Leica TC605 User manual

TC605/TC805/TC905/L

English

Electronic total station

USER MANUAL

605Z01

2TC605/TC805/TC905/L-1.1.1en © Leica

Thank you for purchasing this Leica Total Station.

This manual contains important safety directions (refer

to section "Safety directions") as well as instructions

for setting up the instrument and operating it. Please

read carefully through the User Manual to achieve

maximum satisfaction.

TC605/TC805/TC905/L

Electronic total station

The instrument model and the serial number of your

product are indicated on the label in the battery

compartment.

Write the model and serial number of your instrument in

the space provided below, and always quote this

information when you need to contact your agency or

service workshop.

Type: Serial no.:

Product identification

4TC605/TC805/TC905/L-1.1.1en © Leica

The symbols used in this User Manual have the

following meanings:

DANGER:

Indicates an imminently hazardous situation which, if

not avoided, will result in death or serious injury.

WARNING:

Indicates a potentially hazardous situation or an

unintended use which, if not avoided, could result in

death or serious injury.

CAUTION:

Indicates a potentially hazardous situation or an

unintended use which, if not avoided, may result in

minor or moderate injury and / or appreciable material,

financial and environmental damage.

Important paragraphs which must be adhered to in

practice as they enable the product to be used in a

technically correct and efficient manner.

Symbols used in this manual

Contents

Introduction 8

Applicability 8

Important parts 9

Set-up, getting started 12

Unpacking 12

Charging battery 13

Set-up 14

Tribrach with optical plummet 14

Tribrach without optical plummet 15

Instrument with laser plummet 16

Level instrument with the electronic level 17

Operating concept 18

Settings, first steps 18

Units in this manual 18

Display and keyboard 19

Fixed keys 20

Function keys 20

Control keys 21

Input keys 21

Inputs 22

Numeric / alphanumeric entry mode 22

Entering reflector height 23

General information 23

Menu tree (main menu) 24

Menu tree (configuration) 25

Menu tree (programs) 26

Main menu 26

Measure and record 27

Display symbols 27

Pointing and distance measurement 28

Example: for offset or hidden points 29

Tracking mode 30

Display of recorded measurements 30

Measure and record with coding 31

Coding 32

Input a new code line to the code list 32

Function "Quick-Code" 33

Simple code input during measurements 34

Additional entries to selected code 36

Recording codes 37

Searching for codes using wildcards 38

6TC605/TC805/TC905/L-1.1.1en © Leica

User Programs 39

Introduction 39

Point search in programs 39

Set Job 40

Set station coordinates and Orientation

(Set Station) 41

Orientation of horizontal circle 45

Free Station 47

Setting out (Setout) 52

Tie Distance (Missing line) 54

Area computation (Calc Area) 57

Rapid measurement and recording (Rapid Meas) 60

Reference Line (Ref. Line) 62

Settings 70

Entering point number and reflector height 70

Setting the horizontal circle (Hz) 72

1st variant 72

2nd variant 73

Setting the display mask (DSP) 74

Data management (DATA MANAGER) 75

Input of coordinates and codes (INPUT) 76

Coordinate entry (COORDS) 76

Code input (CODES) 77

Searching for point numbers and multiple

recordings (FIND) 78

Searching for several data blocks with the same

point number 80

Display of stored data (VIEW) 81

Delete measurements, coordinates and codes

(DELETE PNT) 82

Delete the complete range of measurements,

coordinates and codes (DELETE ALL) 83

EDM Configuration (EDM CONF) 84

1. EDM mode 84

2. EGL (Guide Light) 84

3. INTENS 85

4. RETTAP 86

Testing the instrument 88

Battery and instrument temperature 88

EDM Signal (INTENSITY) 89

Configuration (CONFIG MENU) 90

Distance corrections 91

Display contrast (CONTRA) 93

Data and recording parameter (REC DATA) 94

Selecting units (UNITS) 97

Setting time and date (TIME/DATE) 99

Automatic switch-off (ON/OFF) 101

TCTOOLS 104

Other data formats 110

Communication TC605/TC805/TC905/L and

PC/Datalogger 111

Set a point number 111

Set station coordinates 111

Set orientation 111

Setting-out 112

Checking and adjusting 113

Determine instrument errors (CALIB) 113

Vertical index error 114

Line-of-sight error (Hz-collimation) 117

Tripod 118

Circular level 119

Circular level on the tribrach 119

Optical plummet 120

Laser plummet 122

Care and transport 124

Battery charging 126

Battery chargers GKL22 and GKL23 126

Battery chargers GKL12 and GKL14 127

Safety directions 128

Intended use of instrument 128

Limits of use 129

Responsibilities 130

Hazards of use 131

Laser classification 136

Integrated distancer (EDM) 136

Guide Light EGL1

(optional for TC805/TC905/L series) 138

Laser plummet 140

Electromagnetic acceptability 144

FCC statement (applicable in U.S.) 145

Product labeling 146

Error reports and warnings 147

Technical data 149

Index 155

8TC605/TC805/TC905/L-1.1.1en © Leica

Introduction

The TC605/TC805/TC905/L is particularly suitable for

engineering, building and construction surveys with a

focus on setting outs, volume determinations and

tacheometry surveys. Fast and easy coding facilities are

provided. The accuracy of angle-measuring, and the

range of its EDM module, are matched to one another.

The measured data can be stored in the internal memory

or can be output individually via serial interface to an

external recorder.

Applicability This manual applies to the following types of total

stations:

• TC605, TC605L

• TC805, TC805L

• TC905, TC905L

Differences between the three versions TC605/TC805/

TC905/L are clearly set out and assigned.

General text applies to all versions.

Important parts TC605/L

1 Foot screw

2 Keyboard

3 Display

4 Focusing

5 Carrying handle

6 EDM transmitter

7 Battery

8 Vertical drive

9 Horizontal drive

10 Serial Interface

RS-232

11 Circular level

12 Optical sight

12 7

605Z03

910

81 112 36

10 TC605/TC805/TC905/L-1.1.1en © Leica

TC805/L

18 102

605Z04

1 Foot screw

2 Keyboard

3 Display

4 Focusing

5 Carrying handle

6 EDM, Telescope

7 Battery

8 Vertical drive

9 Horizontal drive

10 Serial Interface

RS-232

11 Circular level

12 Optical sight

13 EGL1 (optional)

6 3 11 9

12 13 54
