Sureshotlaser PINLOC 2000 User manual
PINLOC
2000
USER MANUAL
VERSION 1.2
USER MANUAL PINLOC 20002
PINLOC
2000
Congratulations on purchasing the sureshotlaser PINLOC
2000. This product is a superior portable golf rangefinder
that enables you to Know the Distance. Please read the
following information in this booklet to ensure you get
the most out of your PINLOC 2000.
CONTENTS OF BOX
• sureshotlaser PINLOC 2000
• Deluxe carry pouch
• Instruction Manual
• Lens cloth
• Lithium ion battery
To begin using your SureshotLaser, please insert the Lithium
battery as shown on the unit.
USER MANUAL PINLOC 20003
PINLOC
2000
1 Getting to know your SureshotLaser....................... 4
1.1 Main functions .............................................................. 4
2 Registration................................................................ 5
3 Starting your PINLOC 2000....................................... 5
4 Adjusting the focus.................................................... 6
5 How to find the distance........................................... 7
6 Built in intelligence .................................................... 8
6.1 Priority Loc ................................................................... 8
6.2 PINLOC ........................................................................ 8
6.3 Display Loc................................................................... 8
6.4 Scanner........................................................................ 9
7 Unit measurement change........................................ 9
8 Automatic Power-Save............................................ 10
9 Battery Indicator ...................................................... 10
10 Accuracy................................................................... 10
11 How to clean your PINLOC 2000............................ 11
12 Important Advice ..................................................... 11
13 Specifications .......................................................... 12
14 Warranty information............................................... 13
15 Declaration of Conformity ..................................... 16
16 Website Information ................................................ 17
USER MANUAL PINLOC 20004
PINLOC
2000
1. GETTING TO KNOW YOUR SURESHOTLASER
1.1 Main function
LASER
RECEIVING
TUBE
ADJUSTABLE
EYEPIECE
(DIOPTRE)
BATTERY
HOUSE
POWER BUTTON
MODE BUTTON
MONOCULAR
OBJECTIVE / LASER
EMISSION TUBE
USER MANUAL PINLOC 20005
PINLOC
2000
2. REGISTRATION
It is important to register your SureshotLaser within 14 days
of purchase to activate your warranty. Register your SureshotLaser
online at www.sureshotgps.com > Select mysureshotgps >
Register > Register sureshotlaser, for free technical support
and product updates. You will need the serial number found
underneath your PINLOC 2000 and on the packaging.
3. STARTING YOUR PINLOC 2000
The PINLOC 2000 has two buttons: the power button and
the mode button “MODE”. To turn on, press the power button
for one second, the PINLOC 2000 will power on.
USER MANUAL PINLOC 20006
PINLOC
2000
4. ADJUSTING THE FOCUS
The SureshotLaser is designed with an adjustable eyepiece
(dioptre). By adjusting the focusing dioptre within a –5 to +5
range, people with far sighted or near sighted vision can use
the SureshotLaser without glasses. Looking through the
eyepiece, turn the dioptre left or right until the view is focused
with clarity to suit you.
Other model shown
USER MANUAL PINLOC 20007
PINLOC
2000
5. HOW TO FIND THE DISTANCE
Hold the SureshotLaser to your eye and depress the Power
Button once to turn on. The LCD display will now show three
lines and a small rectangular box. Line the target up so it appears
inside the rectangular box, then depress the Power Button once.
The distance from you to the target will be displayed on the
screen instantly.
DISTANCE LOCKED IN
258
USER MANUAL PINLOC 20008
PINLOC
2000
6. BUILT IN INTELLIGENCE
SureshotLaser has highly intelligent software built in to provide
accuracy and confidence in every distance.
6.1 PRIORITY LOC
SureshotLaser instinctively locks into the nearest target, which may
be the smallest among multiple objects in the background giving
you shot confidence every time. Priority Loc intelligence delivers
the first and closest target by scanning the area and displaying
only the nearest distance. This feature automatically delivers by
depressing the Power Button once quickly.
6.2 PINLOC
PINLOC technology ensures even the smallest target is locked
in from the longest distance. This is important for delivering pinpoint
distances. This feature is automatically delivered when the Power
Button is depressed quickly once.
6.3 DISPLAY LOC
Each time the Power Button is depressed quickly once,
the distance is displayed on screen to be reviewed again.
After 30 seconds the screen automatically switches off.
USER MANUAL PINLOC 20009
PINLOC
2000
6.4 SCANNER
The Scanner feature displays a continuous update of distances
to various targets across a panoramic area. To use the Scanner,
hold the Power Button down and scan across the target area.
Once complete, release your finger and resume using the
SureshotLaser as usual.
7. UNIT MEASUREMENT CHANGE
This PINLOC 2000 can be used to measure distances in metres
or yards. Press the “MODE” button to change the unit display.
(See below)
258258
USER MANUAL PINLOC 200010
PINLOC
2000
8. AUTOMATIC POWER-SAVE
The PINLOC 2000 will automatically switch off in 10 seconds
without operation.
9. BATTERY INDICATOR
A battery level warning will appear when battery is running low.
The battery will last approximately 3000 actuations. The battery can
be replaced by removing the battery housing (see diagram on page
2). Any generic brand BCR2-3V lithium battery can be used.
10. ACCURACY
The PINLOC 2000 delivers incredible accuracy at +1 or -1 metre.
The range is dependent on the reflectivity of the target. The colour,
surface, shape and size of the target will affect reflectivity and the
range. For example, red is highly reflective and will give longer range
as opposed to black which is the least reflective colour. A shiny
surface will also provide more range than a dull one and likewise,
a small target is more difficult to range than a large target.
The angle to which you set your target also affects accuracy.
A 90 degree angle will give you good range while a steep angle will
provide limited range. Please note lighting can also affect accuracy
levels, the less light the further the unit’s maximum range.
