ACME Whack User manual

CONTENTS

1. Safety Instructions ......................................................................................... 2

2. Technical Specifications ................................................................................. 5

3 Control Panel .................................................................................................. 7

4. Color/Gobo and Lamp.................................................................................... 8

4.1 Color/Gobo .............................................................................................. 8

4.2 Light Source ............................................................................................. 8

4.3 Change The Lamp..................................................................................... 9

5. How To Set The Unit..................................................................................... 11

5.1 Main Function........................................................................................ 11

5.2 Home Position Adjustment .................................................................... 15

6. Control By Universal DMX Controller ........................................................... 18

6.1 DMX512 Connection.............................................................................. 18

6.2 Address Setting ...................................................................................... 19

6.3 DMX512 Configuration........................................................................... 19

7. Troubleshooting........................................................................................... 32

8. Fixture Cleaning ........................................................................................... 33

1. Safety Instructions

WARNING

Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that

they also receive this instruction manual.

Important:

Damages caused by the disregard of this user manual are not subject to warranty. The dealer will

not accept liability for any resulting defects or problems.

Unpack and check carefully that there is no transportation damage before using the unit.

This product is for indoor use only. Use only in a dry location.

DO install and operate by qualified operator.

DO NOT allow children to operate the fixture.

Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.

The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent

surfaces.

Be sure that no ventilation slots are blocked, otherwise the unit will be overheated.

Before operating, ensure that the voltage and frequency of power supply match the power

requirements of the unit.

It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.

Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃.

DO NOT connect the device to any dimmer pack.

During initial start-up some smoke or smell may arise. This is a normal process and does not

necessarily mean that the device is defective, and it will decrease gradually within 15 minutes.

Make sure there are no flammable materials close to the unit while operating to avoid fire

hazard.

Examine the power wires carefully; replace them immediately if there is any damage.

Avoid any inflammable liquids, water or metal objects entering the unit. Once it happens, cut

off the mains power immediately.

DO NOT operate in dirty or dusty environment, do clean fixtures regularly.

Please read the instruction carefully which includes important information about

the installation, usage and maintenance.

DO NOT touch any wire during operation as there might be a hazard of electric shock.

Avoid power wires together twist other cables.

The minimum distance between light output and the illuminated surface must be more than 12

meters.

Disconnect mains power before fuse/lamp replacement or servicing.

Replace fuse/lamp only with the same type.

In the event of serious operating problem, stop using the unit immediately.

Never turn on and off the unit time after time.

The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.

DO NOT open the unit as there are no user serviceable parts inside.

Never try to repair the unit by yourself. Repairs carried out by unskilled people can lead to

damage or malfunction. Please contact the nearest authorized technical assistance center if

needed.

Disconnect the mains power if the fixture is has not been used for a long time.

DO use the original packing materials before transporting it again.

Hot lamp explosion hazard. DO NOT open the unit within 15 minutes after switching off.

DO replace the bulb once it is damaged, deformed or life-expired.

DO NOT look directly at the light while the bulb is on.

Never touch bulb with bare fingers, as it is very hot after using.

DO NOT start on the unit without bulb enclosure or when housing is damaged.

Installation:

1. Bolt each clamp (1) to the Omega holder with screw and lock nut through the hole in the holder.

2. Fasten the omega holders (2) on the bottom of the base by inserting quick-lock fasteners (3) into

the holes of the base and tighten fully clockwise.

3. Hang the fixture to the support (4) through clamp and fasten the screws (5). Fasten the safety

cable (6) through the bottom of the base and over the support.

Attention:

The fixture should be mounted via its Omega Quick Release Clamp bracket. Always ensure that the

unit is firmly fixed to avoid vibration and slipping while operating and make sure that the structure

to which you are attaching the unit is secure and is able to support a weight of 10 times of the

fixtures weight. Always use a safety cable that can hold 12 times of the weight of the fixture when

installing.

The equipment must be installed by professionals. It must be installed in a place where is out of the

reach of people and no one can pass by or under it.

2. Technical Specifications

Power Voltage:

AC 100~240V, 50/60Hz

Power Consumption:

270W

Light Source:

PHILIPS MSD Platinum 5R

Color Temperature:

8000K

Beam Angle:

1°/3.8°

Movement:

Pan: 540°

Tilt: 250°

Pan/Tilt Resolution: 16 bit

Dimmer/Shutter:

Smooth dimming from 0-100%; outstanding strobe effect with variable speed

Color Wheel:

1 x color wheel with 14 fixed colors plus white with rainbow effect

Gobo Wheel:

1 x static gobo wheel with 17 gobos plus open

Control:

DMX Channel: 16/15/19/20 Channels

Control Mode: DMX512

Firmware Upgrade: Update via DMX link

Construction:

Display: LED display

Data In/Out: 3-pin XLR

Power In/Out: Power Connector in/out

Protection rating: IP20

Features:

Motorized focus

Outstanding color macro effect

8 facet Prism, rotation in both directions

Independent frost effect

Dimension/Weight:

394x325x500mm, 18kgs

15.5"x12.8"x19.7"in, 39.7lbs

Photometrics Diagram:

3 Control Panel

Wire Version:

Powercon Version:

1. Microphone: To receive music for sound active

2. LED:

POWER

Power On

DMX

DMX input present

3. Button:

To select the programming functions

To go backward in the selected functions

DOWN

To go forward in the selected functions

ENTER

To confirm the selected functions

4. Display: Used to show the various menus and the selected function

5. DMX IN: DMX 512 link, use 3-pin XLR cable to link the unit and DMX controller

6. DMX OUT: DMX 512 operation, use 3-pin XLR cable to link the next units

7. POWER SWITCH(WIRE VERSION): Turn On/Off the power

8. FUSE(T 6.3A): Protect the unit from damage of over voltage or short circuit

9. POWER(WIRE VERSION): Used to connect to supply power

10. POWER IN(POWERCON VERSION): Used to connect to supply power

11. POWER OUT(POWERCON VERSION): Used to connect to the next fixture

4. Color/Gobo and Lamp

4.1 Color/Gobo

DANGER!

Install the color wheel/gobo wheels with the device switched off only.

Unplug from mains before changing the color wheel/gobo wheels!

4.2 Light Source

PHILIPS MSD Platinum 5R

Because of its high internal pressure, there might be a risk that the Discharge lamp

would explode during operation. The lamp emits intense UV radiation which is harmful

to the eyes and skin. The high luminance of the arc can cause severe damage to the

retina if you take a close look at the lamp.

To protect the lamp, always turn off the lamp first (via control panel or DMX controller)

and let the unit run at least five minutes to cool down before switching off the mains

supply. Never handle the lamp or luminary when it is hot.

Do not touch the bulb with bare hands. If this happens, clean the lamp with denatured

alcohol and wipe it with a lint free cloth before installation.

The lamp generates UV radiation. Never operate the lamp without appropriate shielding.

When lighting up, the lamp operates at high pressure and there is a slight risk of arc tube

rupture. The risk increases with age, temperature and improper handling of the lamp. Do not

use the lamp longer than its lifespan.

Make sure the lamp is located in the center of the reflector for the best projection.

4.3 Change The Lamp

Attention: The entire light path and lens of the luminaire must be thoroughly cleaned before

changing the bulb.

Do not use this lamp more than 2000 hours, using the lamp any longer than its set life could

seriously damage your unit. Periodically checking the lamp running time, when the lamp reaches

the 2000 hour mark, or close to it, we strongly suggest you switch the lamp out. Clear the lamp time

after you have replaced the lamp.

To replace the lamp:

1. Remove the fixture head covers using a screwdriver (Figure 1).

Figure 1

2. Position the head as Figure 2 and remove the lamp cooling fan at the rear of the head.

Figure 2
