FUNCTIONS:
○
1Sensor probe
○
2Display screen
○
3Power / Backlight button
Power on/off:
Press the button to turn on the unit. To turn the unit off, press and hold button down
until the screen shows “OFF 3, 2, 1, 0,”then the LCD screen goes off.
Note:
When the unit is on, the LCD will show the following initial information before entering the main
function: Available memory
Current date
Current time
Entering main function
LCD backlight on/off:
Press button to turn on the LCD backlight, making it easier to read in dark environment.
Press button again to turn off backlight. The backlight will turn itself off automatically after
30 seconds to save battery power.
Auto power off:
To save battery life, by default, every time the unit is powered on, it is under auto power off mode.
The unit will power itself off after 30 minutes if no key operation.
Auto power off will be automatically disabled under the following 2 circumstances:
When connecting to PC.
When data logger function is in process.
Disabled auto power off:
(1) Turn off the unit.
(2) Press and hold button, and keep holding button.
(3) Press button to turn on the unit.
(4) The LCD shows the initial information and then enters main function.
(5) Release button.
(6) Make sure the auto power off symbol disappears from display screen.
○
4REC button
Press button to start recording data. The REC symbol will display on the screen. To stop
recording, press button again.
○
5Relative Humidity/Dew Point Temperature switch
By default, the LCD displays Relative Humidity when the unit is powered on. To display dew point
(DP) temperature, press button. Press button again to switch back to Relative
Humidity.
○
6MAX/MIN mode
Under this mode, the unit simultaneously monitors and stores the maximum and minimum value
(both humidity and temperature) in the memory. The unit will keep updating/refreshing the data.
