Whirlpool AZA9791 User manual

www.devicemanuals.eu/

CONTENTS

SAFE INSTALLATION AND USE Page 3

INTENDED USE Page 7

INSTALLATION Page 8

DESCRIPTION OF THE DRYER Page 9

CLEANING AND MAINTENANCE Page 10

CLEANING THE DOOR FILTER Page 10

CLEANING THE BOTTOM FILTER Page 11

DRAINAGE SYSTEM Page 12

DOOR REVERSIBILITY Page 14

ENERGY SAVING/AUTOMATIC SWITCH-OFF FUNCTION Page 15

TROUBLESHOOTING GUIDE/AFTER-SALES SERVICE Page 16

DISPOSAL Page 18

INDICATORS AND OPTIONS

PROGRAMME CHART

RUNNING A PROGRAMME

TROUBLESHOOTING / MAINTENANCE

CONSUMPTION DATA

INSTRUCTIONS FOR USE

QUICK REFERENCE GUIDE

READ INSTRUCTIONS FOR USE!

www.devicemanuals.eu/

To avoid injuries, damages on the dryer and its surrounding area or even a fire,

you must observe the instructions below.

Packaging, damages, handling

• Keep the packaging foil away from children; danger of suffocation.

• Do not operate the dryer if it has been damaged during transport or later.

Inform the After-Sales Service.

• If the dryer was exposed to the cold before delivery, keep it at room

temperature for a few hours before installation. Cold temperatures can affect

the proper functioning of electronic parts.

• Never lift your dryer by holding it on extruding parts (e.g. door) or on the

worktop; parts might loosen or break and persons might get injured.

• For lifting the dryer, at least 2 persons are necessary, to avoid accidents.

• The dryer must be carried in an upright position.

Location and surrounding area

•Thedryerisappropriate for indoor use only.

• Do not install the dryer in rooms with poor ventilation. If you want to install it in a

small storage room, toilet, bathroom or similar, assure a good ventilation (open

door, ventilation grid or slot larger than 500 cm²).

• Do not install the dryer where it will be exposed to extreme temperatures below

5°C or over 35°C, to avoid malfunction, damages to dryer parts or fire.

• The dryer must be placed with the back towards a wall, to avoid injuries by

touching the rear panel, which can become hot during the drying process.

• Do not store flammable fluids near the dryer, to prevent fires.

• Do not install the dryer behind a lockable door, a sliding door or a door with a

hinge on the opposite side to the tumble dryer's door, in a way that a full opening

of the dryer door is restricted.

• Do not install the dryer on a deep pile carpet, to avoid that the ventilation

openings are clogged.

• Do not store flammable fluids near the dryer, to prevent fires.

• If you must install the dryer next to a gas or coal stove, you must fix a heat

insulating plate (85 x 57 cm) between dryer and stove; the plate's side pointing

towards the oven must be covered with aluminium foil, to protect the dryer

against high temperatures.

• Built-in installation of the tumble dryer is not permitted.

SAFE INSTALLATION AND USE

www.devicemanuals.eu/

• If you want to install the dryer under a worktop, make sure that a ventilation grid

(minimum 45 x 8 cm) is inserted in the rear part of the worktop where the dryer

will be installed, to assure sufficient ventilation.

Stacking on a washing machine

• If you want to place the dryer on top of your washing

machine, first contact our After-Sales Service or your specialist

dealer to verify if this is possible. Stacking of a dryer is only

admitted if the dryer and your washing machine are

compatible, and if an appropriate stacking kit is available

through our After-Sales Service or your specialist dealer by

which the dryer can be safely fixed on the washing machine.

Electrical connection

• The dryer must only be connected to an earthed socket

which is in compliance with the current safety regulations

and which is appropriate for the values regarding

voltage, power consumption and protection

requirements as they are indicated on the rating

plate on the rear of the dryer.

• Do not use extension leads, extension leads with multiple sockets, or

adapters; they might cause a fire by overheating. If you need a longer mains

cable, contact our After-Sales Service.

• After installation, access to the mains plug or to disconnection from mains

supply by a double-pole switch must be ensured at all times, to make sure

the dryer can be separated immediately from the mains supply.

• For unplugging the dryer, do not pull the mains cable, to avoid damaging it.

Never touch the mains plug with wet hands, to avoid an electrical shock.

www.devicemanuals.eu/

• Do not trap the mains cable between the dryer and the wall, to prevent

damages on the cable.

• Do not operate the dryer if the mains cable or plug shows damages.

• Before doing any maintenance on the dryer, disconnect it from the mains

supply, to avoid dangers.

• If necessary, the mains cable can be replaced; the replacement must only

be done by our After-Sales Service or by a qualified technician, to avoid

dangers.

• When using a residual current circuit breaker (RCCB), only use a model

marked with

Children and handicapped people

• Children must not play with the dryer.

• Children younger than 3 years should be kept away from the dryer, unless

they are continuously supervised.

• The dryer can be operated by children from the age of 8 years up, as well as

by people with reduced physical, sensory or mental capabilities or lack of

experience and knowledge, provided they are supervised or instructed

regarding the safe use of the dryer and they understand the dangers

resulting from the use.

• Care and maintenance works on the dryer must not be done by children

without being supervised.

• Ensure that children and small animals cannot get into the drum.

Safe operation/minimizing the risk of a fire

• Do not tumble dry laundry containing oil, to prevent a fire. Oil-bearing items

can ignite spontaneously, especially when they are exposed to heat sources

as in a tumble dryer. The items would become warm, causing an oxidation

reaction in the oil. Oxidation creates heat; if the heat cannot escape, the item

can become hot enough to catch fire.

• Do not tumble dry unwashed laundry in the tumble dryer.

• Laundry items that have been soiled with substances such as cooking oil,

acetone, alcohol, benzene, petroleum, kerosene, stain removers, turpentine,

wax or wax removers must be washed in hot water, with an extra amount of

detergent, before being dried in the tumble dryer.

• Items such as foam rubber (latex foam), shower caps, waterproof textiles,

rubber backed articles and clothes or pillows fitted with foam rubber pads

must not be dried in the tumble dryer.

• Remove all objects from pockets such as lighters and matches.

www.devicemanuals.eu/

• Do not use flammable cleaning agents.

• Do not use the tumble dryer if chemicals have been used for cleaning.

• Fabric softeners or similar products must be used as specified by the fabric

softener instructions.

• Never stop the tumble dryer before the end of the drying cycle, unless all

items are quickly removed and spread out so that the heat is dissipated.

The final phase of a drying cycle always occurs without heat (cool down

phase), to ensure that the laundry items are left at a temperature which

does not cause damage to the laundry.

• Clean the door filter after each drying cycle (see paragraph CLEANING THE

DOOR FILTER).

• Keep the surrounding area of the dryer free from lint.

• Always set the programme knob to the Off-position "O" after programme

end, to reduce the risk that the dryer might be started accidentally.

• Drying clothes with buckles or using dryer balls may impact the surface of

the drum.

Maintenance

• Before doing any maintenance, switch off the dryer and disconnect it from

the mains supply.

• Never use flammable fluids for cleaning the dryer.

• Do not use detergents containing solvents, scouring powder, glass or

general purpose cleaners. They might harm the surfaces.

Repairs and spare parts

• Repairs must only be done by our After-Sales service. Improper repairing can

lead to unpredictable dangers for the user and to damages on the dryer and

will moreover cause the loss of the guarantee.

• For repairs, only original spare parts are admitted, to assure proper

functioning of the dryer.

• For dryer models with drum light: Replacing the light bulb must only be

carried out by our After-Sales Service.

www.devicemanuals.eu/

This appliance is destined to dry laundry which is marked to be appropriate for

being treated in a dryer, in quantities which are usual for private households.

• Observe the instructions given in these Instructions for Use and in the Quick

Reference Guide when using the dryer.

• Keep these Instructions for Use and the Quick Reference Guide; if you pass

on the dryer to another person, also give him/her Instructions for Use and

Quick Reference Guide.

INTENDED USE

Heat Pump Technology

This dryer with modern heat pump technology provides the same results, but only

consumes a fraction of the energy used by traditional condenser and air-vented dryers.

In order to treat your laundry as gentle as possible and to reach a low energy

consumption, the laundry is dried with low temperature; therefore it may feel cooler than

expected during and after the drying process.

For heat pump dryers, the initial heating phase is longer than it is for traditional dryers.

For that reason, no or only little heat can be perceived inside the dryer during the first

10 to 20 minutes.

If possible, do not open the dryer door during the drying process to check dryness of your

laundry. Otherwise heat will escape from the drum, and the programme time will be

prolonged unnecessarily.

www.devicemanuals.eu/

For installing your dryer, you must observe the instructions of chapter SAFE INSTALLATION AND USE.

• Carefully level the dryer by adjusting the four feet; check the correct leveling with a level.

• Before running the first drying cycle, ensure that the water container is fully pushed inside and that

the bottom filter is correctly positioned (see chapter DESCRIPTION OF THE DRYER).

• Also make sure that all hoses of the drainage system are connected as shown in the picture below.

If possible you can drain the water directly into the domestic plumbing system. This will avoid having to

empty the water container at the end of each drying cycle since the condensation water can be directly

drained away (see chapter DRAINAGE SYSTEM).

Electrical connection for Great Britain/Ireland

1) For Great Britain only

Warning – this appliance must be earthed

Fuse replacement

If the mains lead of this appliance is fitted with a BS 1 363A 13 amp

fused plug, to change a fuse in this type of plug use an A.S.T.A.

approved fuse to BS 1 362 type and proceed as follows:

1. Remove the fuse cover (A) and fuse (B).

2. Fit replacement 13A fuse into fuse cover.

3. Reinstall both into plug.

Important:

The fuse cover must be reinstalled when changing a fuse and if the

fuse cover is lost, plug must not be used until a correct replacement

is installed.

Correct replacements are identified by the color insert or the color embossed in words on the base of

the plug. Replacement fuse covers are available from your local electrical store.

INSTALLATION

www.devicemanuals.eu/

2) For the Republic of Ireland only

The information given in respect of Great Britain will frequently apply, but a third type of plug and

socket is also used, the 2-pin, side earth type.

3) Socket outlet / plug (valid for both countries)

If the fitted plug is not suitable for your socket outlet, please contact Whirlpool Service for further

instruction.

Please do not attempt to change plug yourself. This procedure needs to be carried out by a qualified

Whirlpool technician in compliance with the manufactures instructions and current standard safety

regulations.

A. Work top

B. Water container

C. Contact pin

D. Door:

To open the door: pull the handle.

To close the door: push gently until

closed.

E. Door filter

F. Bottom filter

G. Bottom filter flap

DESCRIPTION OF THE DRYER

www.devicemanuals.eu/

AFTER EACH DRYING CYCLE

• Switch off the dryer before cleaning or carrying out maintenance.

• Empty the water container at the end of each drying cycle.

• Clean the door filter at the end of every drying cycle.

Dryer exterior and control panel:

• Use a soft, damp cloth. Dry with a soft cloth.

• Do not use detergents containing solvents, scouring powder, glass or general purpose cleaners;

they may harm the surfaces.

Door seal, door, filter area:

• Use a damp cloth to wipe away lint.

• Since lint can go through the filter, occasionally clean the complete filter area (including below the

filter) with a brush, a damp cloth or a vacuum cleaner.

CLEANING THE DOOR FILTER

Depending on the model of your dryer, the door filter

can have different shapes.

A. Remove the complete laundry out of the dryer

before removing the lint filter.

B. Take the D filter out of the dryer and carefully

open the filter.

C. Carefully remove the complete lint from the lint

screen.

D. If the mesh is clogged and cannot be cleaned by

hand, run the filter under water and scrub with a

soft brush.

When the door filter is clean, put it back intothe dryer.

Assure that it is positioned correctly before starting

the next drying cycle.

IMPORTANT:

• Be aware that the lint filter is always correctly positioned when laundry is put into the drum or is

taken out of it.

• Clean the door filter after each drying cycle.

CLEANING AND MAINTENANCE

www.devicemanuals.eu/

Table of contents

Other Whirlpool Dryer manuals

Whirlpool

Whirlpool Vantage WGD7990X User manual

Whirlpool

Whirlpool 8562113 User manual

Whirlpool

Whirlpool MAYTAG MLG-52 User manual

Whirlpool

Whirlpool LEV4634JQ User manual

Whirlpool

Whirlpool WCD5090JW User manual

Whirlpool

Whirlpool LE-7680XM User manual

Whirlpool

Whirlpool AWZ 7303 User manual

Whirlpool

Whirlpool ELECTRIC LE5795XM User manual

Whirlpool

Whirlpool Duet GGW9200LW0 User manual

Whirlpool

Whirlpool WGD9470WW Parts list manual

Whirlpool

Whirlpool Duet GEQ8858EQ0 User manual

Whirlpool

Whirlpool WGD72HED User manual

Whirlpool

Whirlpool 29" User manual

Whirlpool

Whirlpool CEM2750TQ2 User manual

Whirlpool

Whirlpool WGD4985EW User manual

Whirlpool

Whirlpool LE7005XP User manual

Whirlpool

Whirlpool W11356336A User manual

Whirlpool

Whirlpool Duet YGEW9200LL1 User manual

Whirlpool

Whirlpool LEN3634DW0 User manual

Whirlpool

Whirlpool LE5200XT User manual

Whirlpool

Whirlpool W10562346B User manual

Whirlpool

Whirlpool YWED7500VW User manual

Whirlpool

Whirlpool 3401083 User manual

Whirlpool

Whirlpool LE6098XT User manual

Popular Dryer manuals by other brands

Bosch

Bosch WTA79200GB Installation and operating instructions

Amana

Amana W10233410A Use and care guide

Miele

Miele TWH 780 WP operating instructions

Asko

Asko T760 user guide

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Original instructions

Bosch

Bosch Logixx 10 WTB76556GB Instruction manual and installation instructions

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Operation and installation

Electrolux

Electrolux EW2H328R2 user manual

Beko

Beko DS8433RX1M user manual

Dawlance

Dawlance Spinner DS 6000 C owner's manual

Electrolux

Electrolux TP5080TW user manual

AEG

AEG TR838P4OB user manual

Indesit

Indesit IDV 75 instruction manual

Infiniton

Infiniton SD-DG85C manual

BOMANN

BOMANN WT 5019 instruction manual

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Installation

Asko

Asko T793C operating instructions

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer installation instructions
