PROAIM CINEMA DL-MRCS-01 User manual
1
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Marcus Camera Dolly with Mitchell & Euro/Elemac
Adapter Base (DL-MRCS-01)
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
What’s In The Box
Assembly Manua l
Mitchell Base
Euro/ Elemac Base Adapter
3 x Adapters
2 x Track Wheels Cam Wheel
3 x Legs
3 x Foots With Knobs
3 x Spike Feet
3 x Caster Wheels
1 x L-Type Allen Key
(Size:4mm)
2
• Aer sliding the Leg, properly ghten it
using the provided knob, as shown in the
image.
• Now, properly ghten the knob of the
Adapter.
• Loosen the knob of the Adapter and
carefully slide it into the Dolly’s leg.
• Aach the remaining two Legs using the
same method.
Marcus Camera Dolly Setup
• Slide the Dolly Leg into the Mitchell Base.
Legs Assembly
Adapters Assembly
3
• Aer properly inserng the Caster wheel,
properly ghten it in place by ghtening its
knob.
• Now, push the Caster wheels downward
and lock them, as shown in the image.
• To aach the remaining Caster wheels,
follow the same process.
• Loosen the boom knob of the Adapter and
insert the caster wheel in the Adapter.
Caster Wheel Assembly
• Aach the remaining two Adapters using
the same process.
Spike Foot Assembly
• Loosen the top knob of the Adapter and
insert the Spike Foot in it.
4
• Repeat the same process to insert the
remaining Spike Feet.
• Aer mounng the Fluid Head, ghten the
castle ring.
• Remove the castle ring of the Fluid Head
(Not Included) and mount it on the Mitchell
base.
• Aer inserng the Spike Foot, properly
ghten its knob.
• Now, aach the plate with the Camera
(Not Included) and ghten it using a
screwdriver (Not Included).
Camera Mounng Setup
• Press the push buon of the camera plate
and remove it.
5
• Slide the Camera onto the Fluid Head, as
shown in the image.
• The Camera is properly mounted on the
Fluid Head.
• Aer sliding the Camera onto the Fluid
Head, properly lock it.
• Mount the 100mm Bowl Baby Tripod Stand
(Not Included) on the Marcus Dolly.
• Aer mounng the Tripod Stand, properly
lock the Tripod feet with the Spike’s feet.
100mm Bowl Baby Camera Tripod Stand Setup
• Loosen the screws of the spike feet and
adjust them using the 4mm Allen Key.
6
• Aer adjusng the Spike Feet, re-ghten its
screws using the Allen key.
• Aach the Camera with the Tripod stand, as
shown in the image.
• Now, ghten both the knobs properly.
Foot Assembly
• Loosen both the knobs of the Adapter.
• Insert the foot into the Adapter.
• Repeat the same process for the remaining
foot.
7
• Loosen the boom knob of the Foot.
• Adjust the height of the Foot using the top
knob.
NOTE: If the operator doesn't want to use
wheels, they can use the height-adjustable
feet to ensure you get the perfect shot, even
on uneven surfaces.
• Now, Mount the Euro/Elemac Base Adapter
on the Mitchell Base.
• Loosen and remove the castle ring of the
Euro/Elemac Base Adapter.
Euro/Elemac Base Adapter Assembly
• Aer adjusng the height of the Foot,
re-ghten the boom knob.
• Repeat the same process for the remaining
Foot.
• Tighten the Euro/Elemac Base Adapter
using the castle ring.
8
• Loosen the ratchet knob of the Camera Riser
(Not Included) and mount it on the Bull
Bazooka.
• Mount the Bull Bazooka (Not Included) on
the Euro Mount.
• Aer mounng the Bull Bazooka, properly
lock it using the ratchet knob.
Bull Bazooka Setup
• Aer mounng the Camera Riser, re-ghten
the ratchet knob.
• Now, mount your Camera as shown in the
image.
NOTE: It can withhold a whopping payload of
200kg/440lb, oering the sturdiest plaorm
for your setup.
Camera Riser Setup
9
• The dolly is properly mounted on the Track,
as shown in the image.
• Mount the Marcus Dolly on the Track
(Not Included).
Cam Wheel/Track wheel Assembly
• Aer inserng the Cam Wheel, re-ghten
the boom knob.
• Repeat the same process to insert the
remaining track wheels.
• Loosen the boom knob of the Adapter and
insert the Cam Wheel.
Track Setup
10
YOUR PROAIM MARCUS CAMERA DOLLY
ALL DRESSED UP AND READY TO GO!
(SHOWN WITH OPTIONAL ACCESSORIES)
Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,
we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it
cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon
and evaluaon by us.
Liability: We are not liable for damage caused by products that we do not supply or from mishandling in
transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.
Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our
utmost support and care unl you use our product.
