Fieldmann FZR 70375-0 User manual

FZR 70375-0

EN 2

FZR 70375-0

English .................................................................................................................................................................................1–22

Čeština.............................................................................................................................................................................23–38

Slovenčina .....................................................................................................................................................................39–54

Magyarul ........................................................................................................................................................................55–70

Polski ................................................................................................................................................................................. 71–86

CORDLESS LAWN MOWER USER’S MANUAL

(not included) (not included)

EN 4

FZR 70375-0

CORDLESS LAWN MOWER USER’S MANUAL

EN 6

FZR 70375-0

(not included)

Cordless Lawn mower 370mm

INSTRUCTIONS FOR USE

Thank you for purchasing this cordless lawn mower.

Before you start using it, please read this user manual carefully and save it for future use.

TABLE OF CONTENTS

1. GENERAL SAFETY REGULATIONS..........................................................................................................................8

2. SYMBOLS..........................................................................................................................................................................9

3. DESCRIPTION................................................................................................................................................................10

4. BASIC WORK SAFETY................................................................................................................................................10

5. ASSEMBLY.......................................................................................................................................................................14

6. OPERATION...................................................................................................................................................................16

8. TROUBLESHOOTING..................................................................................................................................................18

9. MAINTENANCE............................................................................................................................................................19

10. DISPOSAL..................................................................................................................................................................... 20

11. DECLARATION OF CONFORMITY ......................................................................................................................21

EN 8General safety regulations

FZR 70375-0

1. GENERAL SAFETY REGULATIONS

IMPORTANT SAFETY NOTICE

Unpack the product carefully and do not throw away any of the packaging until you have found all the parts of

the product.

Store the product in a dry place out of reach of children.

Read all the warnings and instructions. Failure to comply with the warnings and instructions may lead to

electric shock, ﬁre and/or serious injuries.

PACKAGING

The product’s packaging prevents damage during transport. This packaging is a resource and can be recycled.

USER MANUAL

Before starting to work with the machine, please read the following safety regulations and instructions for use.

Get familiar with the controls and correct use of the equipment. Keep the user’s manual in a safe place for easy

future reference. Save the original packaging, including the internal packing material, guarantee card and proof

of purchase receipt for at least the time of the guarantee. If you need to transport this power tool, pack it in the

original cardboard box for maximum protection during shipping or transport (e.g. when moving or when you

need to send this power tool to a service centre for repair).

Note: If you hand over the appliance to somebody else, do so together with this user's manual. Make sure

you use the appliance properly by following the instructions in the included User manual. The user’s manual

also contains operating, maintenance, and repair instructions.

The manufacturer assumes no responsibility for accidents or damages arising from

failure to comply with these instructions.

CORDLESS LAWN MOWER USER’S MANUAL

Symbols 9

2. SYMBOLS

Risk of injury due to cutting mechanism!

Never reach into the cutting mechanism.

Use eye protection.

Observe the safety instructions before using the product

for the ﬁrst time.

Use ear protection.

Keep other persons in distance!

WARNING! When operating the device, take care that no

other persons are nearby (safe distance: 5m).

This is particularly valid for children and animals.

Be careful of the sharp blade edges.

Danger of injury!

Beware of hurled-away objects.

Keep bystanders away.

Be careful of the sharp blade edges. The blades continue

to rotate even after the motor is turned off.

Read the Instruction Manual attentively prior to use.

Protect the tool from the damp and never expose it to rain!

Guaranteed sound power level Lwa 93 dB (A)

Before doing any maintenance and repair work

disconnect the circuit breaker from the lawn mower.

EN 10 Description

FZR 70375-0

3. DESCRIPTION

FIG. 1

1. Switch-on lever

2. Handlebar

3. Handlebar, bottom part

4. Collection box

5. Lever for adjusting the cutting height

6. Battery cover

7. Safety ﬂap

FIG. 2

8. Battery pack (not included in the scope of delivery)

9. Display for remaining capacity

10. Push button for capacity display

11. Locking button

12. Control lights

13. Battery charger (not included in the scope of delivery)

SCOPE OF DELIVERY

• Operating manual

• Cordless lawn mower

• Handle

• Collection box

• Mulch wedge

• Circuit breaker

• Bag containing small parts

4. BASIC WORK SAFETY

IMPORTANT ACCUMULATOR SAFETY INSTRUCTIONS

Batteries are a chemical source of electrical energy, containing chemical compounds that can cause injury

to health, property or the environment. Therefore, handle them with caution.

The battery is ready to supply power at any time, even in undesirable circumstances!

ATTENTION! even with a partially charged battery, a short circuit may occur and damage it. In the worst

case, it may cause an explosion or ﬁre. Therefore, always treat batteries in a way that prevents short circuits

(e.g. with paper clips, coins, keys, nails, screws or other small metal objects)!

Even when stored.

Use only batteries recommended by the device manufacturer.

The battery must not be stored or operated near an open ﬂame. It must also not be thrown into the ﬁre.

Do not dispose of old batteries into regular household waste.

Also, never touch the blades until the machine is disconnected from the power source and until the blades

completely stop.

Disconnect the device from the power supply (i.e. remove the battery from the machine):

• If you need to leave the machine without supervision

• If you have to leave the machine unsupervised

• Before every inspection, every cleaning or repairs

• If you hit a foreign body when working with it

• If the machine vibrates excessively.

Read carefully the basics of working safely with the machine and the user's manual.

This machine must not be operated by anyone with limited physical, sensory or mental abilities (including

children). Furthermore, it must not be used by inexperienced people who do not have the technical knowledge to

operate it. These people must be supervised by a competent person or instructed about the basics of work safety.
