Poly Voyager Focus 2 UC Series User manual

Voyager Focus 2 UC Series

Bluetooth Headset

User Guide

Contents

Overview 3

Headset 3

Charge stand (select models only) 4

USB Bluetooth adapter 4

Connect and pair 5

Connect to PC 5

Pair to mobile device 5

Pair mode 6

Pair BT700 USB adapter again 6

Fit and charge 7

Wear on the right or left 7

Charge 7

Check headset battery status 8

Load software 9

Update your Poly device 9

Basics 10

Power on/off 10

Adjust the volume 10

Adjust voice prompt volume 10

Make/Take/End Calls 10

Launch Microsoft Teams (Teams model only) 11

ANC 11

Use sensors 11

Play or pause audio 12

Voice assistant (smartphone feature) 12

More Features 13

Select language 13

Online indicator 13

Corded mode (audio over USB) 13

Troubleshooting 14

What's in the box 16

Support 17

Overview

Headset

Siri

Google Assistant

:02

2x 3x

Support Timer

Custom Button

olume

Play / Pause

Power

Device Controls

Headphones

Headset

Support Timer

Custom Button

Volume

Play / Pause

Power

Device Controls

Support T

Custom Button

Volume

Play / Pause

Power

Device Controls

Lock

Indicator Light

Music

ANC

Devices

Phone

Mobile

Computer

Camera

Charging/Battery

Scaled to 45% of full size

Devices

Charging/Battery

Blutooth

Device Status

Support

Settings

Daisy Chain / Link Lock

ANC

Timer

Custom Button

Power

Device Controls

Headphones

Mobile

Computer

Camera

Headset

Support

Settings

Daisy Chain / Link Lock

ANC

Timer

Custom Button

Power

Device Controls

Custom Button

Volume

Mic / Mic Mute

Play / Pause

Power

Device Controls Headset

olume

Mic / Mic Mute

Play / Pause

Power

Volume

Mic / Mic Mute

Play / Pause

Power

Device Controls

ANC:

Low/High

Icon Headset control

ANC Active Noise Cancelling (off/low/high)

Volume up

Call button/Press to interact with Microsoft Teams (Teams

model only, requires Teams app)

Siri/Google Assistant Default voice assistant

Play/pause**

Next track**

Previous track**

Volume down

Mute/unmute

Power on/off

Bluetooth pairing

Note: **Functionality varies by application. May not function with web-based apps.

Be safe

Please read the safety guide for important safety and regulatory information before

using your new device.

Charge stand (select models only)

Note: The charge stand plugs into a computer or wall charger's USB port.

USB Bluetooth adapter

Your high-fidelity Bluetooth USB adapter comes pre-paired to your Poly device. Plug it

into your computer to connect to high-fidelity computer audio.

Note: Adapter's USB connection and design may vary, but function is the same.

Standard LEDs

USB LEDs What they mean

Flashing red and blue Pairing

Solid blue Device connected

Flashing blue On a call

Solid red Mute active

Flashing purple Streaming media from computer

LEDs when Microsoft Teams* is detected

USB LEDs What they mean

Flashing red and blue Pairing

Solid purple Microsoft Teams connected

Flashing blue On a call

Solid red Mute active

Pulsing purple Microsoft Teams notification

Note: *Requires Microsoft Teams desktop application.

Connect and pair

Connect to PC

Your Bluetooth USB adapter provides the best connection, softphone functionality and

acoustic sound quality through your headset. The adapter comes pre-paired to your

headset.

1Turn on your headset and insert the Bluetooth USB adapter into your laptop or PC.

2The USB adapter LED ﬂashes and then turns solid to indicate the headset is

connected to the USB adapter. If you are wearing your headset you hear “PC

connected” to indicate the connection has been established. When on a call, the LED

on the USB adapter flashes blue. When not on a call the LED is solid.

3Load Poly Lens Desktop App by visiting poly.com/lens. This allows you to customize

your headset behavior through advanced settings and options.

Configure USB adapter for streaming media

Your high-fidelity Bluetooth USB adapter comes ready to take calls. To stream media,

conﬁgure your Bluetooth USB adapter.

Windows

1To conﬁgure your Bluetooth USB adapter for streaming media in your PC, go to Start

menu > Control Panel > Sound > Playback tab. Select Poly BT700 set it as the

Default Device and click OK.

2To pause music when you place or receive calls, go to Start menu > Control Panel >

Sound > Communications tab and select the desired parameter.

Mac

1To conﬁgure your Bluetooth USB adapter for streaming media on your Mac, go to

System Preferences > Sound. On both the Input and Output tabs, select Poly BT700.

Pair to mobile device

1To put your headset in pair mode, slide and hold the Power switch away from the off

position until you hear "pairing" and the headset LEDs flash red and blue.

:02

“Pairing”

Blutooth

Headphones

Computer

Camera

2Activate Bluetooth on your phone and set it to search for new devices.

•iPhone Settings > Bluetooth > On*

•Android Settings > Bluetooth On > Scan for devices*

Note: *Menus may vary by device.

3Select “Poly VFOCUS2 Series.”

Once successfully paired, you hear “pairing successful” and the headset LEDs stop

flashing.

Note: Your headset can pair with up to 8 devices but only maintain 2 connections

simultaneously; this includes the base.

Pair mode

Put your headset in pair mode to connect to a new device or to pair again.

Slide and hold the headset Power switch away from the off position until the LEDs flash

red and blue.

Pair BT700 USB adapter again

Typically, your USB Bluetooth adapter is pre-paired to your Poly audio device. In the

event that your adapter is disconnected or bought separately, you will need to pair the

adapter to your Poly device.

Your USB adapter requires Poly Lens Desktop App to pair to a Poly audio device.

Download: poly.com/lens.

Note: Adapter design varies by USB connection.

1Insert the high-fidelity Bluetooth USB adapter into your laptop or computer and wait

for your computer to recognize it.

2Put your Poly audio device in pair mode.

3Launch Poly Lens Desktop App and navigate to Poly BT700.

4Put your Bluetooth USB adapter into pair mode by selecting "Pair new device" on the

adapter's main page or overflow menu. Your adapter flashes red and blue.

Pairing is successful when you hear "pairing successful" and "PC connected" and the

Bluetooth USB adapter LED is solid.

Fit and charge

Wear on the right or left

• To position the microphone on the right or left side, rotate the microphone boom up

and over. Bend the boom so it is approximately 2 finger widths from the corner of

your mouth.

Note: Your headset senses when you change the microphone boom from one side to

the other and syncs the audio specific to each side.

• Gently flex the headband wider if the fit is uncomfortable on your ears.

Charge

Note: The micro USB cable and charge stand (sold separately) plug into a computer or

wall charger's USB port.

Charge your headset using the micro USB cable or the charge stand (sold separately). The

headset LEDs flash when charging. It takes approximately 2 hours to fully charge your

headset. The LEDs turn off once charging is complete.

Micro USB cable Charge stand (sold separately)

Headset LEDs What they mean

Off Charging complete

Battery high

Battery medium

Battery low

Battery critical

Check headset battery status

Check your headset battery status:

• With headset inactive, slide and release the Power switch away from the off

position. Listen to the voice alert or observe the headset LEDs.

Load software

Download Poly Lens App to get the most out of your device. Some softphones require the

installation of Poly software to enable device call control (answer/end and mute)

functionality. Download: poly.com/lens.

• Enable features

• Change settings

• Configure call control for softphones

• Update device firmware

• Manage notifications and alerts

• Schedule health and wellness reminders

Update your Poly device

Keep your firmware and software up-to-date to improve performance and add new

features to your Poly device.

Update your device using Poly Lens App. Download at poly.com/lens.

Basics

Siri

Google Assistant

:02

2x 3x

Support Timer

Custom Button

olume

Play / Pause

Power

Device Controls

Headphones

Headset

Support Timer

Custom Button

Volume

Play / Pause

Power

Device Controls

Support T

Custom Button

Volume

Play / Pause

Power

Device Controls

Lock

Indicator Light

Music

ANC

Devices

Phone

Mobile

Computer

Camera

Charging/Battery

Scaled to 45% of full size

Devices

Charging/Battery

Blutooth

Device Status

Support

Settings

Daisy Chain / Link Lock

ANC

Timer

Custom Button

Power

Device Controls

Headphones

Mobile

Computer

Camera

Headset

Support

Settings

Daisy Chain / Link Lock

ANC

Timer

Custom Button

Power

Device Controls

Custom Button

Volume

Mic / Mic Mute

Play / Pause

Power

Device Controls Headset

olume

Mic / Mic Mute

Play / Pause

Power

Volume

Mic / Mic Mute

Play / Pause

Power

Device Controls

ANC:

Low/High

Power on/off

To turn on the headset, slide the Power button to reveal green.

Adjust the volume

Tap the Volume up (+) or down (–) button.

Adjust headset microphone volume (softphone)

Place a test softphone call and adjust softphone volume and PC sound volume

accordingly.

Adjust voice prompt volume

To adjust the volume of voice alerts and prompts, toggle the volume switch up (+) or

down (-) while not on a call or streaming audio.

Make/Take/End Calls

Answer or end a call

Tap the Call button.

Answer a second call

First, tap the Call button to end current call, then tap the Call button again to answer

new call.

Mute

Mute your headset on an active call:

• Tap the Mute button

• Rotate your microphone boom and click it into the up position

• Take off your headset (requires active smart sensors). Put on your headset to unmute.

Hold a call

To hold an active call or resume a held call:

• Standard headset: Press the Call button for 2 seconds.

• Microsoft Teams headset: Press the Mute button for 2 seconds.

Other manuals for Voyager Focus 2 UC Series

Table of contents

Other Poly Headset manuals

Poly

Poly Savi 8210 UC User manual

Poly

Poly Savi 8240 Office User manual

Poly

Poly Plantronics Voyager 5200 Office User manual

Poly

Poly Voyager 4200 UC Series User manual

Poly

Poly Savi 8240 UC User manual

Poly

Poly Savi 8245-M UC User manual

Poly

Poly Voyager 8200 UC User manual

Poly

Poly Savi 8200 Series User manual

Poly

Poly Voyager 4245 Office User manual

Poly

Poly Voyager 42 Series User manual

Poly

Poly Voyager 4300 UC Series User manual

Poly

Poly Savi 7310 User manual

Poly

Poly Voyager 5200 Series User manual

Poly

Poly Savi 8210 Office User manual

Poly

Poly Savi 8245 Office User manual

Poly

Poly Voyager 4245 Office User manual

Poly

Poly Voyager Focus 2 UC Series Instruction Manual

Poly

Poly Plantronics Voyager Focus UC User manual

Poly

Poly Voyager 6200 UC User manual

Poly

Poly Savi 8240 Office User manual

Poly

Poly Savi 8210 Office User manual

Poly

Poly VOYAGER SURROUND 85 UC User manual

Poly

Poly Voyager 8200 UC User manual

Poly

Poly Savi 7310 User manual

Popular Headset manuals by other brands

Sena

Sena SMH10 quick start guide

IASUS

IASUS Stealth IA-NT4-BASIC-BT manual

Sennheiser

Sennheiser EPOS ADAPT 230 user guide

Doro

Doro Flexus HS2005 user guide

GE 98971 datasheet

Hama

Hama 00184070 quick start guide

Plantronics

Plantronics Blackwire 3200 Series user guide

Blue Tiger

Blue Tiger Advantage PLUS user manual

Jawbone

Jawbone Icon user manual

Jabra

Jabra FR 20 user guide

Roxcore

Roxcore Flow A+ manual

Turtle Beach

Turtle Beach XP 510 user guide

Philips

Philips SHB6101 Specification sheet

Jabra

Jabra PRO 9460 Duo datasheet

HyperX

HyperX HyperX Cloud Flight manual

Bose

Bose MIE2 Mobile owner's guide

Jabra

Jabra Steel quick start guide

HyperX

HyperX cloud ii quick start guide
