Parts Manual

Rev. 11/2008

Conquest / 1700 / 2700

Series Garden Tractors & Mower Decks RMO

. No. Descri

tion

23HP Product

1695152 Conquest, 23HP B&S Hydro w/PS RMO

1695153 Conquest, 23HP Kohler Hydro RMO

1695154 1723H, 23HP B&S Hydro w/PS RMO

1695155 2723H, 23HP B&S Hydro w/PS RMO

1695226 Conquest, 23HP B&S Hydro (CE/Export)

2690598 Conquest, 23HP Hydro RMO and 44" Mower Deck

2690600 Conquest, 23HP Hydro w/PS RMO and 50" Mower Deck

2690603 1723H, 23HP Hydro w/PS RMO and 50" Mower Deck

2690605 2723H, 23HP Hydro w/PS RMO and 50" Mower Deck

2690656 Conquest, 23HP B&S Hydro and 44" Mower Deck

(CE/Export)

. No. Descri

tion

Mower Decks

1694038 44" Mower Deck

1695028 44" Mower Deck (CE/Export)

1695183 50" Mower Deck

1695184 50" Mower Deck

TP 400-4593-A-CQ-SMA

1734979

Part No.:

Not for

Reproduction

Not for

Reproduction

Table Of Content

Torque Specification Chart ..................................................................... Inside Back Cover

PRODUCT COMPONENTS PAGES

Frame Group - Manual Steering .......................................................................................................................... 4

Frame Group - Power Steering ............................................................................................................................ 8

Power Steering & Hydraulic Lift Group ................................................................................................................ 12

Steering Group - Manual Steering ....................................................................................................................... 14

Steering Group - Tilt Steering .............................................................................................................................. 16

Engine Group - 20HP, 22HP & 23HP Briggs & Stratton, Vanguard Twin ........................................................... 18

Engine Group - 23HP Kohler, Courage Twin ...................................................................................................... 20

Transmission Group ............................................................................................................................................. 22

Controls Group ..................................................................................................................................................... 26

Cruise Control Group ........................................................................................................................................... 28

Electrical Group .................................................................................................................................................... 30

Hood, Grille & Dash Group .................................................................................................................................. 34

Seat & Seat Deck Group ...................................................................................................................................... 36

Lift Group - Manual Lift ......................................................................................................................................... 38

Wheels & Tires Group .......................................................................................................................................... 40

Decals Group - Brand & Model ............................................................................................................................ 42

Decals Group - Safety & Common ...................................................................................................................... 44

44" & 50" Mower Deck - Clutch & Support Group ............................................................................................... 46

44" Mower Deck - Belt, Idler Arm & Hitch ............................................................................................................ 48

44" Mower Deck - Height Adjustment & Roller Bar ............................................................................................. 50

44" Mower Deck - Housing, Arbors & Blades ...................................................................................................... 54

50" Mower Deck - Height Adjustment & Roller Bar ............................................................................................. 58

50" Mower Deck - Housing, Arbors & Blades Group ........................................................................................... 62

Not for

Reproduction

Frame Group - Manual Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986747

The above parts group applies to the following Mfg. Nos.:

2008 4

1695153 - Conquest

1695226 - Conquest

2690598 - Conquest

2690656 - Conquest

TP 400-4593-A-CQ-SMA

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame Group - Manual Steering

Footnotes

TOWER & SUPPORT ASSEMBLY1 1733139ASM 1

CAPSCREW, Hex Washer Head Taptite, 3/8-16 x 3/42 1923683SM 4

CAPSCREW, Hex Washer Head Taptite, 5/16-18 x 3/43 1960541SM 4

SUPPORT, Seat Deck4 1723528ASM 1

NUT, Hex Flange 3/8-16 Whiz Lock, Large5 1928352SM 2

NUT, Hex Flange Two-Way Lock, 1/2-136 1930644SM 2

BACKPLATE7 1722602ASM 1

CAPSCREW, Hex Head 1/2-13 x 1, Black8 1923114SM 2

CAPSCREW, Hex Head 3/8-16 x 1, Black9 1921210SM 2

FRAME ASSEMBLY, Front & Rear10 1726989ASM 1

NUT, Hex Flange Two-Way Lock, 3/8-1611 1930645SM 7

WASHER, 3/8, Black12 1922755SM 1

WASHER, 3/8, Black13 1960103SM 2

LINK, Drag14 1722541SM 1

NUT, Hex Jam 1/2-2015 1919262SM 1

JOINT, Ball16 1702779SM 1

SPACER, 3/8 x 1/2 x 5/817 1708236SM 1

CARRIAGE BOLT, 3/8-16 x 118 1931350SM 2

ROD, Tie19 1722626ASM 1

AXLE ASSEMBLY w/LH Spindle (Includes Ref. Nos. 22, 24, 41, 42 & 43)20 1722200ASM 1

SPACER, 25/64 x 5/8 x 5/16, Powder Metal21 1611705SM 2

BUSHING, 31/32 x 1-1/4 x 3/4, Powder Metal22 1721682SM 6

NUT, Hex Flange Two-Way Lock, 7/16-1423 1930650SM 2

FITTING, Lube24 2821133SM 3

SPINDLE REPLACEMENT KIT, LH (Includes Ref. Nos. 22, 26, 27, 28, 29 & 30)25 1686985SM 1

CAPSCREW, 3/8-16 x 7/8, GR826 2823485SM 1

WASHER, Spring, 3/827 1663151SM 1

HUB & ARM ASSEMBLY28 1725112SM 1

KEY, Woodruff29 2830671SM 1

SPINDLE, LH30 1724264SM 1

CARRIAGE BOLT, 3/8-16 x 1-1/231 1931352SM 1

SPACER, 11/16 x 21/32 x 2 3/3232 1721752SM 1

CAPSCREW, Hex Head, 7/16-14 x 2 G833 1927531SM 2

HOOK, "J"34 1721918ASM 1

BUMPER, Black35 1721805ASM 1

BUMPER, Chrome35 1723502SM 1

SCREW, Truss Head Torque Drive, 5/16-18 x 7/836 1960086SM 4

CAPSCREW, Hex Whiz Lock, 5/16-18 x 3/437 1930591SM 2

PLATE, Axle Wear38 1724801ASM 1

NUT, Hex Flange Whix Lick, 5/16-1839 1931277SM 2

SPINDLE, RH40 1722199SM 1

WASHER41 1919394SM 1

RETAINING RING42 2832577SM 1

The above parts group applies to the following Mfg. Nos.:

2008 5

1695153 - Conquest

1695226 - Conquest

2690598 - Conquest

2690656 - Conquest

TP 400-4593-A-CQ-SMA

Not for

Reproduction

Frame Group - Manual Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

986747

The above parts group applies to the following Mfg. Nos.:

2008 6

1695153 - Conquest

1695226 - Conquest

2690598 - Conquest

2690656 - Conquest

TP 400-4593-A-CQ-SMA

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame Group - Manual Steering

Footnotes

CAPSCREW, Hex Flange Whiz Lock, 3/8-16 x 3/443 1933260SM 4

FITTING, Grease for Wear Plate44 2821133SM 2

WASHER, 5/845 1960035SM 2

CAPSCREW, Hex Head, 5/8-11 x 3-1/246 2860645SM 1

NUT, Hex Flange Two-Way Lock, 5/8-1147 2860646SM 1

PLATE, Axle48 1722212ASM 1

The above parts group applies to the following Mfg. Nos.:

2008 7

1695153 - Conquest

1695226 - Conquest

2690598 - Conquest

2690656 - Conquest

TP 400-4593-A-CQ-SMA

Not for

Reproduction

Frame Group - Power Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

987426

The above parts group applies to the following Mfg. Nos.:

2008 8

1695152 - Conquest

1695154 - 1723H

1695155 - 2723H

2690600 - Conquest

2690603 - 1723H

2690605 - 2723H

TP 400-4593-A-CQ-SMA

Not for

Reproduction

PART NO. DESCRIPTIONREF NO QTY.

Frame Group - Power Steering

Footnotes

FRAME ASSEMBLY, Front & Rear1 1733765ASM 1

TOWER & SUPPORT ASSEMBLY2 1733139ASM 1

SUPPORT, Seat Deck3 1723528ASM 1

BACKPLATE, Hitch4 1722602ASM 1

PLATE, Axle Support5 1722212ASM 1

BUMPER6 1721805ASM 1

AXLE, SPINDLES & BUSHINGS ASSEMBLY (Includes Ref. Nos. 19, 21, 44, 45, 46, 47,

48, 49 & 50)

7 1732937ASM 1

HOOK, "J"8 1721918ASM 1

ROD, Tie, Flat Ends9 1732759ASM 1

SUPPORT, Steering Unit10 1733044ASM 1

SPACER, Powdered Metal11 1721752SM 1

SPACER12 1611705SM 2

JOINT, Ball, 1/2-20 Thread13 1702779SM 1

SPACER14 1719725SM 1

NUT, Hex Jam, 1/2-2015 1919262SM 1

NUT, Hex Flange, 3/8-16 Two-Way Lock16 1930645SM 4

CYLINDER, Hydraulic Steering17 1732439SM 1

CARRIAGE BOLT, 3/8-16 x 1 G518 1931350SM 2

FITTING, Lube 1/4 Drive19 1704314SM 3

NUT, Hex Flange 7/16-14 Two Way Lock20 1930650SM 2

SPACER, Powdered Metal21 1732208SM 1

CAPSCREW, Hex Head 7/16-14 x 2 G822 1927531SM 2

CAPSCREW, Hex Head 5/8-11 x 3-1/2 G523 2860645SM 1

WASHER, 5/824 1960035SM 2

SCREW, Hex Whiz Lock Flange 3/8-16 x 3/425 1933260SM 4

SCREW, Hex Washer Head Taptite 5/16-18 x 3/426 1664847SM 4

NUT, Hex Flange 5/8-11 Two Way Lock27 2860646SM 1

SCREW, Hex Washer Head Taptite 3/8-16 x 3/428 1923683SM 4

NUT, Hex Flange 1/2-13 Whiz Lock29 2860668SM 2

NUT, Hex Flange 3/8-16 Whiz Lock Large30 1928352SM 2

CAPSCREW, Hex Head 1/2-13 x 1 G531 1923114SM 2

CAPSCREW, Hex Head 3/8-16 x 1 G532 1921210SM 2

SCREW, Truss Head Torx Drive 5/16-18 x 7/833 1960086SM 4

PLATE, Axle "U" Form34 1724801ASM 1

SCREW, Hex Whiz Lock Flange 5/16-18 x 3/435 1930591SM 2

NUT, Hex Flange 5/16-18 Whiz Lock36 1931277SM 2

FITTING, Lube 1/4 Drive37 2821133SM 2

SCREW, Hex Washer Head Taptite 5/16-18 x 1/238 1924856SM 4

SPACER39 1733912ASM 1

WASHER, 5/840 1924366SM 2

CAPSCREW, Hex Head41 1960713SM 1

NUT, Hex Toplock42 1960714SM 1

NUT, Hex Flange, Machine Lock 3/8-1643 1960339SM 2

The above parts group applies to the following Mfg. Nos.:

2008 9

1695152 - Conquest

1695154 - 1723H

1695155 - 2723H

2690600 - Conquest

2690603 - 1723H

2690605 - 2723H

TP 400-4593-A-CQ-SMA

Not for

Reproduction

Frame Group - Power Steering

NOTE: Unless noted otherwise,

use the standard hardware torque

specification chart.

987426

The above parts group applies to the following Mfg. Nos.:

2008 10

1695152 - Conquest

1695154 - 1723H

1695155 - 2723H

2690600 - Conquest

2690603 - 1723H

2690605 - 2723H

TP 400-4593-A-CQ-SMA

Not for

Reproduction
