Exmark Frontrunner 720,000 & Higher Serial Nos. User manual

FRONTRUNNERTM

AIR-COOLEDMODELS

ForSerialNos.

720,000&Higher

PartNo.4500-218Rev.A

WARNING

CALIFORNIA

Proposition65Warning

Theengineexhaustfromthisproduct

containschemicalsknowntotheStateof

Californiatocausecancer,birthdefects,or

otherreproductiveharm.

Important:Whenthemowerisusedoroperated

onanyCaliforniaforest,brushorgrasscovered

land,aworkingsparkarrestermustbeattached

tothemufer.Ifnot,theoperatorisviolating

statelaw,Section4442PublicResourceCode.To

acquireasparkarresterforyourunit,seeyour

EngineServiceDealer.

ThissparkignitionsystemcomplieswithCanadian

ICES-002Cesystèmed’allumageparètincellede

vèhiculeestconformeàlanormeNMB-002du

Canada

TheenclosedEngineOwner’sManualis

suppliedforinformationregardingTheU.S.

EnvironmentalProtectionAgency(EPA)and

theCaliforniaEmissionControlRegulationof

emissionsystems,maintenanceandwarranty.

KeepthisengineOwner’sManualwithyourunit.

ShouldthisengineOwner’sManualbecome

damagedorillegible,replaceimmediately.

Replacementsmaybeorderedthroughthe

enginemanufacturer.

Exmarkreservestherighttomakechangesor

addimprovementstoitsproductsatanytime

withoutincurringanyobligationtomakesuch

changestoproductsmanufacturedpreviously.

Exmark,oritsdistributorsanddealers,accept

noresponsibilityforvariationswhichmaybe

evidentintheactualspecicationsofitsproducts

andthestatementsanddescriptionscontained

inthispublication.

IndustrialParkBox808

Beatrice,NE683102

Contactusatwww.Exmark.com.

PrintedintheUSA.

AllRightsReserved

Introduction

CONGRATULATIONSonthepurchaseofyour

ExmarkMower.Thisproducthasbeencarefully

designedandmanufacturedtogiveyouamaximum

amountofdependabilityandyearsoftrouble-free

operation.

Thismanualcontainsoperating,maintenance,

adjustment,andsafetyinstructionsforyourExmark

mower.

BEFOREOPERATINGYOURMOWER,

CAREFULLYREADTHISMANUALINITS

ENTIRETY.

Byfollowingtheoperating,maintenance,andsafety

instructions,youwillprolongthelifeofyourmower,

maintainitsmaximumefciency,andpromotesafe

operation.

Ifadditionalinformationisneeded,orshouldyou

requiretrainedmechanicservice,contactyour

authorizedExmarkequipmentdealerordistributor.

AllExmarkequipmentdealersanddistributorsare

keptinformedofthelatestmethodsofservicing

andareequippedtoprovidepromptandefcient

serviceintheeldorattheirservicestations.They

carryamplestockofservicepartsorcansecurethem

promptlyforyoufromthefactory.

AllExmarkpartsarethoroughlytestedandinspected

beforeleavingthefactory,however,attentionis

requiredonyourpartifyouaretoobtainthefullest

measureofsatisfactionandperformance.

Wheneveryouneedservice,genuineExmarkparts,

oradditionalinformation,contactanAuthorized

ServiceDealerorExmarkCustomerServiceandhave

themodelandserialnumbersofyourproductready.

Figure1identiesthelocationofthemodelandserial

numbersontheproduct.Writethenumbersinthe

spaceprovided.

Figure1

1.Modelandserialnumberlocation

ModelNo.

SerialNo.

Contents

Introduction...........................................................3

Safety.....................................................................5

SafetyAlertSymbol.........................................5

SafeOperatingPractices..................................5

SafetyandInstructionalDecals.....................10

Specications.......................................................14

ModelNumbers............................................14

Systems.........................................................14

Dimensions...................................................16

TorqueRequirements....................................17

ProductOverview................................................17

Operation.............................................................18

Controls........................................................18

Pre-Start........................................................19

OperatingInstructions..................................19

Transporting.................................................22

Maintenance.........................................................23

RecommendedMaintenanceSchedule(s)...........23

PeriodicMaintenance.......................................24

CheckEngineOilLevel.................................24

CheckBatteryCharge....................................24

CheckSafetyInterlockSystem.......................25

CheckRolloverProtectionsSystems(Roll

Bar)Pins...................................................26

CheckSeatBelt..............................................26

CheckforLooseHardware............................26

ServiceAirCleaner........................................26

ChangeEngineOil........................................26

CheckHydraulicOilLevel.............................27

CheckTirePressures.....................................27

CheckConditionOfBelts..............................28

LubricateGreaseFittings...............................28

LubricateRearCasterWheelHub(s)...............28

LubricateBrakeHandlePivot........................29

LubricateBrakeRodBushings.......................29

LubricateMotionControlBronze

Bushings...................................................29

LubricateMotionControlShaft.....................29

LubricateSteeringLinkageRodEnds.............29

CheckSparkPlugs.........................................30

ChangeHydraulicSystemFilter.....................30

CheckWheelHubLocknuts..........................30

ThreadLockingAdhesives.............................30

DielectricGrease...........................................31

Adjustments.....................................................31

PumpDriveBeltTension...............................31

PumpDriveBeltReplacement.......................31

ParkBrakeAdjustment..................................31

MotionControlLinkageAdjustment.............32

WeightTransferSpringAdjustment...............33

CasterPivotBearingsPre-Load

Adjustment...............................................34

Cleaning...........................................................34

CleanEngineCoolingSystem........................34

RemoveAccumulatedDebrisfrom

Engine(Briggs&StrattonUnits

Only).........................................................34

RemoveEngineShroudsandCleanCooling

Fins...........................................................35

WasteDisposal..............................................35

Troubleshooting...................................................36

Schematics...........................................................38
