Eusso UNC7500-IR Setup guide
MPEG4/MJPEG
Network Camera
Advanced Installation Guide
Version 1.0
- 1 -
PREFACE
Thank you for purchasing the MPEG4/MJPEG Network Camera, a
powerful dual-codec network camera with the 1-way or 2-way audio
function that provides the high-quality image and on-the-spot audio
via the Internet connection. The Infrared LEDs and light sensor
(optional) enable the camera to capture images even in the dark
environment. The camera can be installed as a standalone system
within your application environment easily and quickly, and supports
remote management function so that you can access and control it
using a Web browser on your PC.
This Advanced Installation Guide provides you with the instructions
and illustrations on how to use your camera, which includes:
Chapter 1 Introduction to Your Camera describes the features of
the camera. You will also know the components and
functions of the camera.
Chapter 2 Hardware Installation helps you install the camera
according to your application environment. You can use
this camera at home, at work, at any where you want.
Chapter 3 Accessing the Camera lets you start using your camera
without problem. The camera can be set up easily and
work within your network environment instantly.
Chapter 4 Configuring the Camera guides you through the
configuration of the camera using the web browser on
your PC.
Chapter 5 Appendix provides the specification of the camera and
some useful information for using your camera.
NOTE The illustrations and configuration values in this guide are for
reference only. The actual settings depend on your practical
application of the camera.
- 2 -
Contents
Preface ...............................................................................................1
Chapter 1 Introduction To Your Camera............................................3
1.1 Checking the Package Contents...........................................3
1.2 Getting to Know Your Camera ..............................................4
1.3 Features and Benefits ...........................................................6
1.4 System Requirement.............................................................8
Chapter 2 Hardware Installation ........................................................9
2.1 Installing the Camera Stand..................................................9
2.2 Connecting the Camera to LAN/WLAN...............................10
2.3 Applications of the Camera .................................................11
Chapter 3 Accessing the Camera....................................................12
3.1 Using IP Finder ...................................................................12
3.2 Accessing to the Camera ....................................................13
3.3 Configuring the IP Address of the PC .................................16
Chapter 4 Configuring the Camera..................................................17
4.1 Using the Web Configuration ..............................................17
4.2 Using Smart Wizard ............................................................18
4.3 Basic Setup .........................................................................20
4.4 Network Settings .................................................................22
4.5 Setting up Video & Audio ....................................................26
4.6 Event Server Configuration .................................................30
4.7 Motion Detect ......................................................................33
4.8 Event Config........................................................................34
4.9 Tools ...................................................................................37
4.10 USB.....................................................................................39
4.11 Information ..........................................................................41
Chapter 5 Appendix .........................................................................42
A.1 Specification........................................................................42
A.2 Glossary of Terms...............................................................44
- 3 -
CHAPTER 1
INTRODUCTION TO YOUR
CAMERA
1.1 Checking the Package Contents
Check the items contained in the package carefully. You should have
the following:
5One MPEG4/MJPEG Network Camera.
5One AC Power Adapter.
5One Camera Stand.
5One Ethernet Cable (RJ-45 type).
5One Installation CD-ROM.
5One Quick Installation Guide.
NOTE Once any item contained is damaged or missing, contact the
authorized dealer of your locale.
.2 Getting to Know Your Camera
Front View
NOTE After long pressing the Unmount button for four seconds, the
Power LED starts flashing. When the Power LED resumes the
steady amber light, you can remove the USB device safely.
- 4 -
Rear View
- 5 -
- 6 -
1.3 Features and Benefits
MPEG4/MJPEG Dual-codec Supported
The camera provides you with excellent images by the
MPEG4/MJPEG dual-codec selectable technology, allowing you
to adjust image size and quality, and bit rate according to the
networking environment.
1-way/2-way Audio Capability
The built-in microphone of the camera provides on-the-spot
audio via the Internet, allowing you to monitor the on-site voice.
In addition, you can connect an external speaker to the camera
to speak through the camera (for 2-way audio model only); the
camera is embedded with an echo cancellation processor to
provide a better sound quality.
Day & Night Surveillance Supported (optional)
The six Infrared LEDs around the standard lens assembly
(optional) enable the camera to capture crystal clear images in
the dark environment or at night. When the Light Sensor detects
the environmental light level becomes low, the camera captures
the images in black & white mode using these infrared LEDs.
Supports Multiple Profiles
The camera supports multiple profiles simultaneously, so that
you can separately set up different image settings (such as
image quality and frame rate) for the three video types of the
camera: MPEG4, MJPEG, and 3GPP.
Supports RTSP
The camera supports RTSP (Real Time Streaming Protocol),
which is a technology that allows you to view streaming media
via the network. You can view the real-time video with the Quick
Time player or RealPlayer. To view the real-time streaming
image on your computer, open the Web browser and enter the
RTSP link: rtsp://(IP address of the camera)/mpeg4.
- 7 -
Remote Control Supported
By using a standard Web browser or the bundled Ultra View
software application, the administrator can easily change the
configuration of the camera via Intranet or Internet. In addition,
the camera can be upgraded remotely when a new firmware is
available. The users are also allowed to monitor the image and
take snapshots via the network.
Supports Connection to the External Devices
With the auxiliary Input/Output connectors, you can connect the
camera to a variety of external devices, such as the external
speaker and the USB device.
Multiple Platforms Supported
The camera supports multiple network protocols, including
TCP/IP, SMTP e-mail, HTTP, and other Internet related
protocols. Therefore, you can use the camera in a mixed
operating system environment, such as Windows 2000 and
Windows XP.
Multiple Applications Supported
Through the remote access technology, you can use the
cameras to monitor various objects and places for your own
purposes.
For example, babies at home, patients in the hospital, offices
and banks, and more. The camera can capture both still images
and video clips, so that you can keep the archives and restore
them at any time.
- 8 -
1.4 System Requirement
Networking
LAN: 10Base-T Ethernet or 100Base-TX Fast Ethernet.
Accessing the Camera using Web Browser
Platform: Microsoft® Windows® 98SE/ME/2000/XP
CPU: Intel Pentium III 350MHz or above
RAM: 128MB
Resolution: 800x600 or above
User Interface: Microsoft® Internet Explorer 5.0 or above
Accessing the Camera using Ultra View
Platform: Microsoft® Windows® 98SE/ME/2000/XP.
Hardware Requirement:
1 camera connected: Intel Pentium III 800MHz; 512MB RAM
2 ~ 4 cameras connected: Intel Pentium 4 1.3GHz; 512MB RAM
5 ~ 8 cameras connected: Intel Pentium 4 2.4GHz; 1GB RAM
9 ~ 16 cameras connected: Intel Pentium 4 3.4GHz; 2GB RAM
Resolution: 1024x768 or above
NOTE If you connect multiple cameras to monitor various places
simultaneously, you are recommended to use a computer with
higher performance.
CHAPTER 2
HARDWARE INSTALLATION
2.1 Installing the Camera Stand
The camera comes with a camera stand, which uses a swivel ball
screw head to lock to the camera’s screw hole. When the camera
stand is attached, you can place the camera anywhere by mounting
the camera through the three screw holes located in the base of the
camera stand.
The Camera Stand
- 9 -
