Genie SSIP2DVAF User manual
Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference. All the examples and pictures used
here are for reference only. The contents of this manual are subject
to change without notice.
2MP Stainless Steel IP IR Dome
Camera with 2.8-12mm Auto
Focus Lens
SSIP2DVAF
Quick Start Guide 2MP Stainless Steel IP IR Dome Camera with 2.8-12mm Auto Focus Lens
2
Features
• 1/2.8” Sony 2MP Starvis image sensor
• 1080p full HD resolution
• 2.8–12mm megapixel auto focus motorised lens
• Triple Codec (H.264 / MPEG4 / MJPEG)
• True day & night with ICR mechanism
• D-WDR (Digital Wide Dynamic Range)
• 3DNR (Digital Noise Reduction)
• DC12V / PoE operation
• 316 grade stainless steel housing
• IP67 ingress protection
• NDAA compliant
Specifications
Camera
Image Sensor Sony 2MP Starvis
Size 1/2.8”
Electronic Shutter Auto (1/15–1/15000), Suppress rolling, Manual
Scanning System Progressive scan
Lens 2.8–12mm auto focus motorised lens
Total Pixels 2000 (H) x 1121 (V), 2.24 Mega Pixels
Effective Pixels 1984 (H) x 1105 (V), 2.19 Mega Pixels
Privacy Area On / Off (6 programmable zone)
Motion Detection 48 Zone, Sensitivity 1~5 Step, On / Off
Day & Night Auto / Day (Colour) / Night (B&W), ICR control
LPR Auto 1/15 – 1/1900, On / Off
Wide Dynamic Range DWDR (1–5 Step) On / Off
3DNR Digital Noise Reduction 1–63 Step
External Video VBS 1.0Vp-p
Colour Adjust Bright / Contrast / Saturation / Sharp / Hue
White Balance Auto / Indoor / Outdoor / Fluorescent
OSD Display Text, Data, Time. Event, On / Off
Image Mirror Normal / Mirror (H) / Flip (V) / Both (HV)
Others
Network Interface Protocol Onvif Profle S compatible
Ingress Protection IP67
Power Supply DC12V +/− 10%
Working Environment Operating : -10°C +50°C, Preservation : -10°C +60°C,
Humidity : 0%-90%
Dimensions 118 × 88.5 mm
Weight 1.3 Kg (Approx.)
Quick Start Guide 2MP Stainless Steel IP IR Dome Camera with 2.8-12mm Auto Focus Lens
3
Dimensions
Cable
Installation
Accessories
88.5mm
118mm
Mounting Screws
Block CD
L-Wrench
Step 1 Step 2 Step 3
Screws
Please tighten up
3pcs of fixed screws
by L-wrench after
closing dome cover.
