D-Link WIRELESS G DCS-950G User manual

Check Your Package Contents

Thesearetheitemsincludedwithyourpurchase:

If any of the below items are missing, please contact your reseller.

BeforeYouBegin

Youmusthaveatleastthefollowing:

• Windows98/Me/2000/XP

• ACD-ROMdrive

• AnavailableEthernetconnection

DCS-950G

This product can be set up

using Internet Explorer 6.x

or above

SECURICAM Network

802.11g Wireless

Audio Internet Camera

their respective holders. Software and specifications subject to change without notice. DCS-950G.11172004

DCS-950G Wireless Internet Camera

5V 2.5A AC Power Adapter

CAT5 Ethernet Cable

CD-ROM with Manual and Installation Wizard

Using a power supply

with a different voltage

rating will damage this

productandvoidthewarranty.

Mounting Bracket and Stand

Antenna

Hardware Installation

System Requirements

• InternetExplorer6.xorabove

• CPU:800MHzorabove

• MemorySize:128MB (256MBrecommended)

• VGAcardresolution:800x600orabove

Note: If using multiple cameras for viewing/recording, the minimum requirements

are a 2GHz or above CPU with 512MB memory and a 32MB video card.

Connect the Ethernet Cable

ConnectanEthernetcabletotheEthernetconnectorlocated

on the Internet Camera’s back panel and attach it to the

network.

Attach the External Power Supply

Attach the external power supply to the DC power input

connectorlocated on theInternet Camera’s backpanel

(labeled DC 5V 2.5A) and connect it to anAC power outlet.

The LAN LED will light green when there is a good connection to the LAN. The LED will

beginto flashindicating the camerais receivingor sending data.

Power source is confirmed when

the LED Power Indicator on the

InternetCamerais illuminated.

If you connect this camera directly to a PC,

theDCS-950GhasanMDI/Xportthatwillallow

youtouseeitherastraightthrough(included)orcross-

overcable.

Installing the Installation Wizard

InserttheDCS-950G CDintothe

CD-ROMdrive.

Click on Install Software.

Click on Installation Wizard.

Click Next.

Installing the Installation Wizard

(continued)

ClickYes.

Click Next.

Click Finish.

Installing the Installation Wizard

(continued)

Click OK.

Click Next.

Installing the Installation Wizard

(continued)

Click I Agree.

Click Next.

Click Install.

Installing the Installation Wizard

(continued)

Click Next.

Click Finish.

Configuring Your Camera with the

Setup Wizard

Click the Wizard

buttonto begin.

Your camera’s IPAddress will be

displayedhere.

To run the Setup Wizard, click on

Start->Programs->DCS-950 Series

Setup Wizard.

By default, the Admin ID and

Passwordare“admin”(lowercase).

Enter this in both fields. To change

the Admin Password, select the

Change box and enter a New

Password.

TheIP Address,Subnet Mask, and

Gateway of your camera must

correspondwithyournetworksettings

for you to access the camera. If you

are unsure of what these settings

should be, please check with your

networkadministrator.

Click Next.

Configuring Your Camera with the

Setup Wizard (continued)

Ifyouneedtomakeanychanges,click

Back tomodifyyour camerasettings.

Otherwise, click Restart to save and

apply your settings. This may take a

fewminutes.

The Connection Mode depends on

howyourcameraisconnectedtoyour

network.Click Infrastructure for use

with a router or Adhoc for a peer-to-

peer connection. The Network

Name, Wireless Channel, Security

Mode and Authentication MUST

correspondwithyourwirelessnetwork

settings for the camera to work.

Click Next.

ClickRestart.

Enter the Encryption Mode, Key

Format,andEncryptionKeysfor you

wireless network. Click Next.

Configuring Your Camera with the

Setup Wizard (continued)

Click Link.

WaituntiltheLinkLEDonthecamera

begins to flash. Click Link to launch

your Web browser and view your

images.
