.4
NOTICE
Product Model : SL-75DRV/75DRV-X
Manual Revision : V1.4
Release Date : Au ust 2001
• AMD Athlon ThunderbirdTM, and DuronTM processors are trademarks of AMD Corporation.
• VIA, KT- 33, VT8363 and VT82C686A are trademarks of VIA Corporation.
• Norton AntiVirus, Norton Ghost are trademarks of Symantec Corporation.
T
his Users Guide & Technical Reference is to help system manu-
facturers and end-users set up and install the mainboard.
Every effort has been made to ensure that the information in this
manual is accurate. Soltek Computer Inc. is not responsible for print-
ing or clerical errors. Information in this document is subject to
change without notice and does not represent a commitment on the
part of Soltek Computer Inc.
No part of this manual may be reproduced, transmitted, translated
into any language in any form or by any means, electronic or
mechanical, including photocopying and recording, for any purpose
without the express written permission of Soltek Computer Inc.
Companies and products mentioned in this manual are for identifi-
cation purpose only. Product names appearing in this manual may
or may not be registered trademarks or copyrights of their respec-
tive companies.
Soltek Computer Inc. provides this manual “As is “ without warranty
of any kind, either express or implied, including but not limited to the
implied warranties or conditions of merchantability or fitness for a
particular purpose. In no event shall Soltek Computer Inc. be liable
for any loss or profits, loss of business, loss of use or data, interruption of
business, or for indirect, special, incidental, or consequential damages of
any kind, even if Soltek Computer Inc. has been advised of the possibility
of such damages arising from any defect or error in this manual or product.
Copyright © 2001 Soltek Computer Inc. All Rights Reser ed.
SOLTEK AROUND THE WORLD
SOLTEK COMPUTER INC.
Address : 7F, No. 306 3, Ta Tung Rd, Sec.1, Hsi Chih, Taipei
Hsien, Taiwan, R.O.C.
Telephone : 886 2 2642 9060
Fax : 886 2 2642 9065
Web site : http://www.soltek.com.tw
SOUL TECHNOLOGY EUROPE B.V.
Address : Hongkongstraat 55, 3047 BP Rotterdam. The Neth
erlands
Telephone : 31 10 2457492
Fax : 31 10 2457493
E mail : sales@soultech europe.com
Web site : http://www.soultech europe.com
75DRV/75DRV-X
4
CONTENT
CHAPTER 1 INTRODUCTION ................................................. 9
1 1 MAINBOARD SPECIFICATION ............................................... 10
1 1.1 PROCESSOR ................................................................................. 10
1 1.2 CHIPSET......................................................................................... 10
1 1.3 AWARD BIOS V6.0 SUPPORTING................................................. 10
1 1.4 SOUND CONTROLLER.................................................................. 10
1 1.5 POWER MANAGEMENT ................................................................ 10
1 1.6 FULL FEATURED ACCELERATED GRAPHICS PORTS (AGP)
CONTROLLER ................................................................................ 11
1 1.7 MULTI I/O FUNCTION .................................................................... 11
1 1.8 EXPANSION SLOTS ....................................................................... 11
1 1.9 ADVANCED HIGH PERFORMANCE SDR/DDR DRAM
CONTROLLER ............................................................................... 11
1 1.10 FORM FACTOR ............................................................................ 12
1 1.11 HARDWARE MONITOR ................................................................ 12
1 1.12 OTHERS ....................................................................................... 12
1 2 MAINBOARD LAYOUT ............................................................ 13
1 2.1 Mainboard Layout 75DRV .......................................................... 13
1 2.2 Mainboard Layout 75DRV X ....................................................... 14
1 3 CHIPSET DIAGRAM 75DRV/75DRV X ............................... 15
CHAPTER 2 HARDWARE SETUP......................................... 17
2 1 CPU INSTALLATION ............................................................... 18
2 2 MEMORY INSTALLATION ....................................................... 19
2 3 ACCELERATED GRAPHICS PORT(AGP) PRO INSTALLATION ... 21
5
2 4 HDD/FDD INSTALLATION....................................................... 22
2 5 SWITCH SETTING FOR CPU FREQUENCY AND VOLTAGE 24
2 5.1 Information On AMD Socket 462 Processor (Model4, 5 Products) . 24
2 5.2 Information On AMD Socket 462 Processor (Model6, 7 Products) . 25
2 5.3 Frequency Ratio Select (By SW1 DIP1 DIP5) ................................ 26
2 5.4 Processor Core Voltage Select (By SW2 DIP1 DIP6)..................... 27
2 5.5 CPU External Frequency Setting (By SW3) .................................... 28
2 6 JUMPER SETTING FOR DEVICES ON BOARD .................... 29
2 6.1 JP1/JP2 Memory Module Voltage Select ........................................ 29
2 6.2 JP17 Power Lost Resume............................................................... 30
2 6.3 JP18/19 AGP Voltage Select ........................................................... 30
2 6.4 JBAT1 For Clear CMOS Data ......................................................... 31
2 7 CONNECTORS CONFIGURATIONS ...................................... 32
2 7.1 On Board FAN Connector (FAN1, FAN2, FAN3, FAN4) .................. 32
2 7.2 WOL1 Wake On LAN ...................................................................... 33
2 7.3 CD ROM Audio Connector (JCD_IN1) ............................................ 33
2 7.4 Thermal Sensor Connector (RT2) ................................................... 34
2 7.5 Complex Header CON1 .................................................................. 35
2 7.6 ATX Power Supply Connector ......................................................... 36
2 7.7 Chassis Panel Connector............................................................... 37
2 7.8 Smart Card Reader Connector (SCR1) .......................................... 38
2 7.9 Communication And Networking Riser Slot (CNR) ......................... 39
2 7.10 USB Header (USB2/USB3 Header) .............................................. 40
2 7.11 PS/2 Mouse And PS/2 Keyboard .................................................. 40
2 8 VOICE DIAGNOSTIC FUNCTION FOR 75DRV X ONLY....... 41
2 8.1 JP10 VD Tech II Language Select .................................................. 42
75DRV/75DRV-X
6
CHAPTER 3 SOFTWARE SETUP ......................................... 44
3 1 VIA CHIPSET DRIVER INSTALLATION (4 IN 1 DRIVER) ...... 45
3 2 HARDWARE MONITOR INSTALLATION ................................ 48
3 3 AC’97 AUDIO CODEC DRIVER INSTALLATION .................... 50
CHAPTER 4 BIOS SETUP ..................................................... 52
4 1 WHAT IS BIOS SETUP ............................................................ 53
4 2 HOW TO RUN BIOS SETUP ................................................... 53
4 3 WHAT IS CMOS ...................................................................... 53
4 4 WHAT IS POST ....................................................................... 53
4 5 BIOS UPGRADE ..................................................................... 53
4 5.1 BEFORE UPGRADING BIOS ......................................................... 54
4 5.2 UPGRADE PROCESS .................................................................... 54
4 6 BIOS SETUP CMOS SETUP UTILITY................................ 58
4 6.1 CMOS SETUP UTILITY .................................................................. 58
4 6.2 STANDARD CMOS SETUP ............................................................ 59
4 6.3 ADVANCED BIOS FEATURES ....................................................... 62
4 6.4 ADVANCED CHIPSET FEATURES ................................................ 66
4 6.5 INTEGRATED PERIPHERALS ....................................................... 71
4 6.6 POWER MANAGEMENT SETUP ................................................... 77
4 6.7 PNP / PCI CONFIGURATION ......................................................... 83
4 6.8 SMARTDOC ANTI BURN SHIELD ................................................. 86
4 6.9 FREQUENCY/VOLTAGE CONTROL.............................................. 88
4 6.10 LOAD OPTIMIZED DEFAULTS..................................................... 91
4 6.11 SET SUPERVISOR / USER PASSWORD .................................... 91
4 6.12 SAVE & EXIT SETUP.................................................................... 92
4 6.13 EXIT WITHOUT SAVING .............................................................. 92
7
APPENDICES ......................................................................... 94
APPENDIX 1 TECHNICAL TERMS .............................................. 95
APPENDIX 2 IDENTIFYING BIOS VERSION AND BIOS ............ 96
PART NUMBER ..................................................... 96
APPENDIX 3 IDENTIFYING MAINBOARD MODEL NUMBER .... 98
75DRV/75DRV-X
8
Mainboard
====Support CD
====User’s Manual
====Bundled Bonus Pack CD
====Bundled Bonus Pack Manual
====Temperature Sensor Cable
====ATA66/100 IDE Cable
====RS232 Cable
FDD Cable
ITEM LIST CHECKUP
Chapter 1 Introduction
9
CHAPTER 1
INTRODUCTION
This chap er con ains he following opics :
1-1 MAINBOARD SPECIFICATION
1-2 MAINBOARD LAYOUT
1-3 CHIPSET DIAGRAM
• This chapter briefly introduces the characteristics of the mainboards. It includes
the information regarding the chipset, CPU types, built in functions and layout.
Users will have more ideas about mainboards after reading this chapter.
75DRV/75DRV-X
10
1-1 MAINBOARD SPECIFICATION
1-1.1 PROCESSOR
• Supporting AMD Athlon Thunderbird processor up to 1.5GHz or above.
• Supporting AMD Athlon Duron processor up to 1.2GHz or above.
• Supporting 200MHz & 266MHz FSB bus.
• Supporting Processor VID(voltage ID) and FID(Frequency ID) auto
detection.
• Supporting Atholon 4 Processors.
1-1.2 CHIPSET
• North Bridge VIA VT8366 KT 266 AMD ATHLONTM NORTH BRIDGE.
• South Bridge VIA VT8233 VLINK CLIENT HIGHLY INTEGRATED SOUTH
BRIDGE.
• LPC I/O ITE 8705.
1-1.3 AWARD BIOS V6.0 SUPPORTING
• Plug & Play V1.0.
• Flash Memory for easy upgrade.
• Year 2000 compliant.
• BIOS writing protection.
• SmartDOC Anti Burn shield.
1-1.4 SOUND CONTROLLER
• SoundBlaster Pro Hardware and Direct Sound Ready AC97 Digital Audio
Controller with Codec onboard.
1-1.5 POWER MANAGEMENT
• ACPI 1.0 compliant (Advanced Configuration and Power Interface).
• APM V1.2 compliant (legacy power management).
• Supporting ACPI suspend STR mode (Suspend To DRAM) and POS mode
(Power On Suspend).
• System event monitoring with two event classes.
• Supporting PS/2 Keyboard & Mouse power on.
• Supporting Wake On LAN (WOL) & Wake On Modem.
• Supporting real time clock (RTC) with date alarm, month alarm, and century
field.
• USB boot up Function.
This manual suits for next models
1
