Whirlpool AWZ 241 User manual

SERVICE Whirlpool Europe

Customer Services

Model AWZ 241

Version 8575 241 01000 Page

Technical data 2 - 3

Spare part list 4

Exploded view 5 - 6

Wiring diagram 7

Circuit diagram 8

Text/Legend 9 - 14

Service Manual

Tumble dryer

Air Vent

AWZ 241

This documentation is only intended for qualiﬁed technicians who are aware of the respec-

tive safety regulations.

Date: 27.09.2001 (Mod.01) Subject to modiﬁcation

Document-No.: 4812 713 12387

SERVICE

18.05.2001 / Page 2 AWZ 241 Whirlpool Europe

Doc. No: 4812 713 12387 8575 241 01000 Customer Service

Technical data

Dimensions

Height 85 cm

Width 59.5 cm

Depth 56 cm

Weight

Gross weight 33 kg

Net weight 31 kg

Surroundings temperature

Room temperature

maximun 35 ˚C

Room temperature

minimum 5 ˚C

Humidity

Relative humidity

maximun 95 %

Power connection

Voltage 230 V

Frequency 50 Hz

Connected load 2.8 kW

Fuse 16 A

Drum data

Volume 104 l

Drum speed 56 ±3 rpm

Airﬂow 120-160 m3/h

Capacity of laundry

Cotton max. 5 kg

Easy care max. 2.5 kg

Exhaust hose

Inner diameter 10 cm

Maximum allowable

length (with 2 bows) 4 m

Electrical components

Heating

Type IRCA 1T.8275001

Nominal voltage 230 +10% /-15% V

Nominal power 2500 ±5%W

Heating resistances:

Connection points 19.5 - 23 Ω

Thermostats

Safety thermostat (in heater) TL

Switch off (temp.) 298 -10 ˚C

Fluff thermostat (in heater) TH 1.2

Switch off (temp.) 220 ±7.5 ˚C

Exhausting thermostat (in airchannel) TH 1.1

Switch on (temp.) 38 ±5˚C

Switch off (temp.) 53 ±4˚C

Control module

Type Invensys 3224

Nominal voltage 230+10% /-15%V

Frequency 50/ 60 Hz

Rated currents

Motor ≤6A

Heater ≤16 A

Temperature

Ambient up to 85 ˚C

Storage up to 85 ˚C

Caution:

☞If one of the thermostats (TL, TH1.2)

is defective, the whole heating

element has to be changed for safety

reason !

☞Therefore, the thermostats are not

available as separate spare parts !

SERVICE Whirlpool Europe AWZ 241 18.05.2001 / Page 3

Customer Service 8575 241 01000 Doc. No: 4812 713 12387

Technical data

Main- and blower motor

Type 1-phase asynchronous

Nominal voltage 230 +10% / -15% V

Frequency 50 Hz

Power consumption 295±7% W

Resistances of coils:

Main coil (2-3) 24.7±7% Ω

Auxiliary coil (2-1) 25.6±7% Ω

Rated speed with 5 kg laundry

and 100% rest humidity 2730 rpm

Capacitor 10 ±7% µF

Radio interference ﬁlter

Typ ISKRA 7325

Voltage max. 275 V

Capacity 100 nF X1 + 2x 15nF Y2 + 1MQ

Display

No. of LEDs 7

Option buttons - Start

- Gentle

- Buzzer

Program selector 11 positions integrated ON/OFF (stand-by)

SERVICE

27.09.2001 (Mod.01) / Page 4 AWZ 241 Whirlpool Europe

Doc. No: 4812 713 12387 8575 241 01000 Customer Service

Spare part list

Model AWZ 241

Service No. 857524101000

Version 857524101000

Pos. No. 12NC Code Description

004 0 4812 530 48144 Bottom

011 0 4812 500 18054 Foot adjustable

012 0 4812 528 78033 Roll

012 1 4812 528 98003 Shaft Front + Roll

012 2 4812 520 28068 Shaft rear

021 0 4812 440 19387 Front,panel

022 0 4812 440 19445 Panel,side

024 0 4812 440 19467 Panel, rear from 98/34

030 0 4812 440 19779 Table top R0 VBL

033 0 4812 310 18582 Kit Push in cover

100 0 4812 416 18182 Door R0 WH VBL

131 1 4812 271 38362 Door lock

133 0 4812 417 28049 Pin Door

191 0 4812 466 68539 Gasket, door

220 0 4812 418 18199 Drum coated

223 0 4812 418 88027 Drum lifter

271 0 4812 358 18162 Belt 1965-H7 EH81

273 0 4812 358 18055 Pulley jokey

275 0 4812 492 68129 Spring

291 0 4812 466 68563 Gasket Drum front

291 1 4812 466 68541 Gasket Fluff Filter

291 2 4812 466 68562 Gasket Drum rear

301 0 4812 452 10892 Control panel

321 0 4812 452 10891 Insert panel

321 1 4812 446 88127 Fastener f. Inlay

331 0 4812 414 58111 Knob,timer VBL cpl.

332 0 4812 276 18329 Button VBL WH EL Start

332 1 4812 276 18328 Button VBL WH EL Opt.

401 0 4812 361 18247 Motor

401 1 4812 401 18421 Clamp Motor

420 0 4812 121 18144 Capacitor 10 µF

421 0 4812 121 18158 Interf.ﬁlter

443 0 4812 361 18248 Blower Wheel

456 0 4812 259 28674 Heating element 2500W

490 0 4812 321 18087 Cable,mains

490 1 4812 321 28367 Strain relief

492 1 4812 401 18195 Clip

521 0 4812 214 78615 Control board Type 3224

551 3 4812 271 28369 Thermostat

633 1 4812 276 18271 Pin Start Reset

692 0 4812 278 58001 Sensor

743 0 4812 530 48145 Air guide

743 1 4812 530 48147 Heating chamber

743 2 4812 466 68538 Seal for blower

761 0 4812 480 58077 Filter

794 0 4812 466 28107 Gasket

900 1 4812 290 88053 Clip

902 1 4812 256 38002 Bracket Roller

903 0 4812 532 28028 Clip,ﬁx

910 0 4812 502 38057 Screw Torx 4,2 x 13

910 5 4819 502 38265 Screw VAB 4,5x20

910 8 4812 502 48347 Screw,selftap 3,5x14SS

912 4 4812 502 48015 Screw 4,0x16-TORX

922 0 4812 532 58005 Ring,circlip Triring

922 1 4812 532 58007 Ring,circlip

Pos. No. 12NC Code Description

962 0 4812 466 38012 Protector Motor

962 2 4812 466 38056 Protec,el.parts Foil Aluminium

993 0 4812 263 78014 Adapter

993 1 4812 310 18413 Accessory hose kit AMH 577

SERVICE Whirlpool Europe AWZ 241 27.09.2001 (Mod.01) / Page 5

Customer Service 8575 241 01000 Doc. No: 4812 713 12387

Exploded view

SERVICE

27.09.2001 (Mod.01) / Page 6 AWZ 241 Whirlpool Europe

Doc. No: 4812 713 12387 8575 241 01000 Customer Service

Exploded view

SERVICE Whirlpool Europe AWZ 241 18.05.2001 / Page 7

Customer Service 8575 241 01000 Doc. No: 4812 713 12387

Wiring diagram

SERVICE

18.05.2001 / Page 8 AWZ 241 Whirlpool Europe

Doc. No: 4812 713 12387 8575 241 01000 Customer Service

Circuit diagram

SERVICE Whirlpool Europe AWZ 241 18.05.2001 / Page 9

Customer Service 8575 241 01000 Doc. No: 4812 713 12387

Text/Legend

SERVICE

18.05.2001 / Page 10 AWZ 241 Whirlpool Europe

Doc. No: 4812 713 12387 8575 241 01000 Customer Service

Text/Legend
