2400 mm
400 mm
1800 mm
1818 mm
ModulateTM Straight 1824
MOD-S-1824
ModulateTM consists of a set of frames made from aluminium tubes (Ø30 mm) covered
with a printed tension fabric graphic. These frames can be connected together using
formats.
Simple assembly with
numbered frame parts
Self-locking system
with bungee poles and
push-buttons
Central reinforcement
tube (Ø 18 mm)
2 stabilising feet with
Twist & Lock supplied
with each frame
Double-sided tension
fabric. Zip system
ModulateTM carry
bag with dedicated
compartments for the
feet and graphics
400 mm extension
included
360° MagLink connector
in each pole. 4 magnets
per structure
- Thanks to the exclusive MagLink magnetic system built into the structure, you can connect the
frames by simply touching them together.
- With the Twist & Lock system, simply position the foot under the structure, turn it and it’s locked!
- The graphics are very easy to maintain thanks to the crease-resistant and machine washable textile
400 (w) x 6 (h) x 80 (d) mm
Aluminium Tubes
Ø 30 mm
4 MagLink connectors
per structure
Central reinforcement
Ø 18 mm
Item Modulate Straight 1824
Code MOD-S-1824
Structure dimensions 1818 (w) x 2400 (h) x 400 (d) mm
Graphic visual area 1800 (w) x 2382 (h) mm
Boxed dimensions (2 boxes) 1000 (w) x 245 (h) x 125 (d) + 460 (w) x 65 (h) x 65 (d) mm
Structure weight 8.18 kg
Boxed weight (2 boxes) 8.65 kg
Modulate half feet (pair)
MOD-HALF-FOOT-P
218 (w) x 6 (h) x 80 (d) mm
Spot LED Flood
LED-FLOOD-ARM-BDLK
Spot LED Strip
LED-STRIP-ARM-BDLK
Fixing for 30mm Ø tubing
US903
PATENT
PENDING
Straight 420
MOD-S-420
Slope 2
MOD-SS-824-02
Straight 824
MOD-S-824
Straight 810
MOD-S-810
Straight 1824
MOD-S-1824
Curved 824
MOD-C-824
Straight 424
MOD-S-424
Straight 1820
MOD-S-1820
Curved 820
MOD-C-820
Straight 820
MOD-S-820
Slope 1
MOD-SS-824-01
