Table of Contents
MicroPolar (++) LB 566 5
Table of Contents
Page
Safety Summary 7Chapter 1.
1.1 Symbols and Warnings 7
1.2 General Information 8
1.3 General Safety Instructions 9
General Information 11Chapter 2.
2.1 Use and Function 11
2.2 Frequency License 12
2.3 Intended Use 14
2.4 Explanation of Terms 15
System Description 17Chapter 3.
3.1 Principle of Measurement 17
3.2 Calculation of Measured Values 18
3.3 Temperature Compensation 19
3.4 Throughput Calculation and Output 20
3.5 Mechanical Components 21
3.5.1 Evaluation Units 23
3.5.2 FlowCell 25
3.5.4 Container Probe 27
3.5.5 High-frequency Cable 30
3.6 Assembly on a Pipeline 32
3.7 Assembly on a Container 33
Getting Started 35Chapter 4.
4.1 Transport 35
4.2 Commissioning the FlowCell 36
4.2.1 Installing the FlowCell 36
4.2.2 Installing the Evaluation Unit 38
4.2.3 Connecting the HF Cable 39
4.3 Commissioning the Container Probe 41
4.3.1 Installing the Container Probe 41
4.3.2 Setting Up the Evaluation Unit 43
4.3.3 Connecting the HF Cable 43
4.5 Connecting the Evaluation Unit 45
4.5.1 Pin Configuration of the Connector Strip 46
4.5.2 Digital Outputs, Relay 48
Service instructions 51Chapter 5.
5.1 General Information 51
5.2 Wear Parts 52
5.3 Instrument Cleaning 53
5.4 Battery 53
5.5 Fuse Replacement 54
