Snapper 7800190 User manual

Parts Manual fo

22" VARIABLE SPEED HIGH WHEEL

WALK BEHIND MOWERS

Revision: G 7/27/2010

Briggs & Stratton Yard Power Products Group

Manual No. 7102345

535 Macon Road

McDonough, GA, 30253 U.S.A.

800-935-2967

Descri

tionModel No.

780023

NSPV22675HW

780042

NSPV22675HW

780019

SPV22675HW

780058

SPV2270HW

Not for

Reproduction

Not for

Reproduction

Table Of Contents

TP 400-5323-G-WB-N

22" VARIABLE SPEED HIGH WHEEL

Manual No. 7102345

PAGE GROUP

4 Handles & Controls

6 Deck Assembly

8 Engine & Blade Assembly

10 Decals

Not for

Reproduction

Handles & Controls

Manual No. 7102345 22" VARIABLE SPEED HIGH WHEEL

Not for

Reproduction

Handles & Controls

Footnotes:

Manual No. 710234522" VARIABLE SPEED HIGH WHEEL

Part No Descri

tionItem Qty

1 7101312 1 HANDLE, Plastic Upper, WBM

2 7101321BH 1 BAIL, Plastic Handle, WBM

3 7090015 2 BOLT, 1/4-20 x 1-3/4 Round Head Square Neck, GR 2

4 2860694 3 NUT, 1/4-20, Hex Flange Nyloc, YZ

5 7101415 1 ASSEMBLY, Control Head, 22 WBM, VS, HW (incl. cable & lever)

6 7300670A 1 PLATE, Control Panel- Plastic Handle

7 7100225 4 SCREW, #8-16 Torxplus Recessed Pan Head, Twin Helix

8 7300649BH 2 HANDLE, Connecting 21/22 WBM

9 7101410 1 ROPE GUIDE (1/4-20 thread)

10 7035744 2 KNOB, 5/16-18 Wing (Black)

11 7090391 2 WASHER, 5/16” Internal Tooth Lock

12 7091189 2 BOLT, 5/16-18 x 2 Curved Head Square Neck, GR 2

13 7024649 3 WIRE TIE,11 Inch Standard Black Nylon

14 7101395 1 CABLE, Bail, 22 WBM (43.10” cable length)

15 7300667BH 1 HANDLE, Lower, 22 WBM, Hi-Wheel

16 7101198 2 PIN, Handle Adjust

17 7101200 2 SPRING, Compression

18 7101199 2 BUSHING, Handle Pin

19 7101202 2 KNOB, Quick Release

20 7090958 2 BOLT, 5/16-18 x 1-1/2” Round Head Short Square Neck, GR 5

21 7090951 2 NUT, 5/16-18 Large Head Center Lock, Black

22 7101246 1 GRASS BAG, 22” Rear Discharge

23 7101230A 1 BAG FRAME, 22” WBM (Weldment)

24 7026421 1 GRIP, Rectangular (Black)

Not for

Reproduction

Deck Assembly

Manual No. 7102345 22" VARIABLE SPEED HIGH WHEEL

Not for

Reproduction

Deck Assembly

Footnotes:

Manual No. 710234522" VARIABLE SPEED HIGH WHEEL

Part No Descri

tionItem Qty

1 7300400D 1 DECK, 22 Walk, 3-N-1

2 7900054 4 SCREW, 3/8-16 x 3/4” Hex Head Cap, GR 5, YZ

3 7091619 6 NUT, 3/8-16 Hex Flange Lock, YZ

4 7300854D 1 BAFFLE, Rear, 22 Deck

5 7101243 1 DOOR, 22” Rear

6 7091286 4 SCREW, #10-24 x 1/2 Hex Washer Self-Tap, SEMS

7 7102422 1 GUARD, Rear

8 7300583BH 1 BRACKET, Lower Handle, LH, 22” WBM, HW

9 7300582BH 1 BRACKET, Lower Handle, RH, 22” WBM, HW

10 7100633 4 GRIP, Height Latch

11 7101461 1 SPRING, Torsion, Rear Door, 22” WBM

12 7101070 1 ROD, Pivot, Rear Door (1/4” Dia. X 17-1/2”)

13 7501055 1 ASSEMBLY, Height-Of-Cut, Left Rear, 22” WBM

14 7501056 1 ASSEMBLY, Height-Of-Cut, Right Rear, 22” WBM

15 7501058 1 ASSEMBLY, Height-Of-Cut, Left Front, 22” WBM, Propelled

16 7501057 1 ASSEMBLY, Height-Of-Cut, Right Front, 22” WBM, Propelled

17 7091601 2 NUT, 5/16-18 Flange Lock, YZ

18 7091811 2 BOLT, 5/16-18 x 5/8” Hex Flange Lock, YZ

19 7091020 4 PUSHNUT, 1/4”

20 7500546 2 * ASSEMBLY, Wheel, 12 x 2 Idle, BB, Snapper Cool Gray

21 722604 4 WASHER, 1” O.D. x .387 I. D. Flat

22 7091585 4 NUT, 3/8-16 Hex Center Lock, YZ

23 7101393 2 HUBCAP, 12 Wheel, Snapper Cool Gray

24 7300856D 1 PLATE, Mulch, 22” RB Scott's

25 7300855D 1 BRACKET, Chute

26 722848 3 SCREW, 1/4-20 x 11/16 Pan Head Torx, Self-Tap

27 721682 1 COVER, Mulch, Plastic, Black

28 7101067 1 ROD, Pivot (1/4” Dia. x 5.55”)

29 722507 1 SPRING, Torsion, Chute

30 721681 1 SIDE CHUTE, Plastic, Black

31 7101402 2 DUST SHIELD, 22” WBM, Front Wheel Drive

32 7101207 2 GEAR, Pinion, 22” WBM, Front Wheel Drive

33 7014341 4 RING, External Retaining (Waldes 5133-50)

34 7500542 2 * ASSEMBLY, Drive Wheel, 8 x 2, BB, Snapper Charcoal Gray

35 7101350 2 HUBCAP, 8 & 9 Wheel Spoked - Snapper Cool Gray

36 7100857 1 TRANSMISSION, Rocker, 22 WBM HW, VS

37 7101270 2 DRIVE PIN, 22” WBM, Front Wheel Drive

38 7300440D 1 BAFFLE, Front, 22 WBM

Note: * Includes two 1-1/8 O. D. Flanged Ball Bearings (p/n 7101380).

Not for

Reproduction

Engine & Blade Assembly

Manual No. 7102345 22" VARIABLE SPEED HIGH WHEEL

Not for

Reproduction

Engine & Blade Assembly

Footnotes:

Manual No. 710234522" VARIABLE SPEED HIGH WHEEL

Part No Descri

tionItem Qty

1 7101449 1 ASSEMBLY, Engine Spacer, 22” WBM, Self-Propelled (includes 7101209 (spacer) & 7101448

(3) (bushings))

2 7100913 1 BELT, Traction Drive, 22 Pivot Handle (3L Section; 31.94 effective length)

3 7101195 1 FRONT COVER, Deck, 22” Front Wheel Drive

4 7900018 2 SCREW, 4.8 x 1.59 x 13mm, Round Washer Head Hi-Lo (Torx)

5 720351 1 BOLT, 3/8-16 NS x 2-1/2” Hex Head

6 7101451 2 SCREW, 3/8-16 x 3” Hex Washer Self-Tap

7 7101302 2 SPACER, BELT GUIDE, 22” VS

8 7101024 2 BELT GUIDE, Engine, 22” VS

9 7101009 1 BELT GUIDE, Transmission, 22 WBM

10 7091195 2 SCREW, #10-16 x 3/4 Pan Head Self-Tap, Combo

11 7091214 1 KEY, #HP-506 Hi-Pro

12 7100437 1 PULLEY, Engine

13 7092086 1 SET SCREW 5/16-18 x 1/2 Hex Recess

14 7100740 1 BLADE HUB, 22” Deck, Self Propelled

15 7100851 1 BLADE, 22”, Walk Mower

16 721890 1 WASHER, .38” I.D. x 1.183 O.D. Bellville

17 720209 1 BOLT, 3/8-24 x 3-1/4” Hex Head, GR 8

18 7900032 8 SCREW, 7mm x 1 x .550 AB Point

19 126T02-0675-B3 1 * ENGINE, B&S, 675 Ser, X-Spec, B3 (used on 7800190 model)

19 126L02-0675-F3 1 * ENGINE, B&S, 675 Ser, X-Spec, F3 (used on 7800230 model)

19 126L02-4675-F3 1 * ENGINE, B&S, 675 Ser, X-Spec, F3 (used on 7800420 model)

19 128T02-0740-B3 1 * ENGINE, B&S, 700 Ser, X-Spec, B3 (used on 7800585 model)

NOTE: * Purchase engine parts from engine manufacturer dealer.

Not for

Reproduction

Decals

Manual No. 7102345 22" VARIABLE SPEED HIGH WHEEL

Not for

Reproduction
