ACME Building wash User manual

CONTENTS

1. Safety Instruction........................................................................................... 2

2. Techical Specfications .................................................................................... 4

3. How To Set The Fixture .................................................................................. 5

3.1 Control Panel ........................................................................................... 5

3.2 Main Functions ........................................................................................ 6

4. How To Control The Unit.............................................................................. 12

4.1 Primary/Secondary Built In Preprogrammed Function........................... 12

4.2 DMX Controller ...................................................................................... 12

4.3 DMX512 Configuration........................................................................... 13

5. DMX512 Connections .................................................................................. 14

6. Troubleshooting........................................................................................... 15

7. Fixture Cleaning........................................................................................... 15

1. Safety Instruction

WARNING

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure

that they also receive this instruction manual.

Important:

Damages caused by the disregard of this user manual are not subject to warranty. The dealer

will not accept liability for any resulting defects or problems.

Unpack and check carefully that there is no transportation damage before using the unit.

This product is suitable for indoor use and wet locations. Do not immerse in water.

DO install and operate by qualified operator.

DO NOT allow children to operate the fixture.

Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head

only.

The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces.

Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.

Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃.

DO NOT connect the device to any dimmer pack.

During initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective, and it will decrease gradually within 15 minutes.

Make sure there are no flammable materials close to the unit while operating to avoid fire

hazard.

Examine the power wires carefully; replace them immediately if there is any damage.

Please read the instruction carefully which includes important information about

the installation, usage and maintenance.

Unit’s surface temperature may reach up to 60℃. DO NOT touch the housing bare-handed

during its operation.

Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut

off the mains power immediately.

DO NOT operate in dirty or dusty environment, do clean fixtures regularly.

DO NOT touch any wire during operation as there might be a hazard of electric shock.

Avoid power wires together twist other cables.

In the event of serious operating problem, stop using the unit immediately.

Never turn on and off the unit time after time.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

DO NOT open the unit as there are no user serviceable parts inside.

Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to

damage or malfunction. Please contact the nearest authorized technical assistance center if

needed.

Disconnect the mains power if the fixture is has not been used for a long time.

DO use the original packing materials before transporting it again.

DO NOT look directly at the light while the LED is on.

DO NOT start on the unit without LED enclosure or when housing is damaged.

Installation:

The fixture should be mounted via its Omega Quick Release Clamp bracket. Always ensure that the

unit is firmly fixed to avoid vibration and slipping while operating and make sure that the structure

to which you are attaching the unit is secure and is able to support a weight of 10 times of the

fixtures weight. Always use a safety cable that can hold 12 times of the weight of the fixture when

installing.

The equipment must be installed by professionals. It must be installed in a place where is out of

the reach of people and no one can pass by or under it.

2. Techical Specfications

Features:

An ideal replacement for the outdoor metal halide fixtures - VPad Smart and VPad White

produces powerful and consistent light output, makes its efficiency and cost-effective

Compact design with great heat ventilation in a rugged die-cast aluminum housing to ensure

reliable performance under harsh environment

16 pre-programmed movement patterns and 4/5/7 DMX channels

Easy installation with swivel tilt mechanism for quick positioning

Easy cabling with a specially designed power and DMX compartment

With various beam angles, ideal for multiple applications – for the illumination of buildings,

bridges, stadiums, landscapes, theme parks, and more

Specifications:

Power Voltage:

AC 100~240V, 50/60Hz

Power Consumption:

112W

Light Source:

12x10W CREE MCE LEDs

Beam Angle:

10°, 20° or 30°

IP Rating:

IP66

Dimension:

454x116x330mm / 18”x5”x13”in

Weight:

11.2kgs / 24.7lbs

3. How To Set The Fixture

3.1 Control Panel

1. Display:

To show the various menus and the selected functions

Button:

2. MENU To select the programming functions

3. ENTER To confirm the selected functions

4. DOWN To go forward in the selected functions

5. UP To go backward in the selected functions

6. POWER IN

Water proof connectors for power input

7. POWER OUT:

Water proof connectors for power output

8. DMX IN:

Water proof connectors for DMX512 operation, use 3-pin XLR cable to link the units together

9. DMX OUT:

Water proof connectors for DMX512 operation, use 3-pin XLR cable to link the next units

3.2 Main Functions

To select any functions, press the MENU button until the required one is showing on the display.

Select the function by the ENTER button and the display will blink. Use the UP/DOWN button to

change the mode. Once the required mode has been selected, press the ENTER button to setup or

it will automatically return to the main functions without any change after idling 7 seconds. Back

to the functions without any change press the MENU button. The main functions are shown

below:

Once you set to , after running in show mode for 5 minutes

without any change or restarting the unit, the key board become locked.

Press the ENTER button to enable the menu, the display will show ,

press the UP/DOWN button until it shows , then press the ENTER to

unlock.

DMX Address Setting

Select the , press the ENTER button and the display will blink. Use the UP/DOWN button to

adjust the address between and . Once the address has been selected,

press the ENTER button to setup or automatically exit menu mode without any change after 7

seconds. Back to the previous functions without any change press the MENU button.

Channel Mode

Select the , press the ENTER button and the display will blink. Use the UP/DOWN button

to select the (4 Channels: Red, Green, Blue, White), (5 Channels: Red,

Green, Blue, White, Dimmer) or (7 Channels: Red, Green, Blue, White, Color, Dimmer,

Strobe). Once selected, press the ENTER button to store or automatically exit menu mode without

any change after 7 seconds. To go back to the functions without any change press the MENU

button.

Show Mode

Select the , press the ENTER button and the display will blink. Use the UP/DOWN button

to select the (Show 1), (Show 2)…. (Show 16). Once selected, press

the ENTER button to setup. Press the ENTER button，will blink on the display, use the

UP/DOWN button to adjust the fade time (0~255), press the ENTER button to store and

will blink on the display, use the UP/DOWN button to adjust the wait time (0~255), press the

ENTER button to store or automatically return to the main functions without any change after 7

seconds. To go back to the previous functions without any change press the MENU button.

DMX State

Select the , press the ENTER button and the display will blink. Use the UP/DOWN

button to select the (Primary Secondary), (Blackout), (Last State)

or (Manual Mode). Once selected, press the ENTER button to setup or automatically

exit menu mode without any change after 7 seconds. To go back to the functions without any

change press the MENU button.

Manual Mode

Select the , press the ENTER button and the display will blink. Use the UP/DOWN button

to select (Red), (Green), (Blue), (White),

(Color), (Dimmer) or (Strobe). Once selected, press the ENTER button to

confirm, and use the UP/DOWN button to adjust the value between and , then

press the ENTER button to store, or automatically exit menu mode without any change after 7

seconds. To go back to the functions without any change press the MENU button.

White Balance

Select the , press the ENTER button and the display will blink. Use the UP/DOWN

button to select (Red), (Green), (Blue). Once selected, press the

ENTER button to confirm, and use the UP/DOWN button to adjust the value between

and , then press the ENTER button to store, or automatically return to the main functions

without any change after 7 seconds. To go back to the previous functions without any change

press the MENU button.

Photo Cell

Select the , press the ENTER button and the display will blink. Use the UP/DOWN button

to select (Be controlled by sunlight) or (Not be controlled by sunlight). Once

select, press the ENTER button to setup or automatically return to the main functions without any

change after 7 seconds. Back to the previous functions press the MENU button.
