SOLTEK 85ERV User manual

85ERV / 85ERV-L

Contents

Chapter 1 Specification ............................................. 9

1-1 85ERV / 85ERV-L Components and Options ................... 10

1-2 Mainboard Specifications ..................................................... 11

1-2.1 CPU Socket ................................................................................... 11

1-2.2 System Chipsets ........................................................................... 11

1-2.3 Memory ......................................................................................... 11

1-2.4 AMI BIOS ..................................................................................... 11

1-2.5 Accelerated Graphics Port (AGP) Interface........................... 11

1-2.6 Advanced System Power Management ................................... 12

1-2.7 Multi-I/O Functions .................................................................. 12

1-2.8 Expansion Slots ............................................................................ 12

1-2.9 AC’97 Audio Codec on board .................................................... 13

1-2.10 LAN on board (85ERV-L only) ............................................... 13

1-2.11 Hardware Monitor on board ................................................... 13

1-2.12 6-channel Sound Output Support (optional) ........................ 13

1-2.13 Form Factor................................................................................ 13

1-3 Mainboard Specification Table ........................................... 14

1-4 Chipset System Block Diagram........................................... 15

Chapter 2 Hardware Setup..................................... 16

2-1 CPU Installation with Socket 478B .................................... 17

2-2 Pentium 4 CPU Fan Installation ......................................... 18

2-3 Memory Installation with Warning LED .......................... 19

2-3.1 To Install DDR SDRAM Module for this series ..................... 19

2-3.2 To Remove a DIMM .................................................................... 19

2-4 AGP 4X/8X Slot Installation ................................................ 20

2-5 IDE Connector Installation ................................................. 21

Contents

2-6 Flopy Drive Connector ( FDC ) Installation .................... 22

2-7 ATX V 2.03 Power Supply Installation .............................. 23

2-8 Jumper Settings ..................................................................... 24

2-8.1 Jp1 CPU Clock/Overclock Select ............................................ 25

2-8.2 JBAT1 Clear CMOS .................................................................. 26

2-8.3 Jp2 Flash ROM Write Protection ........................................... 27

2-9 Other Connectors Configuration........................................ 28

2-9.1 On-board FAN Connectors ........................................................ 28

2-9.2 Connector WOL1 Wake On LAN............................................ 29

2-9.3 CD-ROM Audio Connector (CD1) ........................................... 29

2-9.4 Audio 1 6-channel Sound Output Connector (optional) ..... 30

2-9.5 Chassis Panel Connectors .......................................................... 30

2-9.6 RJ45 LAN Connector ( 85ERV-L only) .................................. 31

2-9.7 PS/2 Mouse And PS/2 Keyboard ............................................... 31

2-9.8 Thermal Sensor Connectors RT1 and RT2 ............................. 32

2-9.9 Complex Pin-header.................................................................... 33

2-9.10 USB Ports and USB Pin Headers............................................ 35

2-10 IRQ Description................................................................... 36

Chapter 3 Software Setup ....................................... 38

3-1 Open Up Suport CD ............................................................ 39

3-2 Proceed to VIA 4-IN-1 Drivers Installation ...................... 40

3-3 AC’97 Audio Driver Installation......................................... 42

3-4 Install USB 2.0 Driver for Win98 / Me / 2000 / XP.......... 43

3-5 Install Hardware Monitor Utility ....................................... 45

3-5.1 Installation ................................................................................... 45

3-5.2 Verification .................................................................................. 46

3-6 Install VIA LAN Drivers (for 85ERV-L only) ................. 47

85ERV / 85ERV-L

3-6-1. VIA6183 LAN driver on Windows 9X .................................... 47

3-6-2. VIA6183 LAN driver on Windows NT4.0 .............................. 49

3-6-3. VIA6183 LAN driver on Win ME / 2000 / XP ....................... 50

Chapter 4 AMI BIOS Setup.................................... 52

4-1 About BIOS Setup ................................................................. 53

4-2 To Run BIOS Setup ............................................................... 53

4-3 About CMOS .......................................................................... 53

4-4 The POST ( Power On Self Test ) ....................................... 53

4-5 To Update BIOS ..................................................................... 54

4-6 BIOS SETUP --- CMOS Setup Utility................................ 56

4-6.1 CMOS Setup Utility .................................................................... 56

4-6.2 Standard CMOS Setup ............................................................... 57

4-6.3 Advanced BIOS Features ........................................................... 60

4-6.4 Advanced Chipset Features ....................................................... 63

4-6.5 Power Management Features .................................................... 66

4-6.6 PNP / PCI Configurations .......................................................... 69

4-6.7 Integrated Peripherals................................................................ 71

4-6.8 Hardware Monitor Status .......................................................... 74

4-6.9 Frequency/Voltage Control ....................................................... 76

4-6.10 Set Supervisor Password .......................................................... 78

4-6.11 Load Optimized Defaults ........................................................ 80

4-6.12 Save & Exit Setup...................................................................... 80

4-6.13 Exit Without Saving .................................................................. 80

Chapter 1 Specification

Topics i cluded i this chapter are:

1-1 Mai board Compo e ts Locatio s

1-2 Mai board Specificatio s

1-3 Mai board Specificatio Table

1-4 Chipset Diagram

I troductio

Chapter 1 Specification

This series of mainboards features an integration of the powerful

processor Intel Pentium 4 and the single-chip North Bridge VIA Apollo

P4X400 plus South Bridge VT8235, by which the whole system perfor-

mance can be upgraded to 533 MHz system bus.

The Intel P4 processor is a rapid execution engine providing 4X100/

4X133MHz quadpumped system bus to allow 3.2GB data transfer rates

possible, while VIA Apollo P4X400 plus VT8235 supports Intel P4 pro-

cessor to implement the 4X133 Front Side Bus, AGP 8X external bus,

the LPC Super I/O, the DDR SDRAM and UATA 133/100/66 data trans-

fer rate. This chapter is to introduce to users every advanced function

of this high performance integration.

85ERV / 85ERV-L

DIMM 3

DIMM 1

DIMM2

PCI 1

PCI 2

PCI 3

PCI 4

PCI 5

PCI 6

FLASH BIOS

Battery

Peripheral Power

Conne tor

+12 Power

Conne tor

Main Power

Conne tor

VIA

P4x400

VIA

VT8235

mPGA478B

IDE2

IDE1

FDC1

1 3

FAN2

FAN1

FAN3

FAN4

IT8705F

LPC I/O

LPT1

COM1

MIC

GAME/MIDI PORT

LINE

OUT

LINE

PS/2 K/B¤

(underside)

PS/2 Mouse

(on top)

USB1 (underside)

USB0 (middle)

Rj 45

(on top)

AC'97

Code

JUSB2

JUSB1

10 SCR1

AUDIO1

AGP 4X/8X

WOL1

RT1

RT2

JP1

JBAT1

JP2

SAPK RST PLED SLED

HDD/LED IR PWR SMI

VIA VT6103

PHY (LAN Controller)

CD1

COM2

Audio Code

DDR 333/266/200

1-1 85ERV / 85ERV-L Compo e ts a d Optio s

RJ45

PHY LAN Controller for 85ERV-L o ly

}

Optio al 6-cha el Audio-Out Co ector

Chapter 1 Specification

1-2.1 CPU Socket

CPU Socket 478B on board, supporting Intel® Pentium 4 processors in

478-pin package for :

-- 533/400MHz System Bus;

-- Hyper-pipelined technology;

-- Advanced dynamic execution;

-- Advanced transfer cache;

1-2.2 System Chipsets

• North Bridge VIA P4X400 for managing and supporting 4X133/

4X100MHz system Bus, DDR 333/266/200 SDRAM memory interface,

Hub interface and AGP4X/8X interface.

• South Bridge VIA VT8235 working with North Bridge supporting the

double speed V-Link, LPC Super I/O, upstream Hub interface, PCI

interface, IDE interface, LAN interface, USB V2.0 interface, as well

as AC’97 Audio 6-channel interface.

1-2.3 Memory

3 DDR DIMM 184-pin slots on board for DDR 333/266/200 SDRAMs :

• Supporting unregistered, non-ECC DDR333/266/200 SDRAM up to

3 GBs

• Supporting installation of mixed volumes yet same type of DDR

SDRAM modules

1-2.4 AMI BIOS

• Supporting Plug & Play V1.0

• Flash Memory for easy upgrade

• Supporting BIOS Writing Protection and Year 2000 compliant

• Supporting BIOS Setup (See Chapter 4 BIOS Setup)

1-2 Mai board Specificatio s

1-2.5 Accelerated Graphics Port (AGP) I terface

AGP Controller embedded on board, supporting:

• 1.5V(4X/8X) power mode only, 1 AGP Slot supported

• 4x AD and SBA signaling, AGP pipelined split-transection longburst

transfers up to 2GB/sec.

• AGP 4X/8X only, AGP v3.0 compliant

85ERV / 85ERV-L

1-2.7 Multi-I/O Fu ctio s :

• PCI EIDE Controller, supporting:

-- 2x Ultra ATA133 / 100 / 66 IDE connectors supporting up to 4 IDE

devices

• Dedicated IR Functions:

-- Third serial port dedicated to IR function either through the two

complete serial ports or the third dedicated port Infrared-IrDA (HPSIR)

and ASK (Amplitude Shift Keyed) IR

• Multi-mode parallel data transfer:

-- Standard mode, high speed mode ECP and enhanced mode EPP

• Floppy Disk connector:

-- One FDD connector supporting 2 floppy drives with drive swap support

• Universal Serial Bus Transfer Mode:

-- USB V2.0 compliant, 480 Mb/s USB Bus, supporting Win 2000 and later

operating system; USB drivers provided in Support CD for installation

-- 2 built-in USB connectors and 2 USB pin-headers which require 2 op-

tional USB cables to provide 4 more optional USB ports

• PS/2 Keyboard and PS/2 Mouse

• UARTs (Universal Asynchronous Receiver / Transmitter):

-- Two complete serial ports (COM1 & COM2) on board

1-2.8 Expa sio Slots

• 6 PCI bus Master slots

• 1 AGP 4X/8X slot

• 3 DDR DIMM slots

1-2.6 Adva ced System Power Ma ageme t:

• ACPI 1.0B compliant (Advanced Configuration and Power Interface)

• APM V1.2 compliant (Legacy Power Management)

• ACPI POS (Power On Suspend)

• PS/2 Keyboard & Mouse Power On

• Supporting Ring Power Up Control for Wake-on-Modem (external)

and Wake-on-LAN (via Connector WOL1)

• Real Time Clock (RTC) with date alarm, month alarm, and century

field

Chapter 1 Specification

1-2.9 AC’97 Audio Codec o board

AC’97 Audio Codec 2.2 compliant on board

1-2.10 LAN o board (85ERV-L o ly)

Fast Ethernet Controller integrated in VT8235 and PHY VIA VT6103:

• Supporting 10/100Mb Fast Ethernet Base T LAN

• Supporting Wake On LAN through on-board WOL1 connector

• LAN Driver enclosed in Support CD for user’s installation.

• Supporting up to 6 channels of PCM audio output

• 6 channel audio consists of Front Left, Front Right, Back Left, Back

Right, Center and Woofer for complete surrround sound effect

• AC’97 Audio Codec Driver enclosed in Support CD for user’s

installation.

1-2.11 Hardware Mo itor o board

• Hardware Monitor integrated in Super I/O IT8705F, providing moni-

toring and alarm for flexible desktop management of hardware voltage,

temperatures and fan speeds.

• Utility Software SmartGuardian for displaying Monitoring status is

enclosed in Support CD for user’s installation.

1-2.13 Form Factor

• ATX form factor, ATX power supply, version 2.03 compliant, supported

by one Main Power Connector, one +12V Power Connector and one

Peripheral Power Connector

• Mainboard size: 305mm x 220mm

1-2.12 6-cha el Sou d Output Support (optio al)

• This series is designed with an optional 6-channel Audio-out connec-

tor Audio1”. If this option is chosen, it will provide 3 additional audio-

out ports for the 6-channel sound.

85ERV / 85ERV-L

1-3 Mai board Specificatio Table

CPU

North Bridge

South Bridge

BIOS

Memory

I/O Chip

AGP interface

Audio

IDE Interface

Networking

PCI Slots

I/O Connectors

VGA Display

Other Features

Socket 478B for Intel Pentium 4 CPUs

VIA Apollo P4X400, supporting 533/400MHz FSB

VIA VT8235

AwardBIOS

Supporting DDR 333/266/200 SDRM, up to 3GB

in 3 DDR DIMM slots

IT8705F

1.5V AGP4X/8X mode only

AC’97 Audio V2.2 compliant, 6-channel interface

2 UATA 66/100/133 IDE ports

VIA LAN Controller, 1xRj45 (85ERV-L only)

6 PCI Master slots on board

6xUSB ports (V2.0), 1xFDD port, 2xCOM ports,

1xLPT, 1xIrDA, 1xPS/2 K/B, 1xPS/2 Mouse,

VGA not integrated on board

BIOS Writing Protection;

Hardware Monitoring in IT8705F

keyboard Power On;

ATX 2.03 Power Supply;

ATX form factor

SL-85ERV / 85ERV-L Specificatio s a d Features

Chapter 1 Specification

1-4 Chipset System Block Diagram

Intel Pentium 4 + VIA P4X400 + VIA VT8235 Diagram

Pentium 4

DDR

DDR 333/266/200

UATA66/100/133

PS/2 eyboard

PCI Bus

P4x400

North Bridge

CPU

AGP

Slot

533/400 MHz FSB

SM Bus

LPC

Double Speed (533MB/sec) V-Lin

Super I/O

Serial / IR

Parallel

Floppy Drive

6 PCI Slots

478-pin package

Game Port

H/W Monitor

BIOS

VT8235

South Bridge

Intel

AGP 4X/8X Bus

SDRAMs

6x USBs V2.0

AC'97 Audio (6-channel)

PS/2 Mouse

VIA

MII

PHY(VT6103)

10/100 Base T LAN

(85ERV-L only)

Memory Bus

Fast Ethernet Interface

This manual suits for next models

Table of contents

Other SOLTEK Motherboard manuals

Popular Motherboard manuals by other brands

DFI

DFI SD170 user manual

ASROCK

ASROCK ROMED8-2T user manual

Asus

Asus P2L97A user manual

Winmate

Winmate IC70 user manual

Asus

Asus MES-B user manual

Grantech

Grantech SYS8F377VGGA-3OMN user manual

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR user guide

Gigabyte

Gigabyte GA-9IVDT user manual

Texas Instruments

Texas Instruments ADS8372EVM user guide

Commell

Commell MS-C73 user manual

IBT Technologies

IBT Technologies MB860 user manual

Nvidia

Nvidia TEGRA DG-04927-001_V01 user guide

Biostar

Biostar M7VIT Bravo Description

Intel

Intel D33217CK specification

Asus

Asus F1A55-M LX PLUS R2.0 user manual

EPC

EPC EPC9147C quick start guide

Asus

Asus EX-B760M-V5 D4 quick start guide

EPOX

EPOX MU-8KHA0010 user manual
