PROAIM P-WV-2SD User manual
7’ WAVE-2 VIDEO JIB CRANE With CST-
100 Stand & portable Dolly
(P-WV-2SD)
All rights reserved
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any
means, electronic, mechanical, photocopying, recording, or otherwise, except as may be expressly permied
by the applicable copyright statutes or in wring by the publisher.
I N S TR UC T I O N M A N UA L
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 2
INTRODUCTION
PROAIM welcomes you to the new and modernized era with its Proaim 7' Wave-2 Video Jib Crane
With CST-100 Stand & Portable Dolly , a portable lming soluon to increase your producon
value. The Robust jib crane is specically designed travel crane for indoor & outdoor video pro-
ducons. Its telescopic armfeature adds exibility to frame perfect shots in indoor and outdoor
spaces. This video producon package includes a rugged camera dolly for smooth, dynamic
moving shots and rock solid aluminum tripod stand for immense support. Now you can create
the visual eects and produce incredibly smooth oang camera crane shots that add value to
your lming producons and bring a quick return on your investment.
IN THE BOX
Please inspect the contents of your shipped package to ensure you have received all that is
pictured and listed below. The padded shipping /storage container has been especially designed
to protect your purchase while in transit and is a good place to keep your PROAIM 7' Wave-2
Video Jib Crane with CST-100 Stand and portable Dolly when not in use.
Bag Packing
Wave-2 video crane jib
75mm bowl
Weight shank
CST-100mm Bowl tripod stand
Portable Dolly
Allen key
Red Spreader
CONTENTS OF SHIPPING BOX
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 3
Posion the height of the tripod by loosening all three adjustment knobs, sliding the tripod
up to the desired height and re-ghten the knobs securely.
Now, place the tripod foot on the
spreader and e down it with the help of
elasc clip downs as shown in the
picture.
Take out the spreader and open it’s legs as shown in the image.
ASSEMBLING YOUR PROAIM 7' WAVE JIB WITH 100MM TRIPOD STAND AND
SPREADER
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 4
Provided are the jib panning control
knobs (as shown in the picture). Loosen
the knobs for the smooth pan
movement of the jib and ghten these
knobs to lock the pan movement of the
jib.
NOTE: Inbuilt bubble leveler is also
provided to check accurate set-up of jib
on uneven surface areas.
NOTE: It is important to make sure that the Central Fork is seated in the bowl properly. That
means perpendicular to the tripod bowl. O axis installaon may hamper movement of the jib.
Also you may need the assistance of a grip stand to hold the camera end of the arm during
installaon prevenng it from falling as it will be front heavy at this point. You may also need
the grip stand or assistance at the rear of the jib when mounng the camera.
Now to extend the rear secon of the jib, loosen the Allen bolts with the provided Allen key
and then, loosen the knob as shown in the picture.
Unscrew the locking lever from the Central Post of the jib. Place the Central Post in the
bowl of Tripod Stand and re-ghten the locking mechanism for a secure t. (as shown in
the picture.)
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 5
Aach the weight shanks at the rear end of
the jib secon by screwing it in and then add
weights to it.
NOTE: Make sure the opposite end of the jib arm
is secured so that the addion of the weights
does not cause the arm to rise violently.
Camera head mount is provided with a knob
to control 90 degree lt movement of the
camera.
Loosen the knob for the free lt movement
of the camera and ghten it to lock the
movement.
Then, loosen the knob provided at the lower
telescopic secon of the jib arm as shown in
the picture to extend the front secon of the
telescopic jib accordingly to the rear secon.
Mount your uid head onto the bowl plate in order to aach the camera. And then nally,
secure your camera properly on the uid Head.
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 6
YOUR PROAIM 7’ WAVE DSLR VIDEO JIB ARM WITH TRIPOD STAND
ALL SET AND READY TO USE
NOTE: Add weights to the rear of jib corresponding to the weight of camera aached to
balance the jib arm.
(SHOWN WITH OTPIONAL ACCESSORIES)
Take out the bolt from the center of dolly and spread it on oor. Then put the bolt back
through the center of dolly again.
ASSEMBLING YOUR PROAIM 7' WAVE -2 JIB WITH CST-100 STAND, PORTABLE
DOLLY
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 7
Posion the height of the tripod by loosening all three adjustment knobs, sliding the tripod
up to the desired height and re-ghten the knobs securely.
Now, place the tripod foot on the dolly
and e down it with the help of elasc
clip downs as shown in the picture.
WARRANTY
We oer a one year warranty for our products from the date of purchase.
We will repair or replace your product, free of charge, in the event of a defect in materials or
crasmanship obtained during normal use or handling based on the user manual. Please note
that we will not cover any shipping costs for returning the product to us. If any VAT or import
dues are applied to the return, we will also charge these costs to the customer.
The warranty does not include, by the way of example, damage caused by products that we do
not supply or from mishandling in transit, accident, misuse, neglect, lack of care of the product ,
or service by anyone other than our company.
We are not liable for incidental or consequenal damages resulng from the use of the unit or
occurring due to any breach of this warranty.
Replacement parts of the product will be provided at nominal cost (covering the cost price of the
replacement parts only) to the customers aer the Warranty Period has expired. We will cover
Proaim 7’ WAVE-2 VIDEO JIB CRANE With CST-100 Stand & portable Dolly 8
the complete cost of sending replacement parts within the warranty period. Aer that, Nominal
cost of the product & Actual shipping cost will be charged.
Do not send the unit to us without rst geng a response and geng the approval to send back
the item.
In case of any kind of dissasfacon, we urge you to Contact us immediately and we shall do our
Best to help you out. For any other assistance you can reach us via email.
For any other assistance you can reach us via email.
