Kubota L4600 User manual

L4600MODEL

OPERATOR'S MANUAL

1AGAPBYAP0010

English (Oceania)

Code No. TC437-5971-1

READ AND SAVE THIS MANUAL

1205-1149

KUBOTA Corporation is ···

Since its inception in 1890, KUBOTA Corporation has grown to

rank as one of the major firms in Japan.

To achieve this status, the company has through the years

diversified the range of its products and services to a remarkable

extent. Nineteen plants and 16,000 employees produce over 1,000

different items, large and small.

All these products and all the services which accompany them,

however, are unified by one central commitment. KUBOTA makes

products which, taken on a national scale, are basic necessities.

Products which are indispensable. Products which are intended to

help individuals and nations fulfill the potential inherent in their

environment. KUBOTA is the Basic Necessities Giant.

This potential includes water supply, food from the soil and from

the sea, industrial development, architecture and construction, and

transportation.

Thousands of people depend on KUBOTA's know-how,

technology, experience and customer service. You too can depend

on KUBOTA.

L4600

AQ. F. 1-1. -. K

Thank you very much for choosing the L series tractor.

This operator's manual covers the operation, inspection and preventive

maintenance instructions that is specific to the oceania models. For other

information and instructions, refer to the separately issued operator's manual for

the sister model. (L series tractor)

Please read both manuals carefully, to operate the machine properly and safely.

Proper daily inspection, servicing and lubrication keeps your machine in good

condition.

This symbol, the industry's "Safety Alert Symbol", is used throughout this

manual and on labels on the machine itself to warn of the possibility of personal

injury. Read these instructions carefully. It is essential that you read the

instructions and safety regulations before you attempt to assemble or use this

unit.

DANGER : Indicates an imminently hazardous situation which, if not

avoided, will result in death or serious injury.

WARNING : Indicates a potentially hazardous situation which, if not

avoided, could result in death or serious injury.

CAUTION : Indicates a potentially hazardous situation which, if not

avoided, may result in minor or moderate injury.

IMPORTANT : Indicates that equipment or property damage could result if

instructions are not followed.

NOTE : Gives helpful information.

FOREWORD

SAFETY FIRST

CONTENTS

SAFE OPERATION ................................................................................................. 1

SPECIFICATIONS....................................................................................................... 1

SPECIFICATION TABLE ......................................................................................... 1

TRAVELING SPEEDS ............................................................................................. 3

INSTRUMENT PANEL AND CONTROLS................................................................... 4

OPERATING THE TRACTOR ..................................................................................... 5

STARTING ............................................................................................................... 5

Head Light Switch.............................................................................................................5

Turn Signal / Hazard Light Switch ....................................................................................5

Horn Button....................................................................................................................... 5

Tractor Lights.................................................................................................................... 6

Electrical Outlet.................................................................................................................6

THREE-POINT HITCH & DRAWBAR.......................................................................... 7

DRAWBAR............................................................................................................... 7

Adjusting Drawbar Length ................................................................................................ 7

PERIODIC SERVICE................................................................................................... 8

SERVICE AS REQUIRED........................................................................................ 8

Replacing Fuse.................................................................................................................8

Replacing Light Bulb......................................................................................................... 8

1SAFE OPERATION

SAFE OPERATION

1. Keep danger, warning and caution labels clean and free from obstructing material.

2. Clean danger, warning and caution labels with soap and water, dry with a soft cloth.

3. Replace damaged or missing danger, warning and caution labels with new labels from your local KUBOTA Dealer.

4. If a component with danger, warning and caution label(s) affixed is replaced with new part, make sure new label(s) is

(are) attached in the same location(s) as the replaced component.

5. Mount new danger, warning and caution labels by applying on a clean dry surface and pressing any bubbles to outside

edge.

1. DANGER, WARNING AND CAUTION LABEL(S)

2. CARE OF DANGER, WARNING AND CAUTION LABEL(S)

1SPECIFICATIONS

SPECIFICATIONS

SPECIFICATION TABLE

Model

L4600

Manual Transmission HST

4WD

Engine

Model V2203-M-E3-LB3

Type Indirect injection, Vertical, Water-Cooled 4 cycle diesel

Number of cylinders 4

Total displacement L 2.197

Bore and stroke mm 87 x 92.4

Rated revolution rpm 2600

Low idling revolution rpm 900 - 1000

Net power* kW (HP) / rpm 32.7 / 2600

PTO power*

(factory observed) kW (HP) / rpm 28.6 / 2600 27.4 / 2600

Maximum torque : Gross N-m 143.2

Battery capacity 12V, RC : 133min, CCA : 582A

Capacities

Fuel tank L 48

Engine crankcase (with filter) L 7.6

Engine coolant L 6.5

Transmission case L 40

Dimensions

Overall length (without 3p) mm 3120

Overall width (min. tread) mm 1585

Overall height (with ROPS) mm 2330

Wheel base mm 1845

Min. ground clearance mm 385

Tread

Front mm 1155

Rear mm 1180, 1200, 1300, 1450, 1545

Weight (with ROPS) kg 1445 1450

Traveling

system

Standard

tire size

Front 8.3 - 16

Rear 14.9 - 24

Clutch Dry type single stage

Steering Hydrostatic power steering

Transmission Gear shift, 8 forward and 8 reverse Hydrostatic transmission

3 range speed

Braking system Mechanical, Wet disk type

Min. turning radius (with brake) m 2.6

2 SPECIFICATIONS

NOTE: *Manufacturer's estimate The company reserves the right to change the specifications without notice.

Model

L4600

Manual Transmission HST

4WD

Hydraulic

unit

Hydraulic control system Position control

Pump capacity L / min 29.4

Three point hitch Category 1

Max. lift

force

At lift points kg 1300

24 in. behind lift

points kg 1053

System pressure MPa

(kgf / cm ) 17.7 (180)

PTO

Rear PTO SAE 1-3/8, 6-splines

PTO / Engine speed rpm 540 / 2475 540 / 2640

3SPECIFICATIONS

TRAVELING SPEEDS

[Manual Transmission Type] (At rated engine rpm)

Model L4600

Tire size (Rear) 14.9-24

Range gear

shift lever

Main gear

shift lever km/h

Low

1 2.2

2 2.8

3 4.6

4 6.7

High

1 8.0

2 10.0

3 16.3

4 24.0

Low

1 2.1

2 2.7

3 4.4

4 6.4

High

1 7.7

2 9.6

3 15.6

4 23.0

The company reserves the right to change the specifications without notice

[HST Type] (At rated engine rpm)

Model L4600

Tire size (Rear) 14.9-24

Range shift lever km/h

L 5.9

M 12.2

H 25.4

L 5.3

M 11.0

H 22.9

The company reserves the right to change the specifications without notice

4 INSTRUMENT PANEL AND CONTROLS

INSTRUMENT PANEL AND CONTROLS

BInstrument Panel, Switches and Hand Controls

ILLUSTRATED CONTENTS

(1) Electrical charge lamp.......................... -

(2) Engine oil pressure lamp...................... -

(3) Glow plug indicator.............................. -

(4) Fuel gauge........................................... -

(5) Horn button.......................................... 5

(6) Turn signal switch................................

(7) Head light switch..................................

(8) Hazard light switch...............................

(9) Turn signal / Hazard light indicator.......

(10) Coolant temperature gauge................. -

(11) Hourmeter / Tachometer...................... -

(12) Key switch............................................ -

5OPERATING THE TRACTOR

OPERATING THE TRACTOR

STARTING

BHead Light Switch

Turn the light switch clockwise, and the following lights are

activated on the switch position.

BTurn Signal / Hazard Light Switch

CTurn Signal Light Switch

To indicate a right turn, turn the turn signal light switch

clockwise. To indicate a left turn, turn the turn signal light

switch counter-clockwise. The corresponding right and

left turn signal lights and indicator on the instrument panel

will flash. Turn signal is active when key switch is in the

"ON" position.

ABe sure to return switch to center position after turning.

CHazard Light Switch

When hazard light switch is pushed, the hazard lights

flash along with the indicator on the instrument panel.

Press the hazard light switch again to turn off the light.

BHorn Button

The horn will sound when the key switch is in the "ON"

position and the horn button pressed.

(1) Head light switch

Light name

Switch Position

Head light (Low beam) OFF ON ---

Head light (High beam) OFF --- ON

Tail light OFF ON ON

(1) Turn signal light switch

(2) Hazard light switch

(3) Hazard / Turn signal indicator

(1) Horn button (A) "PUSH"
