YOKOHAMA HITES User manual
It indicates tire air pressure and air temperature
inside tire detected by sensor unit mounted on each
tire and tire position. Detected data are compared
with two preset management values, and when they
are out of ranges of management values, the lamp
at the tire position blinks, and the conditions are
shown by figures and change of background color.
Detected data can be stored in logger. Data in the
logger can be read into PC.
5Explanation of functions of HiTES Display
5.1. Functions of Display
5.2. Concerning language selection
言語／ Language
日本語 English
5.3. Explanation of parts of Display
Air pressure display screen
TOP
Front
Tire position
Comment indication cell
Vehicle selection button
* Simulated screen image
Initial screen
Time and date
Repeaterisconnectedornot
Logger is connected or not
Trailer is connected or not
8
7
Setting when new sensor is mounted and informa-
tion updating when tire rotation is implemented, for
example, can be carried out.
Touch panel is adopted for the indicator. Various
operations can be performed by pushing buttons
on the screen shown in each display.
*Be sure to operate and confirm indicator while
vehicle is parked.
Language selection screen is displayed only at
initial start. Select either Japanese or English.
* Language can be selected from setting menu.
LED Indicator
Occurrence of tire abnor-
mality is informed by means
of color
Tire air pressure (kPa)
Background color
(state of display position)
Blue: Normal
Yellow or Red:
Air pressure is insufficient.
White: No received data
Airtemperatureinside tire(°C)
Background color
(state of display position)
Blue: Normal
Yellow or Red:
High temperature
White: No received data
Position selection button
Position to be displayed is
selected using △and▽.
Switching of initial screen
Position indication during display: Position blinks during display. (Background color represents state.)
Function of automatic indication of all positions: All positions are sequentially indicated when wheel arrange-
ment diagram is touched.
Indication of tire air
pressure
Buttonforswitchingdisplay
* Simulated screen image
Information indication portion
Information concerning
･State of occurrence of red and
yellow,
･State of idle capacity of logger,
･Easy help for error, etc.
is indicated.
Button for switching to setting
menuscreen
(Longpushuntil screenchanges.)
When separation of trailer is
forgotten, it is changed to
[Trailer selection] button.
