Teledyne Lecroy PP016 User manual

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

Excellent Integrated System Limited

Stocking Distributor

Click to view price, real time Inventory, Delivery & Lifecycle Information:

Teledyne LeCroy

PP016

For any questions, you can email us directly:

[email protected]

1 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

Operator’s

Manual

PP016 Passive Probe

2 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

3 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

Unauthorized duplication of Teledyne LeCroy documentation materials other than for internal sales

and distribution purposes is strictly prohibited. However, clients are encouraged to distribute and

duplicate Teledyne LeCroy documentation for their own internal educational purposes.

WaveAce and Teledyne LeCroy are registered trademarks of Teledyne LeCroy, Inc. Windows is a

registered trademark of Microsoft Corporation. Other product or brand names are trademarks or

requested trademarks of their respective holders. Information in this publication supersedes all earlier

versions. Specifications are subject to change without notice.

Warranty

Teledyne Lecroy warrants this oscilloscope accessory for normal use and operation within specification

for a period of one year from the date of shipment. Spare parts, replacement parts and repairs are

warranted for 90 days.

In exercising its warranty, Teledyne Lecroy, at its option, will either repair or replace any assembly

returned within its warranty period to the Customer Service Department or an authorized service

center. However, this will be done only if the product is determined by Teledyne Lecroy’s examination

to be defective due to workmanship or materials, and the defect is not caused by misuse, neglect,

accident, abnormal conditions of operation, or damage resulting from attempted repair or

modifications by a non-authorized service facility.

The customer will be responsible for the transportation and insurance charges for the return of

products to the service facility. Teledyne Lecroy will return all products under warranty with

transportation charges prepaid.

This warranty replaces all other warranties, expressed or implied, including but not limited to any

implied warranty of merchantability, fitness or adequacy for any particular purposes or use. Teledyne

Lecroy shall not be liable for any special, incidental, or consequential damages, whether in contract or

otherwise.

922209-00 Rev A

January 2013

4 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

PP016 Passive Probe

2 922209-00 Rev A

Safety Instructions

This section contains instructions that must be observed to keep this oscilloscope

accessory operating in a correct and safe condition. You are required to follow

generally accepted safety procedures in addition to the precautions specified in this

section. The overall safety of any system incorporating this accessory is the

responsibility of the assembler of the system.

Symbols

These terms and symbols may appear on the probe body or in this manual to alert

you to important safety considerations.

High Voltage, risk of electric shock.

CAUTION of potential damage to equipment, or WARNING of potential for

bodily injury. Attend to the accompanying information/product manual to

protect against personal injury or damage. Do not proceed until conditions

are fully understood and met.

DOUBLE INSULATION

PROTECTIVE (EARTH) TERMINAL

Precautions

To avoid personal injury or damage to property, review and comply with the

following safety precautions. Use product only as specified.

Connect only to grounded instruments. Use only with compatible Teledyne LeCroy

oscilloscopes that have their BNC input connected to an earth ground. Do not

connect the probe reference lead to any point which is at a potential other than

earth ground.

Connect and disconnect properly. Connect probe to the oscilloscope before

connecting the probe to the test circuit. Disconnect the probe input and reference

lead from the test circuit before disconnecting the probe from the oscilloscope. To

avoid injury or death due to electric shock, do not connect or disconnect probes or

probe accessories while they are connected to a voltage source.

5 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

Operator’s Manual

922209-00 Rev A 3

Do not overload. To avoid electric shock or fire, do not apply any potential to the

probe leads that exceeds the maximum rating of the probe.

Comply with voltage derating curve. When measuring higher frequency signals,

comply with the Voltage vs. Frequency Derating Curve.

Observe all terminal ratings. To avoid electric shock or fire, observe all markings on

the oscilloscope before connecting. Consult the respective oscilloscope product

manual for further ratings information.

Do not remove probe casing. Removing the probe’s case or touching exposed

connections may result in electric shock.

Use only within operational environment listed. Do not use in wet or explosive

atmospheres. Keep product surfaces clean and dry.

Use only accessories compatible with the probe.

Handle with care. The probe tip is extremely sharp and may puncture skin or cause

other bodily injury if not handled properly.

Keep fingers behind the finger guard of probe body and accessories.

Do not operate with suspected failures. Before each use, inspect the probe and

accessories for any potential damage such as tears or other defects in the probe

body, cable jacket, accessories, etc. If any part is damaged, cease operation

immediately and sequester the probe from inadvertent use.

Operating Environment

The accessory is intended for indoor use and should be operated in a clean, dry

environment. Before using this product, ensure that its operating environment is

maintained within these parameters:

Temperature: Operating, 5° to 40° C; Non-operating, - 20° to 60° C

Humidity: 5% to 85% relative humidity (%RH) up to +30° C

5% to 65% RH above +30° C to 40° C

5% to 45% RH above 40° C

Altitude: Up to 3000 m (9842 ft)

6 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

PP016 Passive Probe

4 922209-00 Rev A

Introduction

The probe PP016 described in this manual is a passive probe to be used with

Teledyne LeCroy WaveAce oscilloscopes.

Accessories

Following is the standard accessory kit included with the PP016.

Standard Ground Lead 1

Sprung Hook 1

Color Coding Rings (set) 2

Adjustment Tool 1

Ground Attachment 1

Replacement Probe Tip 2

BNC Adaptor 1

IC Test Tip 2

The part number for the Standard Accessory Replacement Kit is PKIT3-5MM-101.

7 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

Operator’s Manual

922209-00 Rev A 5

Specifications

Attenuation 1: 1 10:1

Bandwidth (MHz) 10 300

Input R (MΩ) 1 10

Input C (pF) 46 12

Compensation Range (pF) NA 10-35

Maximum Input Voltage 600 V (DC + ACpeak) CAT II

Cable Length 1.2 m

Connector Type BNC

Operating Temperature 5° to 40° C

Storage Temperature -20° to 60° C

Humidity 5% to 85% relative humidity (%RH) up to +30° C

5% to 65% RH above +30° C to 40° C

5% to 45% RH above 40° C

Operating Altitude Up to 3000 m

NOTE: The maximum input voltage derates when frequency response is

approximately 30 kHz or higher. See Voltage Derating curve below.

Voltage Derating

8 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

PP016 Passive Probe

6 922209-00 Rev A

Cleaning

The outside of the probe should cleaned with a soft cloth dampened with either

deionized / distilled water or isopropyl alcohol. Allow the surface to dry completely

before returning the probe to service. Never immerse the probe in any liquid.

Probe Compensation

Proper compensation of the probe is required to assure good amplitude accuracy in

the dynamic portions of the waveform being measured. LF compensation matches

the probe to differences in oscilloscope input capacitance. The LF compensation

should always be checked and adjusted as needed when first connecting a passive

probe to the oscilloscope input. HF compensation matches time constants within

the probe to compensate for normal component tolerances. It is typically not

necessary to adjust HF compensation unless the probe is being used with an

oscilloscope with large differences in input characteristics than the oscilloscope

model it was designed for.

LF compensation is performed by connecting the input of the probe to a low

frequency square wave, such as the oscilloscope calibrator signal set to 1 kHz. The

compensation is adjusted by rotating the adjustment accessible through the small

hole in the center of the housing near the BNC connector. Use the tool supplied

with the probe for this adjustment.

9 / 13

Distributor of Teledyne LeCroy: Excellent Integrated System Limited

Datasheet of PP016 - PASS PROBE 10:1 300MHZ-WAVEACE

Operator’s Manual

922209-00 Rev A 7

Certifications

This section certifies the probe’ Safety and Environmental compliance.

EC Declaration of Conformity - Safety

The probe meets intent of EC Directive 2006/95/EC for Product Safety. Compliance

was demonstrated to the following specifications as listed in the Official Journal of

the European Communities:

EN 61010-031/A1:2008 Safety requirements for electrical equipment for

measurement, control, and laboratory use –Part 031: Safety requirements for

hand-held probe assemblies for electrical measurement and test.

Measurement Category II (CAT II), measurements performed on circuits

directly connected to the low-voltage installation.

Pollution Degree 2, operating environment where normally only dry non-

conductive pollution occurs. Conductivity caused by temporary

condensation should be expected.

Environmental Compliance

END-OF-LIFE HANDLING

The instrument is marked with this symbol to indicate that it complies

with the applicable European Union requirements to Directives

2002/96/EC and 2006/66/EC on Waste Electrical and Electronic

Equipment (WEEE) and Batteries.

The instrument is subject to disposal and recycling regulations that

vary by country and region. Many countries prohibit the disposal of

waste electronic equipment in standard waste receptacles. For more

information about proper disposal and recycling of your Teledyne LeCroy product,

please visit teledynelecroy.com/recycle.

RESTRICTION OF HAZARDOUS SUBSTANCES (ROHS)

This instrument has been classified as Industrial Monitoring and Control Equipment

and is outside the scope of the 2011/65/EU RoHS Directive until 22 July 2017 (per

Article 4, Paragraph 3).

10 / 13

Other manuals for PP016

Table of contents

Other Teledyne Lecroy Measuring Instrument manuals

Teledyne Lecroy

Teledyne Lecroy ZD500 User manual

Teledyne Lecroy

Teledyne Lecroy WaveRunner 8000-R User manual

Teledyne Lecroy

Teledyne Lecroy USB Advisor T3 User manual

Teledyne Lecroy

Teledyne Lecroy MDA800A User manual

Teledyne Lecroy

Teledyne Lecroy 280 User manual

Teledyne Lecroy

Teledyne Lecroy PP016 User manual

Teledyne Lecroy

Teledyne Lecroy MDA810 User manual

Teledyne Lecroy

Teledyne Lecroy M21 User manual

Teledyne Lecroy

Teledyne Lecroy frontline SODERA User manual

Teledyne Lecroy

Teledyne Lecroy Everywhereyoulook DL05-HCM User manual

Teledyne Lecroy

Teledyne Lecroy Everywhereyoulook ZS4000 User manual

Teledyne Lecroy

Teledyne Lecroy Everywhereyoulook SierraNet M168 User manual

Teledyne Lecroy

Teledyne Lecroy Frontline 802.11 Mounting instructions

Teledyne Lecroy

Teledyne Lecroy AP033 User manual

Teledyne Lecroy

Teledyne Lecroy BPA 600 User manual

Teledyne Lecroy

Teledyne Lecroy DL03-ISO User manual

Teledyne Lecroy

Teledyne Lecroy WaveMaster 8000HD User manual

Teledyne Lecroy

Teledyne Lecroy 980 User manual

Teledyne Lecroy

Teledyne Lecroy PPE6KV-A User manual

Teledyne Lecroy

Teledyne Lecroy ZD200 User manual

Teledyne Lecroy

Teledyne Lecroy Frontline X240 User manual

Teledyne Lecroy

Teledyne Lecroy M42de User manual

Teledyne Lecroy

Teledyne Lecroy HVD3000 Series User manual

Teledyne Lecroy

Teledyne Lecroy LabMaster LM 10-25Zi-A User manual

Popular Measuring Instrument manuals by other brands

Suaoki

Suaoki D40 user manual

Elster

Elster BK-G1.6 operating instructions

Endress+Hauser

Endress+Hauser Deltabar FMD71 technical information

Duratool

Duratool D03128 manual

Vega

Vega VEGAPULS 65 Quick setup guide

Tonghui

Tonghui TH2618B Operation manual

Tenmars

Tenmars TM-801 user manual

MSR

MSR 145 user manual

TPS

TPS WP-82 manual

ELMETRON

ELMETRON CP-511 user manual

PCB Piezotronics

PCB Piezotronics 003C30 Installation and operating manual

Tenma

Tenma 72-10465 manual

Endress+Hauser

Endress+Hauser Proline Promag 50 Brief operating instructions

Siemens

Siemens SITRANS F Coriolis FCT030 Function manual

KLINGER

KLINGER CMF V Series instruction manual

EXFO

EXFO FTB-2 Notice

Keysight

Keysight M8290A Getting started guide

ADTEK

ADTEK MW-5 operating manual
