FittingKit

K455

GB

Fitting Instructions for Basic Carrier

x 4

x 4

1

Revision No:

1.3

FittingKit

K455

GB

MAX kg

MAX kg

W/P

WHD

W/P

WHD

Land Rover

Freelander 2, 5dr SUV 07-+

60

60

ZA

Freelander 2, 5dr SUV 07-+

60

60

US

Freelander 2, 5dr SUV 07-+

60

60

EU

Freelander 2, 5dr SUV 07-+

60

60

NZ

Freelander 2, 5dr SUV 07-+

60

60

AU

2

FittingKit

K455

GB

First Time Installation

Remove parts from packaging and check

contents. Contact your Prorack dealer if parts

are missing or damaged.

This kit fits type A, B, C and D.

These instructions show type A crossbar

fitted. They also apply to type B, C and D.

NOTE: Clamp images in these instructions may

not be representative of the clamps in this kit

3

FittingKit

K455

GB

Use keys to remove covers.

Use hex screwdriver to reverse adjusting

screw 10 turns.

Press adjusting screw and pull crossbar legs

out. Refer to the crossbar instructions for

crossbar adjustment.

Ensure each end of the crossbar is adjusted

equally.

4

FittingKit

K455

GB

Remove locking screw.

Apply protective strip as shown.

Trim if required.

A= Clamp

B= Roof line

C= Body rubber

D= Protective strip

Attach clamp to each leg. NOTE; clamps

may have labels showing their positions on

the vehicle (For example; "Front Right").

5

FittingKit

K455

GB

Refit locking screw so that it goes through

the hole in the clamp. Do not begin to tighten

the locking screw.

Fit rubber pad (supplied with crossbar) to foot.

Make sure the pad fits into the holes

underneath the foot.

6

FittingKit

K455

GB

Fitment

Place crossbar on vehicle. Minimum

recommended spacing between the bars is

700mm (unless otherwise stated).

Clamps over rubber door frame mouldings.

Please check the rear of this manual for

information relating specifically to your

vehicle.

Adjust the legs on the crossbar so that they

are positioned equally from the ends of the

crossbar, and the clamps engage firmly on

the body work of the vehicle.

Tighten adjusting screw to 5 Nm.

7

FittingKit

K455

GB

Tighten locking screw on both legs evenly.

Final clamp position when tight.

Just touching point A

Pressure applied point B

Check crossbar is securely attached to the

vehicle.

8

FittingKit

K455

GB

Use keys to fit and lock covers

CAUTION:

Recheck all fasteners immediately after a load is

applied to the crossbars.

Regularly check screws are tight.

9

FittingKit

K455

GB

Maintenance

Clean the car roof and surfaces of the

product that will be in contact with the car

roof.

Follow the fitting instructions for fitting the

product to your vehicle. Make sure all steps

are carried out in order.

Set crossbars a minimum distance of 700mm

apart where no other distance is specified in

the fitting instructions. This is especially

important when carrying long loads.

Check unit is securely attached whenever

you refit it to the vehicle. If the unit feels

loose, refer to the fitting instructions and

readjust.

Some sunroofs and radio antennae cannot

be used when the product is fitted.

Do not modify this product.

Refer to the maximum permitted load

capacity specified in the fitting instructions.

Do not exceed the vehicle manufacturers

roof load rating if it is lower than the

maximum load capacity specified in the fitting

instructions.

Loads should not overhang the sides of the

product and be evenly distributed with the

lowest possible centre of gravity.

Long loads should be secured with non-

elastic straps to the front and rear of the

vehicle.

Objects with pointed ends (skis) should be

carried with the pointed ends to the rear of

the vehicle.

Remove all loose or removable objects from

the load prior to loading.

Make sure all loads are securely fastened

with non-elastic straps. Check regularly

during longer journeys.

10
