PROAIM TP-ULTM-01 User manual
1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Ultra Modular Teleprompter (TP-ULTM-01)
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Collapsible hood Beam Splier Glass
Quick Release
I -Pad Plaorm
Vesa Mount
Upper Spacer
Hood Spacer
Adjustable Arms
4 x Knobs
2x Cleaning Cloth
2
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Female Mounng rods
4 x bush
Spacer
Hand Gloves
Side Flaps
Male Mounng rods
Belt
L-type (Size:7/32mm)
T-type (Size:4mm)
Bag Packing
Glass protecve Case
• Remove the plate from tripod.
Ultra Modular Teleprompter Setup
3
• Aach universal base plate to the Quick release and
secure it with the help of screw driver.
• Here is the quick release ready to be mount
on tripod.
• Slide quick release while Press the buon to
mount it on tripod and loose all four cornered
knobs of quick release.
• Now add Female mounng rods to the quick
release plate.
• Now mount Hood Spacer on the rods then
secure it by use screw allen key.
4
• Here is hood spacre aached
• Loose the knobs of I-pad plaorm
• Now latch the I-pad plaorm to the hood
spacer.
• Now secure it by ghten the knobs back
again.
• Loose both the knobs which is in the boom
of I-pad plaorm.
• Extend the I-pad holder the ght knob to
secure it.
5
• Now mount spacer to the other end of rods
then secure it by using screw and allen key.
• Here is the spacer aached.
• Now aach male mounng rods on hood
spacer.
• Here is male mounng rods aached.
• Open collapsible hood .
• Now past it on Velcro tape to provide the
collapsible hood a shape.
6
• Loose both the knobs which is on the back of
hood.
• Close tha buckles and ght it.
• Now mount Upper spacer on male rods and
ght the knobs then add screw on rods.
• Lose the middle knob of quick release and
remove camera plate while pressing buon.
• The hood would look like this aer pasng all
Velcro tape.
• Insert male rods into it and close the knobs
back again.
7
• Cover the camera lens with the provide hood
and Tight it.
• Open Velcro from the front of collapsible
hood pull out metal frame.
• Now slide metal frame on glass then insert it
in collapsible hood.
• Now secure it with velcro.
• Aach camera plate to camera and secure it by
using screw driver.
• Mount camera on quick release by sliding and
close knob.
8
• Mount vesa mount on the back side of screen
(Not included) and secure it by adding screws
with allen key.
• Aach the screen (Not included) to
adjustable arm and secure it with knob.
• Past side aps on collapsible hood.
• Remove knob and place adjustable arm on
I-pad plaorm.
• Now secure the arm by aaching knob back
again.
9
YOUR PROAIM ULTRA MODULAR TELEPROMPTER
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
