SYNACORP i-Copy V300CD-PRO User manual
_____________________________________________________________________________________
RFID Copier Duplicator i-Copy V300CD-PRO
Introduction:
Easily duplicate your access card or key FOB with this Handheld V300CD-PRO. Manual
key input supported so that you can manually input the serial number if you do not have the
physical access to the card / tag.
Features:
2.9-Inch HD full color LCD display, multilingual English & Chinese.
Supported frequency 125KHz, 250KHz, 375KHz, 500KHz, 625KHz, 750KHz, 875KHz, 1000
KHz & 13.56MHz.
Comes with keypad for easy manual card/tag number input.
Can use with battery (4pcs AAA Battery) or with 5v Micro USB power input sources
(Compatible with 5v phone charger, Power bank, PC etc.).
Buzzer indicator for operation.
PC Software included for more advance features.
_____________________________________________________________________________________
Device Overview
Navigation Keys
Select Key
Cancel / Clear Input Key
Write Card
Number Input
Power On/Off
Back / Return
Read Card
Auto Scan Card
Change Frequency
RFID Scanner Area
Buzzer
Micro USB Port
Battery Holder
4XAAA
_____________________________________________________________________________________
Procedures:
A. How to copy the RFID cards /tags:
1. Press the "ON/OFF" button and accept the Disclaimer term menu by click on ‘OK’key.
2. Place the original cards on the back of the Device. Make sure to place it on the Scanner
area.
3. Press the “SCAN" key, the Device will enter scanning mode. It will display the card type
and the card ID/UID if success.
4. Once the ID/UID and Card type displayed, swap the original card with the copy card / tag
on the scanner area.
5. Press the “Write" key to initiate the Duplicate / Cloning process. Once the process
completed the it will display “write the card successfully!”.
6. Once cloned both card should have same ID/UID when scanned.
B. Connecting Device with PC with provided software (Windows).
1. Connect the device with PC via provided Micro USB cable. Press ‘ON/OFF’ key and stay
on the Disclaimer menu, do not press the ‘OK’ key yet.
2. The device will only enter U-Disk mode when user connect it to PC and stay on
Disclaimer menu.
3. On your PC, open My Computer / This PC to access the U-Disk storage device.
4. Inside the drive run the NFC PM-ProEnInstall.exe to install the program. Once installed
new shortcut will displayed on your Desktop named NFC PM-ProEnV1.1.exe, launch the
program.
5. Press the ‘OK’ to close the Disclaimer menu and a pop-up window will display “USB
Connected…” on the Device. This indicate that the Device successfully connected to PC.
