LawnMaster CLMF2437G User manual
Instruction Manual
37cm 24V Lithium-Ion Cordless Mower CLMF2437G
Read all safety instructions carefully before assembling and operating
this machine. Ensure the machine has been assembled correctly and safely. Keep the
instructions safe and pass them on to any subsequent user so that the information is always
available.
WARNING:
Original Instructions
23 22
24 25 26
2
3
4
5
6
7
8
10
11
12
13
14
15
18
21
19
20
9
1
16
17
Fig.1
① ② Fig.2
Fig.4
Fig.3
5
TABLE OF CONTENTS
Section Page
Symbols
Safety Information
In the Box
Assembly
Operation
Maintenance
Troubleshooting
Technical data
Recycling and Disposal
6
7-16
16
17-19
20-24
25-27
28-29
30
31
6
SYMBOL DESIGNATION/EXPLANATION
Caution
Read instruction manual.
Keep bystanders away.
Beware of sharp blades. Blades may continue to rotate after the motor is
switched off. Beware of injury to toes or ngers.
Switch off and remove the isolator key before adjusting, cleaning or before
leaving the product unattended for any period.
Cutting diameter
Protection class II (Double insulation)
Only recharge battery packs with the supplied charger indoors.
Fuse
Electrical appliances must not be disposed of with the domestic waste.
Batteries contain Lithium-ion. Do not dispose of batteries in household waste.
Do not dispose of battery packs in rivers or immerse in water.
Do not dispose of battery packs in re.
Do not subject the battery to direct sunlight over long periods and do not leave it
on or near a heat source (max. 60°C).
Recycle electrical waste products in an environmentally safe way where facilities
exist.
SYMBOLS
The following warning symbols appear throughout this manual and indicate the
appropriate safety measures you should take when operating and maintaining the
appliance.
T/3.15A
Li-ion
To avoid serious personal injury, do not attempt to use this product until you read thoroughly and
understand completely the instruction manual.
If you do not understand the warnings and instructions in the instruction manual, do not use this
product.
WARNING
37cm
7
SAFETY INFORMATION
When using equipment, the following safety precautions
must be followed to avoid injuries and damage:
IMPORTANT
■ Read all operating instructions carefully and comply with
them. It is important to understand these instructions and to
acquaint yourself with the machine, its correct usage and
all safety requirements.
■ Keep this manual in a safe place so that the information is
available to the operator at all times.
■ If you give the equipment to any other person, give them
these operating instructions as well.
■ We accept no liability for damage or accidents which result
from non-compliance with these instructions.
The device must not be used by people (including children)
with limited physical, sensory or mental capabilities or who
lack the necessary experience and/or knowledge - other than
they are supervised by a person responsible for safety or are
being instructed to operate the appliance by such a person.
Children should be supervised to ensure that they do not play
with the appliance.
■ Read the instructions carefully. Be familiar with the controls
and the correct use of the lawn mower.
■ Never allow children or people unfamiliar with these
instructions to use the mower. Local regulations may
restrict the age of the operator.
■ When not in use, store the mower out of reach of children
and remove the battery pack and isolator key.
8
SAFETY INFORMATION
■ Never operate the machine while people, especially
children, or pets are nearby.
■ Use extreme care when approaching blind corners,
doorways, shrubs, trees, or other objects that may obscure
your view of a child or animal that may run into the path of
the mower.
■ Keep in mind that the operator or user is responsible for
accidents or hazards occurring to other people or their
property.
■ While operating the mower always wear substantial
footwear and long trousers. Do not operate the mower
when barefoot or wearing open toed sandals. Avoid
wearing clothing that is loose tting or that has hanging
cords or ties.
■ Thoroughly inspect the area where the mower is to be
used. Remove all stones, sticks, and other objects that could
be tripped over or thrown by the blade. Thrown objects can
cause serious personal injury.
■ Before using, always visually inspect to see that the
blade, blade bolt and the blade assembly are not worn or
damaged. Replace worn or damaged components in sets
to preserve balance. Replace damaged or unreadable
labels.
■ Operate the mower only in daylight or in good articial light.
■ Do not use the lawn mower in damp or wet conditions or
operate in the rain.
■ Working on sloping areas can be dangerous. Do not mow
on excessively steep slopes. Always be sure of your footing
on slopes or wet grass.
■ Walk, never run.
9
SAFETY INFORMATION
■ Mow across the face of slopes, never up and down.
■ Exercise extreme caution when changing direction on
slopes.
■ Use extreme caution when reversing or pulling the mower
towards you.
■ Stay Alert: Do not operate the mower when you are tired.
Pay attention to what you are doing.
■ Do not operate the mower while under the inuence of
alcohol or drugs.
■ Stop the blade(s) if the machine has to be tilted for
transportation when crossing surfaces other than grass,
and when transporting the machine to and from areas to be
mowed.
■ Never operate the mower with defective guards or shields,
or without safety devices, for example deectors and/or
grass collector, in place.
■ Switch on the motor carefully according to instructions and
with feet well away from the blade(s).
■ Do not tilt the machine when starting or switching the
motor on, except if the machine must be tilted for starting
in long grass. In this case, do not tilt it more than absolutely
necessary and tilt only the part which is furthest away
from the operator. Always ensure that both hands are in
the operating position on the handle before returning the
machine to the ground.
■ Do not start the mower when standing in front of the
discharge opening.
■ Do not put hands or feet near or under rotating parts. Keep
clear of the discharge opening at all times.
■ Never pick up or carry the machine while the motor is
running.
10
SAFETY INFORMATION
■ Do not carry the machine with your nger on the switch.
■ Do not overreach. Keep proper footing and balance at all
times.
■ Do not use a machine if the switch does not turn it on and
off. Any machine that cannot be controlled with the switch
is dangerous and must be repaired.
■ In case any of the following situations occur, stop the
mower and remove the battery pack and isolator key. Make
sure that all moving parts have come to a complete stop:
− Whenever you leave the mower,
− Before clearing blockages or unclogging discharge chute,
− Before checking, cleaning or working on the mower,
− After striking a foreign object. Inspect the mower for
damage and make repairs before restarting and operating
the mower.
■ If the mower starts to vibrate abnormally (check
immediately)
− Inspect for damage,
− Replace or repair any damaged parts,
− Check for and tighten any loose parts.
■ In order to avoid contact with the blade or injury caused
by a thrown object, ensure you maintain a safe operating
distance, and keep children and bystanders at least 15m
away from the mower while it is in operation. Stop the
motor immediately if someone enters the mowing area.
■ Always wear proper eye protection in order to protect your
eyes while operating or performing any adjustment or
repair. Thrown objects that ricochet can cause serious eye
injury.
■ Do not hold on to the mower if you are falling. Release the
