Husqvarna LB 548i User manual

LB 548i, LC 551iV, LB 553iV

EN Operator's manual 2-33

BG Ръководство за експлоатация 34-68

CS Návod k použití 69-99

DA Brugsanvisning 100-130

DE Bedienungsanweisung 131-163

EL Οδηγίες χρήσης 164-198

ES Manual de usuario 199-231

ET Kasutusjuhend 232-261

FI Käyttöohje 262-292

FR Manuel d'utilisation 293-325

HR Priručnik za korištenje 326-356

HU Használati utasítás 357-388

IT Manuale dell'operatore 389-420

JA 取扱説明書 421-450

LT Operatoriaus vadovas 451-481

LV Lietošanas pamācība 482-513

NL Gebruiksaanwĳzing 514-545

NO Bruksanvisning 546-575

PL Instrukcja obsługi 576-608

PT Manual do utilizador 609-641

RO Instrucţiuni de utilizare 642-673

RU Руководство по эксплуатации 674-708

SK Návod na obsluhu 709-740

SL Navodila za uporabo 741-771

SR Priručnik za rukovaoca 772-802

SV Bruksanvisning 803-833

TR Kullanım kılavuzu 834-863

UK Посібник користувача 864-897

ZH 操作手册 898-924

Contents

Introduction..................................................................... 2

Safety..............................................................................7

Assembly...................................................................... 14

Operation...................................................................... 18

Maintenance................................................................. 25

Troubleshooting............................................................ 27

Transportation, storage and disposal........................... 28

Technical data.............................................................. 29

Declaration of Conformity............................................. 32

Introduction

Product description

The product is a pedestrian-controlled rotary lawn

mower. The models LB 548i and LB553iV use BioClip

to cut the grass into fertilizer.

The model LC551iV collects the grass in a grass

catcher. Remove the grass catcher to get rear discharge

of the grass. Attach a mulch kit (accessory) to cut the

grass into fertilizer.

Intended use

Use the product to cut grass. Do not use the product for

other tasks.

21630 - 004 -

Product overview (LB548i, LC551iV)

LB 548i

LC 551iV

21 6

1116 12 17

1. Control panel

2. Motor brake handle

3. Start inhibitor

4. Grass catcher (LC551iV)

5. Rear cover (LC551iV)

6. Safety key

7. Handle knob (LC551iV)

8. Handle adjustment lever (LB 548i)

9. Battery cover

10. Cutting height control (LC551iV)

11. ON/OFF button

12. SavE button

13. SavE indicator

14. Battery indicator

15. Speed level indicator

16. Decrease speed button

17. Increase speed button

18. Error LED

19. Cutting cover

20. Air intakes

21. Protection cover (LC551iV)

22. Rating plate

23. Drive bail (LC551iV)

24. Battery charger (Accessory)

1630 - 004 - 3

25. Battery (Accessory)

26. Multi battery (Accessory)

27. Adapter plate (Accessory)

28. Multi battery adapter (Accessory)

29. Mulch kit (LC551iV)

30. Operator's manual

Product overview (LB 553iV)

LB 553iV

18 17

813 9 14

1. Control panel

2. Motor brake handle

3. Start inhibitor

4. Safety key

5. Handle adjustment lever

6. Battery cover

7. Cutting height control

8. ON/OFF button

9. SavE button

10. SavE indicator

11. Battery indicator

12. Speed level indicator

13. Decrease speed button

14. Increase speed button

15. Error LED

16. Cutting cover

17. Air intakes

18. Protection cover

19. Rating plate

20. Drive control lever

21. Battery charger (Accessory)

22. Battery (Accessory)

23. Multi battery (Accessory)

24. Adapter plate (Accessory)

25. Multi battery adapter (Accessory)

26. Operator's manual

Symbols on the product

WARNING: This product

can be dangerous and

cause serious injury or

death to the operator

41630 - 004 -

or others. Be careful

and use the product

correctly.

Read the operator's

manual carefully and

make sure that

you understand the

instructions before you

use this product.

Keep persons and

animals at a safe

distance from the work

area.

Look out for thrown

objects and ricochets.

Warning: Keep hands

and feet away from the

rotating blade.

Warning: Keep hands

and feet away from

rotating parts.

Remove the safety key

before you do repair

work or maintenance.

Environmental mark.The

product or package

of the product

is not domestic

waste. Recycle it

at an approved

disposal location for

electrical and electronic

equipment.

The product agrees with

applicable EC directives.

This product conforms

to applicable UK

regulations.

The product agrees

with applicable Eurasian

Customs Union

directives.

The product agrees with

applicable UkrSEPRO

directives.

The product agrees

with applicable RCM

directives. Applies to

AU/NZ only.

Noise emission to

the environment

label as per EU

and UK directives

and regulations, and

New South Wales

legislation "Protection

of the Environment

Operations (Noise

Control) Regulation

2017". The guaranteed

sound power level of

the product is specified

1630 - 004 - 5

Technical data on

page 29

and on the

label.

Protected against

splashing water.

Start proce-

dure: push

ON/OFF but-

ton, loosen

start inhibitor,

push motor

brake handle

down.

Release motor brake

handle to stop.

Slow

Fast

Scannable code

Note: Other symbols/decals on

the product refer to certification

requirements for some markets.

Label on the product

DANGER – Keep hands and feet away.

Product liability

As referred to in the product

liability laws, we are not liable

for damages that our product

causes if:

•the product is incorrectly

repaired.

•the product is repaired with

parts that are not from the

manufacturer or not approved

by the manufacturer.

•the product has an accessory

that is not from the

manufacturer or not approved

by the manufacturer.

•the product is not repaired at

an approved service center or

by an approved authority.

61630 - 004 -

Safety

Safety definitions

Warnings, cautions and notes

are used to point out specially

important parts of the manual.

WARNING: Used if

there is a risk of

injury or death for the

operator or bystanders

if the instructions in the

manual are not obeyed.

CAUTION: Used if there

is a risk of damage to the

product, other materials

or the adjacent area if

the instructions in the

manual are not obeyed.

Note: Used to give more

information that is necessary in

a given situation.

General safety instructions

WARNING: Read the

warning instructions that

follow before you use the

product.

•This product is dangerous if

used incorrectly or if you are

not careful. Injury or death can

occur if you do not obey the

safety instructions.

•This product produces an

electromagnetic field during

operation. This field may

under some circumstances

interfere with active or passive

medical implants. To reduce

the risk of serious or fatal

injury we recommend persons

with medical implants to

consult their physician and the

medical implant manufacturer

before operating this product.

•Always be careful and use

your common sense. If you

are not sure how to operate

the product in a special

situation, stop and speak to

your Husqvarna dealer before

you continue.

•Keep in mind that the operator

will be held responsible for

accidents that involve other

persons or their property.

•Keep the product clean. Make

sure that you can clearly read

signs and decals.

•Never allow children or

people unfamiliar with these

instructions to use the

appliance. Local regulations

may restrict the age of the

operator

1630 - 004 - 7

•Always monitor a person, with

decreased physical capacity or

mental capacity, that uses the

product. A responsible adult

must be there at all times.

•Do not use the product if

you are tired, ill, or under

the influence of alcohol, drugs

or medicine. This has a

negative effect on your vision,

alertness, coordination and

judgment.

•Do not use the product if it is

defective.

•Do not change this product or

use it if it is possible that it has

been changed by others.

Work area safety

WARNING: Read the

warning instructions that

follow before you use the

product.

•Remove objects such as

branches, twigs and stones

from the work area before you

use the product.

•Objects that hit against the

cutting equipment can eject

and cause damage to persons

and objects. Keep bystanders

and animals at a safe distance

from the product.

•Never use the product in bad

weather such as fog, rain,

strong winds, intense cold and

risk of lightning. To use the

product in bad weather or

in moist or wet locations is

tiring. Bad weather can cause

dangerous conditions, such as

slippery surfaces.

•Look out for persons, objects

and situations that can prevent

safe operation of the product.

•Look out for obstacles, such

as roots, stones, twigs, pits

and ditches. Long grass can

hide obstacles.

•To cut grass on slopes can

be dangerous. Do not mow

excessively steep slopes. Do

not use the product on ground

that slopes more than 15°

•Exercise extreme caution

when changing direction on

slopes. Operate the product

across the face of slopes. Do

not move up and down.

•Be careful when you go near

hidden corners and objects

that prevent a clear view.

Work safety

WARNING: Read the

warning instructions that

follow before you use the

product.

81630 - 004 -

•Use this product to cut grass

lawns only. It is not permitted

to use it for other tasks.

•Use personal protective

equipment. Refer to

Personal

protective equipment on page

•Make sure that you know how

to stop the motor quickly in an

emergency.

•Do not operate the product in

rain or wet conditions. The risk

of electrical shock increases if

water enters the product.

•Do not operate the product

unless the blade and all

covers are attached correctly.

An incorrectly attached blade

can come loose and cause

personal injury.

•Make sure that the blade

does not hit objects such as

stones and roots. This can do

damage to the blade and bend

the motor shaft. A bent axle

causes heavy vibration and a

very high risk that the blade

becomes loose.

•If the blade hits an object

or if vibrations occur, stop

the product immediately. Stop

the motor, pull up the safety

key and remove the battery.

Examine the product for

damages. Repair damages or

let an authorised service agent

do the repair.

•Never attach the motor brake

handle permanently to the

handle when the motor is

started.

•Put the product on a stable,

flat surface and start it. Make

sure that the blade does not

hit the ground or other objects.

•Always stay behind the

product when you operate it.

•Let all the wheels stay on

the ground and keep 2 hands

on the handle when you

operate the product. Keep

your hands and feet away

from the rotating blades.

•Do not tilt the product when

the motor is started.

•Be careful when you pull the

product rearward.

•Never lift up the product when

the motor is started. If you

must lift the product, first stop

the motor, pull up the safety

key and remove the battery.

•Do not walk rearward when

you operate the product.

•Stop the motor when you

move across areas without

grass, for example paths

made of gravel, stone and

asphalt.

•Do not run with the product

when the motor is started.

1630 - 004 - 9

Always walk when you operate

the product.

•Stop the motor before you

change the cutting height.

Never make adjustments with

the motor started.

•Never let the product stay

out of view with the motor

started. Stop the motor and

make sure that the cutting

equipment does not rotate.

Safety instructions for operation

Personal protective equipment

WARNING: Read the

warning instructions that

follow before you use the

product.

•Personal protective equipment

cannot fully prevent injury but

it decreases the degree of

injury if an accident does

occur. Let your dealer help

you select the right equipment.

•Use heavy-duty slip-resistant

boots or shoes. Do not use

open shoes or go with bare

feet.

•Use heavy, long pants.

•Use protective gloves when

necessary, for example when

you attach, examine or clean

the cutting equipment.

Safety devices on the product

WARNING: Read the

warning instructions that

follow before you use the

product.

•Do not use a product with

defective safety devices.

•Do not remove or do

modifications to safety

devices.

•Do a check of the safety

devices regularly. If the safety

devices are defective, speak

to your Husqvarna service

agent.

To do a check of the cutting

cover

The cutting cover decreases

vibrations in the product and

decreases the risk of injury from

the blade.

• Examine the cutting cover to

make sure that there are no

damages such as cracks.

Safety key

The safety key is below

the battery lid. The safety

key connects the battery that

supplies the motor with power.

10 1630 - 004 -

Other manuals for LB 548i

This manual suits for next models

Table of contents

Languages:

Other Husqvarna Lawn Mower manuals

Husqvarna

Husqvarna LTH2142 User manual

Husqvarna

Husqvarna 532 43 70-40 User manual

Husqvarna

Husqvarna YTH180XP User manual

Husqvarna

Husqvarna CTH200 TWIN User manual

Husqvarna

Husqvarna LTH2038R User manual

Husqvarna

Husqvarna YTH2642TDF User manual

Husqvarna

Husqvarna LGT25K54 User manual

Husqvarna

Husqvarna LGT48DXL User manual

Husqvarna

Husqvarna CTH 141 User manual

Husqvarna

Husqvarna P 520DX User manual

Husqvarna

Husqvarna YTH18K42 User manual

Husqvarna

Husqvarna Automower 305 User manual

Husqvarna

Husqvarna YTH2042 User manual

Husqvarna

Husqvarna TS 146XK User manual

Husqvarna

Husqvarna 917.375830 User manual

Husqvarna

Husqvarna AUTOMOWER 320 NERA User manual

Husqvarna

Husqvarna MZ28ZT BF User manual

Husqvarna

Husqvarna GTH2548 User manual

Husqvarna

Husqvarna YTH2242 TF User manual

Husqvarna

Husqvarna M48 Pro, M53 S Pro User manual

Husqvarna

Husqvarna 5521RS Setup guide

Husqvarna

Husqvarna PT26 D User manual

Husqvarna

Husqvarna AutoMower G2 User manual

Husqvarna

Husqvarna YTH1542XP User manual

Popular Lawn Mower manuals by other brands

RHINO

RHINO 1958 parts manual

Wolf Garten

Wolf Garten Compact plus 40 B instruction manual

Cub Cadet

Cub Cadet LTX 1045 brochure

Craftsman

Craftsman 917.378461 owner's manual

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Operator's manual

Challenge

Challenge CH18V2 Original manual

TALEN TOOLS

TALEN TOOLS AVR HGM30 manual

DEWEZE

DEWEZE ATM-725 Operation and service manual

Weed Eater

Weed Eater 180083 owner's manual

Better Outdoor Products

Better Outdoor Products Quick Series Operator's manual

Cub Cadet

Cub Cadet 23HP Z-Force 60 Operator's and service manual

MTD

MTD 795, 792, 791, 790 Operator's manual

Toro

Toro Groundsmaster 3505-D Service manual

Dennis

Dennis FT 610 instruction manual

AIRFORCE

AIRFORCE F-15 Gen 3 owner's manual

MTD

MTD 126-220-000 owner's guide

Toro

Toro 74806 Operator's manual

Stihl

Stihl RMA 443 PV instruction manual
