PROAIM JB-VG08-01 User manual
1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
8' Vega Jib Crane for DSLR Video Cameras
(JB-VG08-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Vega Jib Front Secon
Assembly Manua l
Vega Jib End Secon
Handle
2 x L-Type Allen Keys
(Sizes: 3/16 & 1/8)
Counter Weight with ower Knob
2
• Aer opening the end secon, loosen the
boom and side knobs of the Central Fork.
• Now, the end secon is properly open.
Feature: The Central Fork mechanism
facilitates ultra-smooth pan-lt movements
while absorbing unwanted vibraons for
cleaner shots.
• Mount the end secon of the Vega Jib on
the Jib Stand (Not Included).
End Secon Assembly
Vega Jib Setup
• Open the end secon of Vega Jib, as shown
in the image.
• Aer mounng the end secon, re-ghten
the knobs.
• Loosen and remove the top knob of the end
secon.
3
• The front secon has connecng bars
aached at both ends.
• Slide the front secon into the slot of the
middle secon.
Front Secon Assembly
• Loosen and remove the center knob of the
end secon.
• To detach the handles from one another,
loosen them by turning them in a circular
moon.
Feature: The Camera Crane can be controlled
using the handle.
• Remove the washer from the handle.
• Insert the handle into the hole of the end
secon of the Vega Jib, as shown in the
image.
Handle Assembly
• Tighten the locking knobs to secure the Jib
secons.
4
• Aer inserng the handle, aach the
handle to the jib from the other side.
• Now, aach the handle.
• Aer mounng the Quick Release Plate,
insert the bolts from the boom side of the
Camera mounng plate.
Camera Mounng Plate
• Insert a 1/4" bolt from the boom of the
extension Camera plate to secure the Quick
Release Plate and ghten it with the Allen
key.
• Unlock the lever lock of the Quick Release
Plate.
• Slide the Gimbal (Not Included) onto the
Quick Release Plate and lock it using the
locking lever.
• Mount the Quick Release Plate
(Not Included) on the Camera mounng
plate of the Vega Jib.
5
• Insert the weight (Not Included) inside the
weight Rod.
NOTE: Use the weights according to your
camera weight setup requirements.
• Monitor each frame by aaching a monitor
(Not Included) to the Jib using the oponal
Universal Clamp with 13"arculang double
arms and 3/8"-16 Threaded Stud.
YOUR PROAIM 8' VEGA JIB CRANE FOR DSLR VIDEO CAMERAS
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
• Now, the Gimbal is completely secured, as
shown in the image.
6
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and
evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our utmost
support and care unl you use our product.
