Grandstream Networks GXP2160 User manual

Innovative IP Voice & Video

GXP2160

Enterprise IP Telephone

Corporate Headquarters:

126 Brookline Avenue, 3rd Floor

Boston, MA 02215, USA

Regional Offices: Dallas, TX, USA Los Angeles, CA, USA Casablanca, Morocco Valencia, Venezuela Hangzhou, China Shenzhen, China

Grandstream Networks, Inc. www.grandstream.com [email protected]

I II I I

The GXP2160 is a state-of-the-art enterprise level 6-line SIP phone that features a 4.3 inch color LCD, 5 programmable context-sensitive

soft keys, 24 programmable BLF extension keys, dual Gigabit network ports, integrated PoE and Bluetooth, 5-way voice-conferencing,

and Electronic Hook Switch (EHS). The GXP2160 delivers superior HD audio quality on the handset and speakerphone, rich and cutting

edge telephony features, and personalized information and customizable application service. The GXP2160 also supports automated

provisioning for easy deployment, advanced security protection for privacy, and broad interoperability with most 3rd party SIP devices

and leading SIP/NGN/IMS platforms. Ideal for enterprise and SMBs, the GXP2160 is a powerful color-screen IP Phone for users who

handle high call volume and require access to advanced voice communication features.

480x272 TFT color LCD

6 dual-color line keys (with 6 SIP accounts), 5 programmable context-

sensitive soft keys, up to 5-way conferencing, and 24 dual-color BLF

extension keys

Dual switched auto-sensing 10/100/1000Mbps Gigabit network ports,

PoE, Bluetooth, USB, and EHS (Electronic Hook-Switch) with

Plantronics headsets

Automated provisioning using TR-069 or AES encrypted XML

conﬁguration ﬁle, TLS/SRTP/HTTPS for advanced security

and privacy protection

Integrated real-time web applications [weather, currency,

RSS news (pending), etc.]

GXP2160

Feature Highlights

•

Protocols / Standards

Feature Keys

Voice Codecs

Telephony Features

Base Stand

Wall Mountable

QoS

Bluetooth

Auxiliary Ports

Sample Applications

Security

Multi-language

Upgrade/Provisioning

Power &

Green Energy Efficiency

Physical

Temperature and Humidity

Package Content

Innovative IP Voice & Video

Technical Specifications

GXP2160

SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE,

TELNET, TFTP, NTP, STUN, SIMPLE, LLDP, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6

Dual switched auto-sensing 10/100/1000 Mbps Gigabit Ethernet ports with integrated PoE

4.3 inch (480x272) TFT color LCD

6 line keys with up to 6 SIP accounts, 24 speed-dial/BLF extension keys with dual-color LED,

5 programmable context sensitive softkeys, 5 navigation/menu keys, 11 dedicated function keys

for : MESSAGE (with LED indicator), PHONEBOOK, TRANSFER, CONFERENCE, HOLD, HEADSET,

MUTE, SEND/REDIAL, SPEAKERPHONE, VOL+, VOL-

Support for G.729A/B, G.711µ/a-law, G.726, G.722(wide-band),

in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO)

Hold, transfer, forward, 5-way conference, call park, call pickup, shared-call-appearance (SCA)/

bridged-line-appearance (BLA), downloadable phonebook (XML, LDAP, up to 2000 items), call waiting,

call log (up to 500 records), customization of screen, off-hook auto dial, auto answer, click-to-dial, ﬂexible dial plan,

hot desking, personalized music ringtones and music on hold, server redundancy and fail-over

Weather, currency, news

GMI available for advanced custom application development (pending)

Yes, allow 2 angle positions

Yes, both on handset and speakerphone

Yes

Layer 2 (808.1Q, 802.1p) and Layer 3 (ToS, DiffServ, MPLS) QoS

Firmware upgrade via TFTP/HTTP/HTTPS, mass provisioning using TR-069 or encrypted XML conﬁguration ﬁle

English, Arabic, Chinese, Croatian, Czech, Dutch, German, French, Hebrew, Hungarian, Italian, Japanese,

Korean, Polish, Portuguese, Russian, Slovenia, Spanish, Turkish

0 ~ 40ºC (32 ~ 104ºF ), 10 ~ 90% (non-condensing)

FCC Part 15 (CFR 47) Class B; EN55022 Class B, EN55024, EN61000-3-2, EN61000-3-3, EN 60950-1, EN62479

AS/NZS CISPR 22 Class B, AS/NZS CISPR 24, RoHS; UL 60950 (power adapter)

Yes, Bluetooth V2.1

RJ9 headset jack (allowing EHS with Plantronics headsets), USB

User and administrator level passwords, MD5 and MD5-sess based authentication, AES based secure

conﬁguration ﬁle, SRTP, TLS, 802.1x media access control

Universal power adapter included: Input: 100-240V; Output: +12V, 1A;

Integrated Power-over-Ethernet (802.3af)

Max power consumption:6W

Dimention: 275.5mm (W) x 206mm (L) x 46.5mm (H);

Unit weight: 0.98kg; Package weight: 1.62kg

GXP2160 phone, handset with cord, base stand, universal power supply, network cable, Quick Start Guide
