PROAIM CINEMA Series User manual
1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Assembly Manual
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Hybrid Cylindrical Arm with Vesa Mount
What’s In The Box
Hybrid 75mm/100mm VESA Monitor Mount (CT-HMMT-01)
2 x 400mm Rod Post
1 x T-Type Allen Key
(Size: 3/16”)
2 x Rod Mounng Clamp
Arm Mount Adaptor
2
Monitor Mount Setup
Loosen both the (top & boom) knobs on the
producon camera cart (Not Included).
Then, raise the pole of the camera cart
(Not Included), as shown in the image.
Loosen the knob of the rod mounng clamp
and insert it into the rod of the cart.
NOTE: The monitor mount rod can be xed
parallelly to the mast of any compable cart via
the clamping bracket with a clamping range of
38mm.
Aer inserng the rod mounng clamp into
the rod of the cart (Not Included), re-ghten
the knob to secure it. Follow the same
process to insert another Rod Mounng
Clamp into the main rod of the cart.
Loosen the ratchet knob of the rod mounng
clamp. Follow the same process to loosen the
other rod mounng clamp.
Now, insert the rod post into the hole of the
rod mounng clamp, as shown in the images.
3
Then secure the rod post with the rod
mounng clamp using the ratchet knob.
Aer securing the rod post with the rod
mounng clamp, mount the second rod post
by screwing it into the provided thread right
above the rst rod post.
Mount the arm mount adapter on the rod
post by screwing it into the provided thread.
Then mount the Hybrid Cylindrical Arm with
Vesa Mount on top of the Arm Mount
Adapter, and secure the arm mount adapter's
knob by re-ghtening it.
Then mount the Hybrid Cylindrical Arm with
Vesa Mount on top of the Arm Mount
Adapter, and secure the arm mount adapter's
knob by re-ghtening it.
NOTE: A 5/8” Baby Pin receiver at the base of
the arm mount adapter gives you the autonomy
to rig the arm on C-Stands, and Light Stands.
To detach the Vesa Mount from the Hybrid
Cylindrical Arm, loosen the bolt, as shown in
the image.
4
Attach the Vesa Mount at the back of the LCD
Monitor (Not Included) by aligning the
threads, as shown in the image.
To secure the assembly, insert the bolts and
secure them using the Allen key.
Secure all the bolts by ghtening them.
Align and match the thread holes of LCD
monitor (Not Included) with the Hybrid
Cylindrical Arm and then insert and tighten
the bolts using the Allen key to secure the
assembly.
In order to enable the panning movement of
the LCD Monitor (Not Included), loosen the
bolt of the Hybrid Cylindrical Arm.
5
The LCD monitor (Not Included) can be
subjected to lng (75°) by loosening the bolt
at the top of the Hybrid Cylindrical Arm with
the Allen key.
Tighten the ed bolt in the Hybrid
Cylindrical arm with VESA mount using the
Allen key to lock the arm at the required
posion.
NOTE: Arm will stay posioned at the exact
angle you leave it.To make your monitor more
agile & exible, the arm oers panning & lng
movements so that you can posion your
monitor at your convenience
6
YOUR PROAIM HYBRID 75MM/100MM VESA MONITOR MOUNT
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
