PROAIM P-LTCP-01 User manual

Please inspect the contents of your shipped package to ensure you have received everything that is listed

below.

Conversion Lateral Clamp for Proaim Soundchief,

Victor V1 & Victor Pro Camera Carts (P-LTCP-01)

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright

statutes or in wring by the Publisher.

What’s In The Box

Conversion Lateral Clamp

Assemb ly Manua l

Conversion Lateral Clamp Setup

• Open the Conversion Lateral Clamp by

loosening its ratchet knob.

NOTE: The Conversion Lateral Clamp is designed

to eecvely convert 38mm cart posts to 32mm.

• Aer opening the clamp as per your

requirement, insert it in the rod.

• Aer inserng it into the rod, ghten the

ratchet knob to secure it.

• Loosen the second ratchet knob to open the

second clamp.

• Aer opening the second clamp, insert

another rod into it and properly secure using

the ratchet knob.

• The rods are properly secured to the Lateral

clamp, as shown in the image.

NOTE: Conversion Lateral Clamp for Proaim

Soundchief, Victor V1 & Victor Pro Camera Carts

allows you to fasten the required post easily to

the lateral clamp. Aerward, your gear can

securely be mounted on it without destabilizing

the cart.

YOUR PROAIM CONVERSION LATERAL CLAMP

ALL DRESSED UP AND READY TO GO!

(SHOWN WITH OPTIONAL ACCESSORIES)

Warranty: We oer one year warranty for our products from date of purchase. Within this period of me,

we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor does it

cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to inspecon and

evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling in

transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our company.

support and care unl you use our product.
