Multimo 513 User manual
Assembly Instructions
+-
100 min.
210 min.
Technical Service
End User
A 513-ROYAL KING WALL BED
Page 1 Page 2
TAP - 02
4 / piece
MNG - 01
34 / piece
CT - 01 ( 6x40 ) mm
2 / piece
IM - 01 (6x30) mm
4 / piece
DSE - 01 (40x90x32) mm
3 / piece
DD - 01 ( R10 )
3 / piece
PL - 02 (8x22x1) mm
3 / piece
VDA - 01 ( 6,5x50 ) mm
4 / piece
VTB - 01 (4,8x16) mm
12 / piece
KP - 01 ( 224 ) mm
2 / piece
VKP - 01 (22) mm
4 / piece
Accessories List
MNX 02
24 / piece
KVL 01
28 / piece
OT-054
2 / piece
VD - 02 (3,5x25) mm
40 / piece
SG - 01
2 / piece
TAP - 01
34 / piece
AVT - 01
6 / piece2 / piece
OT-056D
TFC - 01(8x70) mm
3 / piece
SC - 92
2 / piece
Piece T h ic k ne s s L e n g th Wid th Piece T hic k H e ig ht M o s t
A-R / A-L 21,18 89, 76 17,32 2 30 2280 440
B10,71 78, 35 16,54 1 18 1990 420
C11,18 78, 35 16,50 1 30 1990 419
D10,71 78, 35 11,81 1 18 1990 300
E40,31 89, 25 19,69 4 8 2267 500
F10,71 78, 35 5,67 1 18 1990 144
G20,71 81, 89 38,66 2 18 2080 982
H11,18 77, 48 4,33 1 30 1968 110
K (OPTIONAL HEADBOARD) 21,97 37, 87 78,15 2 50 962 1985
Track Title
(inch)
(m m )
CT - 02 ( 6x30 ) mm
2 / piece
H
A-R
A-L
B
C
D
F
G
K
K
E
VTB - 02 (4,2x16) mm
80 / piece
H 01
2 / piece
1 / piece
KMT-01
E
E
G
MKZ - 05/02
1 / piece
RL
5 / piece
MNX - 03
LTA - 01
26 / piece
1 / piece
PRF
KOR
1 / piece
YSB - 01 ( 3,9x16 ) mm
2 / piece
CTM - 02 ( 8x35 ) mm
2 / piece
CTA - 01 ( 8x15 ) mm
12 / piece
PL - 05 (8x16x2) mm
14 / piece
CTM - 05 ( 8x45 ) mm
2 / piece 2 / piece
OT-056PE
P
M
N
S
R
AL - 01 (4MM)
1 / piece
AL - 01 (4MM)
1 / piece
E
OPTIONAL
HEADBOARD
OPTIONAL
HEADBOARD
Page 1 Page 2
TAP - 02
4 / piece
MNG - 01
34 / piece
CT - 01 ( 6x40 ) mm
2 / piece
IM - 01 (6x30) mm
4 / piece
DSE - 01 (40x90x32) mm
3 / piece
DD - 01 ( R10 )
3 / piece
PL - 02 (8x22x1) mm
3 / piece
VDA - 01 ( 6,5x50 ) mm
4 / piece
VTB - 01 (4,8x16) mm
12 / piece
KP - 01 ( 224 ) mm
2 / piece
VKP - 01 (22) mm
4 / piece
Accessories List
MNX 02
24 / piece
KVL 01
28 / piece
OT-054
2 / piece
VD - 02 (3,5x25) mm
40 / piece
SG - 01
2 / piece
TAP - 01
34 / piece
AVT - 01
6 / piece2 / piece
OT-056D
TFC - 01(8x70) mm
3 / piece
SC - 92
2 / piece
Piece T h ic k ne s s L e n g th Wid th Piece T hic k H e ig ht M o s t
A-R / A-L 21,18 89, 76 17,32 2 30 2280 440
B10,71 78, 35 16,54 1 18 1990 420
C11,18 78, 35 16,50 1 30 1990 419
D10,71 78, 35 11,81 1 18 1990 300
E40,31 89, 25 19,69 4 8 2267 500
F10,71 78, 35 5,67 1 18 1990 144
G20,71 81, 89 38,66 2 18 2080 982
H11,18 77, 48 4,33 1 30 1968 110
K (OPTIONAL HEADBOARD) 21,97 37, 87 78,15 2 50 962 1985
Track Title
(inch)
(m m )
CT - 02 ( 6x30 ) mm
2 / piece
H
A-R
A-L
B
C
D
F
G
K
K
E
VTB - 02 (4,2x16) mm
80 / piece
H 01
2 / piece
1 / piece
KMT-01
E
E
G
MKZ - 05/02
1 / piece
RL
5 / piece
MNX - 03
LTA - 01
26 / piece
1 / piece
PRF
KOR
1 / piece
YSB - 01 ( 3,9x16 ) mm
2 / piece
CTM - 02 ( 8x35 ) mm
2 / piece
CTA - 01 ( 8x15 ) mm
12 / piece
PL - 05 (8x16x2) mm
14 / piece
CTM - 05 ( 8x45 ) mm
2 / piece 2 / piece
OT-056PE
P
M
N
S
R
AL - 01 (4MM)
1 / piece
AL - 01 (4MM)
1 / piece
E
OPTIONAL
HEADBOARD
OPTIONAL
HEADBOARD
Page 3 Page 4
KVL-01 x 2
MNX-02 x 4
F VIDEO
link
STEP 1
MNX - 02
KVL 01
STEP 2 210°
210°
STEP 3
B F
D
A-R
B
F
C
D
MNG - 01 x 8
MNG - 01 x 8
MNG - 01
MNG - 01
A-R/A-L
MNX-02 x 8
KVL-01 x 8
MNX-02 x 4
B
KVL-01 x 4
C
KVL-01 x 8
D
Page 3 Page 4
KVL-01 x 2
MNX-02 x 4
F VIDEO
link
STEP 1
MNX - 02
KVL 01
STEP 2 210°
210°
STEP 3
B F
D
A-R
B
F
C
D
MNG - 01 x 8
MNG - 01 x 8
MNG - 01
MNG - 01
A-R/A-L
MNX-02 x 8
KVL-01 x 8
MNX-02 x 4
B
KVL-01 x 4
C
KVL-01 x 8
D
Page 5 Page 6
STEP 4 STEP 6
VIDEO
link
E
E
E
STEP 5
MNG - 01
A-L
210°
MNG - 01 x 8
VD - 02 X 6
AVT - 01X 6
VD - 02 X 8
25 cm
E
H 01
VD - 02 X 8
Page 5 Page 6
STEP 4 STEP 6
VIDEO
link
E
E
E
STEP 5
MNG - 01
A-L
210°
MNG - 01 x 8
VD - 02 X 6
AVT - 01X 6
VD - 02 X 8
25 cm
E
H 01
VD - 02 X 8
Page 7 Page 8
STEP 7 STEP 9
VIDEO
link
STEP 8
Ø 10 mm / 0,254 inch
DD - 01
TFC - 01
DSE - 01
VTB - 01
PL - 02
KVL 01
MNX - 03
MNX - 03 x 5
MNX - 02 x 6
G
STEP 10
MNG - 01
G
G
210°
MNG - 01 x 10
VD - 02x16
TAP - 01
K
K
OPTIONAL
HEADBOARD
K
K
Page 5
STEP 5
STEP 6
VIDEO
link
210°
A-L
STEP 8-1
VD - 02 X 6
AVT - 01X 6
VD - 02 X 6
VD - 02 X 6
25 cm
MNG - 01 x 6
MNG - 01
FİRST LOCATE THE STUDS BY USİNG ''STUD
FİNDER'' İN THE WALL AND DRİLL İT
ACCORDİNG TO THE HEİGHT MEASURMENTS
GİVEN ON THE SİDE.
UPPER HOLES SHOULD BE DRİLLED
FOR ATTACHİNG BED AT NEXT STEP.
WARNING:
Do not mount furniture on to paper-mache or sheetrock like material properly it to stud.
SUPPLY DRYWALL FASTENERS APPROPPRİATE
TO YOUR WALL TYPE. WE RECOMMEND
USİNG STEEL TOGGLE BOLT ANCHOR THAT
SHOWN BELOW
WALLS MADE OF DRYWALL WITH WOODEN OR METAL STUDS
NOT INCLUDED
Page 8
TAP - 01
Page 7
Page 9
STEP 7 STEP 9
VIDEO
link
STEP 8
Ø 10 mm / 0,254 inch
DD - 01
TFC - 01
DSE - 01
VTB - 01
PL - 02
KVL 01
MNX - 03
MNX - 03 x 5
MNX - 02 x 6
G
STEP 10
MNG - 01
G
G
210°
MNG - 01 x 10
VD - 02x16
TAP - 01
K
K
OPTIONAL
HEADBOARD
K
K
