Vivo DESK-V102E User manual

Black Electric Single Motor Desk Frame

Follow along step-by-step with our video walk through by scanning

the QR code with your mobile device or by following the product

link: vivo-us.com/products/desk-v102e

Instruction Manual

SKU: DESK-V102E

ASSEMBLY VIDEO AVAILABLE:

[email protected]om www.vivo-us.com

309-278-5303

PERSONABLE CUSTOMER SUPPORT

Our friendly product support team is here to help!

DO NOT RETURN ITEM

We’re Here for You!

Missing a Part?

Our customer-minded support team is here for YOU,

Monday-Friday 7am-7pm CST.

We oer immediate assistance with rapid response times

from customer service agents and product techncians to

help you every step of the way!

Monday-Friday

Chat Us:

www.vivo-us.com

Give us a Call:

309-278-5303

Email Us:

[email protected]om

If any parts are received damaged / defective OR you are

missing a part, please reach out to us within 30 days of

product delivery to have it replaced at no cost.

We are happy to replace parts to ensure you have a fully

functioning product

7AM - 7PM

If you do not understand these directions, or if you have any

doubts about the safety of the installation, please call a qualified

technician. Check carefully to make sure there are no missing

or defective parts. Improper installation may cause damage or

serious injury. Do not use this product for any purpose that is

not explicitly specified in this manual. Do not exceed weight capacity. We

cannot be liable for damage or injury caused by improper mounting, incorrect

assembly or inappropriate use.

PRE-ASSEMBLY | BEFORE YOU BEGIN

Product Warranty

Returns | Product Didn’t Work Out?

For the most up to date details on your product’s warranty, please visit

the product’s listing on our website or reach out to customer support.

vivo-us.com/products/desk-v102e

We oer a hassle-free 30 day return on all products. Contact customer

support at 309-278-5303 or [email protected]om. Please note: For items

ordered in error or no longer needed, the return shipping charges will

be at the buyer’s expense.

WARNING: CHOKING HAZARD

SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS

REQUIRED.

SERIOUS OR FATAL CRUSHING INJURIES CAN OCCUR FROM TIPOVER. TO HELP

PREVENT TIPOVER:

• NEVER ALLOW CHILDREN TO CLIMB, STAND, HANG, OR PLAY ON ANY PART

OF TV OR TV CART.

• USE TIPOVER RESTRAINT OR ANCHOR STAND TO WALL

USE OF TIPOVER RESTRAINTS MAY ONLY REDUCE, BUT NOT ELIMINATE RISK

OF TIPOVER.

TIPOVER WARNING

WEIGHT CAPACITY

DO NOT EXCEED WEIGHT CAPACITY. Failure to do so may result in serious injury.

176lbs

(80kg)

PACKAGE CONTENTS

NOTE: SOME HARDWARE INCLUDED MAY NOT BE USED

A (x1)

Crossbar

B(x1)

Motorized

Leg

C(x1)

Leg

I (x1)

Shelf

J (x2)

Hook

H(x1)

Controller

D (x2)

Side Bracket

E (x1)

Sync Rod

F (x2)

Foot

G (x1)

Power

Adapter

S-F (x5)

ST3.5x13

Screw

S-E (x4)

M6x50mm Hex

Head Screw

S-A (x4)

M4x4mm

Screw

S-B (x4)

M5x14mm

Screw

S-D (x8)

M6x16mm Hex

Head Screw

S-C (x2)

M6x25mm Hex

Head Screw

T-A (x1)

4mm Allen

Wrench

S-G (x9)

ST4.2x16Screw

S-H (x9)

Anti-Vibration

Pad

Please consult the parts list below and ensure you have everything you need to assemble

your product. If parts are missing or damaged, please contact us.

Phillips Screwdriver

TOOLS NEEDED:

DIFFICULTY LEVEL

K (x1)

Power Cable

L (x3)

Cable Clip

Drill

Level

STEP 1: Attaching the Crossbar

Loosen set screw on Crossbar (A) to adjust length and re-tighten. Attach Crossbar (A) to Motorized Leg (B)

with M6x50mm Screws (S-E) and M6x25mm Screws (S-C), as shown below.

Have a question? Give us a quick call / chat!

309-278-5303 or vivo-us.com

ASSEMBLY STEPS

T-A

Crossbar

Motorized Leg

Leg

S-E

M6x50mmScrew

S-C

M6x25mm Screw

T-A

4mm Allen Wrench

STEP 2: Attaching Side Brackets

Attach Side Brackets (D) to Motorized Leg (B) and Leg (C) using M5x14mm Screws (S-B) using 4mm Allen

Wrench (T-A).

STEP 3: Apply Anti-Vibration Pads

Apply Anti-Vibration Pads (S-H) to top of Side Brackets (D), as shown below.

T-A

Side Bracket

S-B

M5x14mm Screw

S-B

S-H

Anti-Vibration Pad

T-A

4mm Allen Wrench

STEP 4: Installing Desk Feet

STEP 5: Adjusting Frame Width to Desktop

Flip desk frame over and attach Foot (F) to bottom of Motorized Leg (B) and Leg (C) using M6x16mm Screws

(S-D) and 4mm Allen Wrench (T-A).

Place intended desktop (not provided) upside down onto of a so surface and then place desk frame

assembly upside down on desktop. Adjust frame width to size of desktop, ensuring the that frace is centered

on the desktop.

Have a question? Give us a quick call / chat!

309-278-5303 or vivo-us.com

T-A

Foot

S-D

M6x16mm Screw

T-A

4mm Allen Wrench

STEP 6: Installing the Sync Rod

STEP 7: Installing the AC Adapter

Loosen the knobs on the Sync Rod (E) and extend the hex sha. Insert hex sha into the Leg (C), making sure

the metal retaining ring makes contact with the Leg. While holding the hex sha with one hand, extend sync

rod onto the spline sha of Motorized Leg (B). Retighten knob. Tighten set screw on Crossbar (A) to secure

frame width.

Attach Hooks (J) to Shelf (I) using M4x4mm Screws (S-A) with a Phillips screwdriver. Hang Cable

Management Tray (I) onto the Crossbar (A) and tighten knobs to secure. Place Power Adapter (G) into Cable

Management Tray.

Sync Rod

Cable Managemnet

Tray

Hook

Power Adapter

Leg with Motor

Leg

1 2 3 4

T-A

4mm Allen Wrench

S-A

M4x4mm Screw

STEP 8: Connect Frame to Desktop

Use ST4.2x16 Screw (S-G) to secure desk frame to desktop with a drill.

Have a question? Give us a quick call / chat!

309-278-5303 or vivo-us.com

S-G

ST4.2x16Screw

STEP 9: Connecting the Controller

Connect cords from Controller (H) to cord from Motorized Leg (B) and Power Adapter (G). Connect

Power Cable (K) to Power Adapter (G).

H(x1)

Controller

K (x1)

Power Cable
