Blue-White Sonic-Pro T-Track User manual

T-Track Installation Guide - V-Mount method

Sonic-Pro

Parts Locator

Locate the T-Track assembly

package and your Transducer

set. The package should

contain the following items:

1) Retainer slide nut (2)

2) Positioning set screw (2)

3) Tensioning thumb screw (2)

4) T-Track cover

5) V-Block (2)

6) V-Block screws (8)

7) Pipe clamp (2)

8) Pipe clamp screws (2)

9) Pipe clamp wrench (1)

10) Installation Guide (1)

Note the serial number

location on the transducer.

Determine Separation

Distance

If not already done, configure

the meter for the pipe

application. The meter’s

display screen will display the

transducer separation

distance.

Install Retainer Slide

Nut Assembly

Install the Positioning Set

Screws (2) and the

Tensioning Thumb Screws

(3) into the Retainer Slide

Nuts (1).

There is a captured nut

located inside transducer

housing. While holding the

captured nut with a small

screwdriver, thread the thumb

screw into the captured nut.

Do not over-tighten.

          

                     

                     ! "

     $   %          & '

( ) * + * * ( ,

  -   . / 0 / 1  $   2

  4 5    0       6 7 8

( )

8 8

)

8 8

%     9 : ; < 5 -    -      4  =   

> ? @ A

B C D E F G H I J E C K L F M M C

Install and Position

the Transducers in

the T-Track

Insert the first transducer’s

Retainer Slide Nut (1)

through the square opening in

the underside of the T-Track

Cover (4). Align the grooves

in the Slide Nut with the slot

in the T-Track Cover. Slide

the transducer assembly over

to the zero position and lock

in place with the Positioning

Set Screw (2).

Insert the second transducer’s

Retainer Slide Nut (1)

through the square opening in

the underside of the T-Track

Cover (4). Align the grooves

in the Slide Nut with the slot

in the T-Track Cover. Slide

the transducer assembly over

to the correct separation

distance position (see step 2)

and lock in place with the

Positioning Set Screw (2).

Install the V-Blocks

Position the transducer cable

through the V-Block (5).

Install the V-Block into the T-

Track Cover (4).

Install the 4 V-Block Screws

(6).

Repeat this process for the

second V-Block.

Sonic-Pro

N O P Q R S T U Q V W X Y Z [ \ ] Y ] ^

_ ] ` ^ \ a a \ ^ _ b ] ` c d Y e b [ [ Y ] f Y f

g b Z [ Y ^ \ a h _ h Y ` c

V d S i T j P k Q d

N l V V l m n o Q p

DOW 111 Silicone Grease

Adjust the Tensioning

Thumb Screws (2) counter-

clockwise so that the

transducers are fully inside the

T-Track Cover (4) as shown.

Adjust the Tensioning

Thumb Screws

Install the

Pipe Clamps

Place the first Pipe Clamp (7)

around the pipe being careful

to position the screw where it

will be easy to tighten. Insert

the Clamp Screw (8) into the

clamp. Use the Clamp

Wrench (9) to tighten the

clamp loosely onto the pipe.

Repeat for the second pipe

clamp.

Sonic-Pro

An acoustic coupling material

must be placed between the

transducer and the pipe

surface at the point where the

sound waves enter the pipe.

Place a drop of DOW 111

grease or the permanent Blue

Gasket pad on the oval shape

waveguide.

Apply Acoustic

Coupling Material

t u v w x y z { | x } ~ y v 

              

ProSeries

               

               



 ¡ ¢ ¢ £ ¤ ¥ ¦ § ¨ ¥ ¥ © ª ¦ « ¨ ¬  ¤ § ® ¦ § ¯ ® ° § £ ¨ ± ² ³ ¬ ´ µ ¶ · ¸ ¹ ¶ º » µ

¼ ½ ¾ ¿ À Á Â Ã ¹ Ä Å ¶ ¡ Ä Å  · ¶ Æ Ç È Á Â Ã ¹ Ä Å ¶ ¹ Ä ¶ ¹ ¶ ·

É Ê Ë Ì Í Á ¥ ± Î ¨ ¥ Ï Ð Î ¤ ¨ Ä Ñ ³ ¦ ® ¨ Ò ² ° Ó ¾ Ô ® ¨ ² ³ ¥ ¤ Õ Õ ° ª ® Ï Ð Î ¤ ¨ Ä Ñ ³ ¦ ® ¨ Ò ² ° Ó Ö × Ø ÁÑ Ñ Ñ Ò Ð Î ¤ ¨ Ä Ñ ³ ¦ ® ¨ Ò ² ° Ó

Install the T-Track

on the Pipe

Position the T-Track on the

side of the pipe - do not install

on the top or bottom of the

pipe.

Insert the first Pipe Clamp

(7) into the slot in the V-

Block (5) and tighten. Ensure

the transducers are fully

adjusted up into the T-Track

Cover (4).

Tighten both clamps securely.

Do not over-tighten.

Insert the second Pipe

Clamp (7) into the slot in the

V-Block (5) on the other side

of the T-Track and tighten.

Tension the

Transducers against

the Pipe Surface

Tighten the Tensioning

Thumb Screws (3) by

turning clockwise.

Confirm that the Retainer

Slide Nuts (1) are positioned

so that the distance between

the slide nuts is equal to the

correct separation distance

per step 2.

Ü Ý

Þ ß à á â á á ã ä å æ ç è á ä é à ä å ä ê ë

ìä í ß æ ä ê ë æ ç è á ä é à ä å ä ê ë

î ï ð ñ ò ï ó ô õ ö
