Thermo Electron Polysonics SX40 User manual
Analyze · Detect · Measure · ControlTM
Polysonics SX40
Dedicated Doppler Flowmeter
User Guide
P/N 1-0563-006
Revision G
HDS MESSTECHNIK
Franz-Kissing-Straße 7
58706 Menden
Tel.: 02373 / 1341
Fax: 02373 / 2488
www.hds-messtechnik.de
Polysonics SX40
Dedicated Doppler Flowmeter
User Guide
P/N 1-0563-006
Revision G
2005© Thermo Electron Corporation. All rights reserved.
“Sil-Glyde” is a registered trademark of American Grease Stick Company.
All other trademarks are the property of Thermo Electron Corporation and its subsidiaries.
Thermo Electron Corporation (Thermo) makes every effort to ensure the accuracy and completeness of this
manual. However, we cannot be responsible for errors, omissions, or any loss of data as the result of errors or
omissions. Thermo reserves the right to make changes to the manual or improvements to the product at any time
without notice.
The material in this manual is proprietary and cannot be reproduced in any form without express written consent
from Thermo.
This page intentionally left blank.
Thermo Electron Corporation Polysonics SX40 User Guide ii
Contents
Product Overview..............................................................................................1-1
Introduction........................................................................................ 1-1
Ordering Information ......................................................................... 1-1
Specifications ...................................................................................... 1-2
Performance..................................................................................... 1-2
Physical............................................................................................ 1-2
Functional........................................................................................ 1-3
Approvals ......................................................................................... 1-4
Installation & Wiring........................................................................................2-1
Installing the Transducers ................................................................... 2-1
Mounting the Enclosure...................................................................... 2-4
Wiring ................................................................................................ 2-5
AC Power......................................................................................... 2-5
DC Power........................................................................................ 2-6
Transducers..................................................................................... 2-7
Relays............................................................................................... 2-9
4–20 mA Current Loop (Rev. F or Earlier) .................................... 2-11
4–20 mA Current Loop (Rev. G or Later)...................................... 2-13
Connecting a Switch to Remote Zero Feature................................ 2-14
Operation & Configuration ..............................................................................3-1
The Interface....................................................................................... 3-1
Screen Contrast................................................................................ 3-1
Configuration ..................................................................................... 3-2
Auto Mode....................................................................................... 3-2
Manual Mode .................................................................................. 3-3
HydraScan .......................................................................................... 3-6
Setup Items.........................................................................................................4-1
Reset ................................................................................................... 4-1
Config................................................................................................. 4-1
I/O Test.............................................................................................. 4-1
Relays............................................................................................... 4-1
4–20 mA Loop Calibration .............................................................. 4-1
4–20 mA Loop Test ......................................................................... 4-2
Flow.................................................................................................... 4-2
Rate.................................................................................................. 4-2
Chapter 1
Chapter 2
Chapter 3
Chapter 4
Contents
iii Polysonics SX40 User Guide Thermo Electron Corporation
Max.................................................................................................. 4-2
Flow Menu Items .............................................................................................. 5-1
Setup................................................................................................... 5-1
FFT..................................................................................................... 5-1
Logset ................................................................................................. 5-1
Accessing, Saving, & Loading Log Files............................................ 5-1
Trend.................................................................................................. 5-1
Rate.................................................................................................. 5-1
Max.................................................................................................. 5-1
Troubleshooting & Maintenance................................................................... 6-1
General Troubleshooting .................................................................... 6-1
Learn Mode Warnings ..................................................................... 6-2
Operating Mode Warnings .............................................................. 6-2
Variable Frequency Drives (VFDs)................................................... 6-3
Checking the FFT............................................................................ 6-3
Signal Quality & Strength................................................................... 6-5
General ............................................................................................ 6-6
Maintenance ....................................................................................... 6-6
Replacing the Relays......................................................................... 6-6
Replacing the 4–20 mA Board ......................................................... 6-7
Replacing the Fuse ........................................................................... 6-8
Upgrades............................................................................................. 6-9
Service & Returns ............................................................................... 6-9
Warranty........................................................................................... 6-10
Hazardous Area Installations........................................................................ A-1
Obtaining Pipe ID............................................................................................. B-1
Chapter 5
Chapter 6
Appendix A
Appendix B
Thermo Electron Corporation Polysonics SX40 User Guide 1-1
Chapter 1
Product Overview
Thermo’s Polysonics SX40 Dedicated Doppler Flowmeter generates two
independent ultrasonic signals at different frequencies. By correlating these
frequencies, the instrument automatically identifies and eliminates noise
errors from sources such as variable frequency drives.
In addition, operation of the instrument is enhanced by an Expert System
which allows the flowmeter to automatically “learn” the application
parameters. As a result, the flowmeter can be easily commissioned in a
fraction of the time required to configure competitive ultrasonic
flowmeters.
Refer to the following list of part numbers to order spare parts for your
instrument.
Table 1–1.
Part Number Description
22767-0001 Poly CD, specification sheet, meter installation video CD
1-0563-006 User guide
1-0561-005 HydraScan software manual
01008-0006 RS232 cable, standard serial, 6-ft, female to male, DB9
10241-0003 Hazardous area relay, 3 A, SPDT
10261-0013 Fuse, 1 A, time delay, AC input
10396-0194 Power cord connector, CGB, for 6-ft AC power cord
10605-0001 Pipe strap, SS, 32-inch with 3/8 SS screw
10605-0003 Pipe strap, SS, 67-inch with 3/8 SS screw
10705-0003 Nut driver, 3/8-inch
10808-0002 Coupling compound, silicone RTV108, 2.8 oz
10823-0005 Coupling compound, Sil-Glyde®, 4-oz
20192-0001 SS tag
22061-0001 Heater assembly suitable for -40°F to 140°F (-40°C to 60°C) operation,
100–120 Vac
22061-0002 Heater assembly suitable for -40°F to 140°F (-40°C to 60°C) operation,
220–240 Vac
Introduction
Ordering
Information
Product Overview
Specifications
1-2 Polysonics SX40 User Guide Thermo Electron Corporation
Part Number Description
22204-0003 Mounting feet, set of 4
22262-0006 PCB assembly, 4–20 mA output (applicable with firmware v. 2.03)
22302-0002 PCB assembly, motherboard (specify input voltage)
22366-0002 Cable adapter, dedicated transducer to portable meter
22490-0001 Cable adapter set, portable transducer to dedicated meter
22511-0020 Intrinsically Safe barrier kit, universal
22686-0002 PCB assembly, Doppler
22703-0002 Transducer assembly (set of 2), 30-ft cable length
22705-0002 PCB assembly, CPU
22714-0002 PCB assembly, adapter board
22732-0001 Front panel assembly, includes keypad and display
22801-0002 PCB assembly, 4–20 mA output (applicable with firmware v. 3.03)
22061-0003 Heater assembly suitable for -40°F to 140°F (-40°C to 60°C) operation,
24 Vdc
Velocity Range: 0.2–18 ft/s (0.06–5.5 m/s)
Accuracy: ±1% of velocity full scale
Fluids: Liquids containing particulate or entrained gas bubbles
Pipe Size: 0.5–200 in (12–5000 mm)
Transmitter: NEMA 4X (IP65), flame retardant, fiberglass reinforced
polyester
Transducers
Two encapsulated dual frequency sensor heads suitable for
submersible/underground service
Encased in stainless steel shrouds, with stainless steel straps and quick
clamps
Cable length: 30 ft (9 m)
Weight: 12 lb (5.4 kg)
Dimensions: Refer to the Figure 1–1
Specifications
Performance
Physical
Product Overview
Specifications
Thermo Electron Corporation Polysonics SX40 User Guide 1-3
Figure 1–1.
Outputs: 4–20 mA (into 750 ohms), 12-bit, 5 kV opto-isolated; loop or
self-powered
Optional Relay: 5-A, SPDT, programmable relay; maximum of 4
Power Supply
DC Power: 11–28 Vdc
AC Power: 90–132 Vac or 190–250 Vac (switch selectable), 50/60 Hz
Keypad: 19-key with tactile action
Display: Backlit, 240 x 60 dot, high resolution graphics display
Data Logger
90000-point data logger
Programmable in intervals of 30 s, 1, 5, 15, 30, and 60 min
Programming: Via HydraScan software or integral keypad
Serial Interface: RS232
Functional
