Velleman K8063 User manual

2 MODULAR DIGITS WITH SERIAL INTERFACE

K8063

ILLUSTRATED ASSEMBLY MANUAL H8063IP-1

Total solder points: 82

Difficulty level: beginner 12345 advanced

Multipleunitscanbelinkedinaneasy

waytocreatelargerreadoutsfore.g.

Score-keeping,timing,counting,...

Features & Specifications

The K8063 is a 7-segment display which can be controlled by a two-wire serial connection, using the RS232 protocol. The

protocol is platform-independent i.e. any computer running any programming language can control the K8063, as long as it

is equipped with a serial port. Up to 255 units can be individually addressed, allowing you to create large display systems for

e.g. scoreboards, clocks, timers, thermometers, games, …

Features

 Red bright 57mm jumbo 7-segment display

 Complete with snap-in enclosure

 Multiple units can easily be linked in order to create larger readouts for different purposes e.g. scorekeeping, timing,

counting, ...

 Easy platform-independent control via three-wire RS232 interface

 Up to 255 separate units can be addressed

 Tested with distances of up to 50m between PC and display

 Use our optional PCUSB6 for USB connection

Specifications



Power supply: 9 to 12Vdc / 120mA per display

 RS232 interface: 2400baud / 8databits / no parity / 1 stop bit

 Dimensions: 74 x 58.5 x 32mm

 The general manuals containing guidelines for assembly, safety and electromagnetic compatibility can be downloaded

from our Velleman website (support / manuals / HALG).

Assembly hints

1. Assembly (Skipping this can lead to troubles ! )

Ok, so we have your attention. These hints will help you to make this project successful. Read them carefully.

1.1 Make sure you have the right tools:

• A good quality soldering iron (25-40W) with a small tip.

• Wipe it oftenon a wet sponge or cloth, to keep it clean; then apply solder to the tip, to give it awet look. This is called ‘thinning’ and will

protect the tip, and enables you to make goodconnections. When solder rolls off the tip, it needs cleaning.

• Thin raisin-core solder. Do not use any flux or grease.

• A diagonal cutter to trim excess wires. To avoid injury whencutting excess leads, hold the lead so they

cannot fly towards the eyes.

• Needle nose pliers, for bending leads, or to hold components in place.

• Small blade and Phillips screwdrivers. A basic range is fine.

For some projects, a basic multi-meter is required, or might be handy

1.2 Assembly Hints :

⇒ Make sure the skill level matches your experience, to avoid disappointments.

⇒ Follow the instructions carefully. Read and understand the entire step before you perform each operation.

⇒ Perform the assembly in the correct order as stated in this manual

⇒ Position all parts on the PCB (Printed Circuit Board) as shown on the drawings.

⇒ Values on the circuit diagram are subject to changes.

⇒ Values in this assembly guide are correct*

⇒ Use the check-boxes to mark your progress.

⇒ Please read the included information on safety and customer service

* Typographical inaccuracies excluded. Always look for possible last minute manual updates, indicated as ‘NOTE’ on a separate leaflet.

0.000

Assembly hints

1.3 Soldering Hints :

1- Mount the component against the PCB surface and carefully solder the leads

2- Make sure the solder joints are cone-shaped and shiny

3- Trim excess leads as close as possible to the solder joint

REMOVE THEM FROM THE TAPE ONE AT A TIME !

AXIAL COMPONENTS ARE TAPED IN THE

CORRECT MOUNTING SEQUENCE !

You will find the colour code for the resistances and the LEDs in the HALG

(general manual) and on our website: http://www.velleman.be/common/service.aspx

Construction

 C1 : 100nF (104)

 C2 : 100nF (104)

 C3 : 100nF (104)

5. Capacitors

 IC1 : 14p

4. IC socket. Watch the

position of the notch!

 ZD1 : 5V1

 ZD2 : 5V1

 ZD3 : 4V3

1. Zener diodes. Watch the

polarity !

ZD...

CATHODE

 D1 : 1N4007

2. Diode. Watch the polarity !

D...

CATHODE

 R1 : 560 (5 - 6 - 1 - B)

 R2 : 560 (5 - 6 - 1 - B)

 Mount R2 at end of chain !

For example: when linking 4

digits, mount the resistor R2 on

the last (4th) digit and leave its

space open on the other 3 digits.

 R3 : 10K (1 - 0 - 3 - B)

 R4 : 1K (1 - 0 - 2 - B)

 R5 : 100 (1 - 0 - 1 - B)

 R6 : 100 (1 - 0 - 1 - B)

 R7 : 100 (1 - 0 - 1 - B)

 R8 : 100 (1 - 0 - 1 - B)

 R9 : 100 (1 - 0 - 1 - B)

 R10 : 100 (1 - 0 - 1 - B)

3. Resistors

R...

Remark: all components are supplied in a double quantity to allow the assembly of 2 digits. Repeat the

procedure of the first digit to assemble the second one.

 R11 : 100 (1 - 0 - 1 - B)

 R12 : 100 (1 - 0 - 1 - B)

 R13 : 100K (1 - 0 - 4 - B)

Construction

 RS232 (2x)

 + (2x)

 GND (2x)

Remark: on the outer digits, only the

PCB tabs close to the IC have to be

mounted.

10. PCB tabs

 IC1 : VK8063

Programmed PIC16F630

12. IC. Watch the position of

the notch!

 T1 : BC547B

7. Transistor.

 C4 : 100µF

 C5 : 100µF

8. Electrolytic Capacitors.

Watch the polarity !

 VR1 : UA7809

6. Voltage regulator

M3 NUT

VOLTAGE REGULATOR

PCB

M3 BOLT

VR...

I O

C...

 SK7:

9. Pin header

 10x

11. Tulip pin headers

Solder side

WATCH FOR SHORTS !

Construction

Mount the spacers onto the PCB with the 2 in-

cluded screws and install the digit display on the

solder side of the PCB. Pay attention to the posi-

tion of the decimal point, see figure 1.0.

Then turn the PCB around and place it into the housing with the display

towards the front, see figure 2.0.

13. Assembly

Fig 1.0

Fig 2.0

2nd digit1st digit

Construction

If you want to mount the digit(s) on the wall, finish by mounting the brackets on the PCB, see figure 3.0

Fig 3.0

Parker screw

2,9 x 12,7mm

Test

When the assembly has been completed, we recommended to test each

individual unit before daisy-chaining them. Make sure SK7 (address jumper) is

put in place, see figure 4.0.

Connect a 9 to 12VDC power supply to the pins GND and +V.

At power-on, the K8063 will display .0123456789 (segment test).

Next, it will display its current address (default : 1) for a couple of seconds.

At this time, the K8063 allows you to select an address ranging from 0 to 19*.

Simply wait until the desired address is displayed and remove the SK7

address jumper. ( note : addresses 0 to 9 are displayed as 0 to 9, addresses

10 to 19 are displayed as 0. to 9. (note the dot).

The K8063 will loop the addresses until the jumper is removed, so if you have missed the desired address,

you can wait a while and it will appear again.

Once you have removed the jumper, the K8063 stops looping and after a couple of seconds the display will

turn blank. The selected address is now stored in its memory.

*If you require 20 or more different addresses, you can configure them when the K8063 units are hooked-up

to the computer (see further in this manual).

14. Test

Fig 4.0

Hook-up

15. Hook-up

Female 9P SUBD connector

To serial port

Fig 5.0

To pin 2 & 3 ‘+’ supply ‘-’ supply To pin 5

12n

Hook-up : All units have two sets of connectors. This allows you to hook them up in an easy way, as

shown below (fig. 5.0):
