Speco INTENSIFIER HTINTB8 User manual
Intensifier™Series
Cameras
HTINTB8/9/10
Please read this manual throughly before operation and keep
it handy for further reference.
2
CONTENTS
Camera Set Up P33
How to Install P34
MOTION DET. P23
Package Contents P3
Precautions P4
O S D Menu P5
Operating Your Camera P6
MENU SET UP P6
LENS SET UP P7
SHUTTER SPEED P9
MANUAL P10
E L C P11
B L C P12
A
G C P13
WHITE BAL. P14
S L C P16
INTENSIFIER P17
NEXT P18
CAMERA TITLE P19
C O L O R P21
S Y N C P22
PRIVACY P25
REVERSE P27
DETAIL P28
Troubleshooting P30
Specification P32
Warranty P35
3
Please make up sure that the following items are
included in the package:
1 HT - INTB CAMERA
PACKAGE CONTENTS
4 MOUNTING SCREW
1 MOUNTING BASE
1 SUNSHIELD
1 USER'S MANUAL
1 L - WRENCH
1 VIDEO TEST CABLE
1 POWER PIGTAIL
1 HT - INTB8 CAMERA
4
TO PREVENT A FIRE OR ELECTRONICAL HAZARD PLEASE
USE PROPER POWER CABLE
PLEASE USE A UL APPROVED REGULATED 24 VOLT AC
OR 12 VOLT DC POWER SUPPLY
PLEASE USE APPROPRIATE LOW VOLTAGE POWER
CABLE TO PREVENT FIRE OR ELECTRICAL SHOCK.
INSTALLATION SHOULD BE PERFORMED BY QUALIFIED
PERSONNEL
PLEASE INSURE THAT YOUR INSTALLATION AREA CAN
SUPPORT THE WEIGHT OF THE CAMERA
PLEASE HANDLE THIS CAMERA CAREFULLY:
- DON'T USE A STRONG OR ABRASIVE DETERGENT WHEN
CLEANING THE CAMERA.
- USE A SOFT TISSUE OR LENS CLOTH TO CLEAN THE
FRONT GLASS.
- DON'T EXPOSE THE CAMERA TO DIRECT SUN
PRECAUTIONS
5
◈ Function
SET UP MENU LENS OPTION
●DC ●MANUAL
SHUTTER
●OFF ●F/L ●MANUAL
WHITE BALANCE
●ATW ●AWC ●MANUAL
SLC - ( Speco Light Compensation )
●OFF ●LOW ●MIDDLE ●HIGH
A
UTO GAIN
●OFF ●LOW ●MIDDLE ●HIGH
REDUCE NOISE
●OFF ●LOW ●MIDDLE ●HIGH
INTENSIFIER
●AUTO ●OFF
NEXT PAGE
●CAMERA TITLE ●DAY/ NIGHT ●SYNC
●MOTION ●PRIVACY ●REVERSE
●DETAIL ●DEFAULT ●PAGE1
EXIT
OSD MENU
6
MENU SET UP
SPECO TECH
LENS TYPE DC IRIS
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
Menu is adjusted by the OSD button on the camera
1. Press the SET button to access the SETUP mode.
●SETUP menu should be displayed on the monitor screen.
2. Select the desired feature using the UP or DOWN buttons
●Move the arrow indicator UP or Down to indicate onto desired feature
by pressing the UP or Down button.
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
Select
desired
Changr the adjustment
By Left or Right Button
MANUAL : Manual Lens
7
CAUTION
A
ccess to submenu by moving arrow to desired feature
A
ccess is not available to submenu on the mode o
f
" -----".
3. MENU SETUP change by using button
●Available value or status should be displayed by pressing the Left or Right button.
●Please press the button until desired features appears.
4. When adjustment is completed, move the arrow indicator to " EXIT " and press the
"SET" button.
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED ELC
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
LENS SETUP
Select the lens by pressing the RIGHT button
1. Move the arrow indicator to " LENS " by UP or Down button on the
SETUP menu.
DC / VIDEO : DC Auto IRIS Lens
MANUAL : Manual Lens
8
2. Select the desired lens type by LEFT or RIGHT button.
SPECO TECH
LENS TYPE DC IRIS
SHUTTER SPEED ELC
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
CAUTION
You can control the brightness when DC is selected, Brightness control range will be 1~70.
LENS
BRIGHTNESS 1--------1---------1 35
Press Set to Return
CAUTION
Color mode is not available when AGC OFF
LENS SETUP
OFF : Deactivation
FLK (1/100):Flicker mode
9
SHUTTER SPEED CONTROL
SPECO TECH
LENS TYPE DC LENS
SHUTTER SPEED
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
SPECO TECH
LENS TYPE MANUAL
SHUTTER SPEED MANUAL
WHITE BAL ATW
SLC HIGH
AUTO GAIN OFF
REDUCE NOISE -----
INTENSIFIER -----
NEXT PAGE
EXIT
You can control brightness of screen by the shutter speed.
①Press the SET button to display the setup menu and move the arrow
indicator to " SHUTTER " by the UP or DOWN button.
②Set " SHUTTER " to the desired mode by the LEFT or RIGHT button
