Plantronics M214I User manual
Internet Headset Online User Guides Page 1 of 13
Welcome:
The following manual describes ways to optimize your sound experience or simply
provide troubleshooting tips.
Setting Up Your USB Adapter......................................................................................... 2
Headset Settings................................................................................................................ 3
Headset Settings for MX500i: ........................................................................................ 4
Headset Settings for M214i: ........................................................................................... 5
Internet Calling Services Settings.................................................................................... 6
Settings for Skype:.......................................................................................................... 7
Settings for Yahoo! Messenger with Voice:................................................................... 8
Settings for Google Talk:.............................................................................................. 10
Windows XP Settings...................................................................................................... 11
Microphone Level Settings for Windows XP:.............................................................. 12
Side Tone Adjustments for Windows XP:.................................................................... 13
Internet Headset Online User Guides Page 2 of 13
Setting Up Your USB Adapter:
To set-up your USB adapter:
1) Plug the 2.5mm jack of your Plantronics Internet Headset into the 2.5mm plug of
the USB adapter.
2) Plug the USB connector into the correct port on your computer.
Internet Headset Online User Guides Page 3 of 13
Method 1:
Headset Settings
Internet Headset Online User Guides Page 4 of 13
Headset Settings for MX500i:
For the best sound experience, please check that:
1) Your talking volume is optimized
2) Your mute button is not on
3) Your listening volume is optimized
1. To adjust the volume that you hear the other person at, adjust the rolling knob on the
side of the pod. Make sure it is on the higher volume setting if you are having trouble
hearing the other person.
2. If the person on the other end can not hear you, check that the pod is NOT on mute.
Make sure that you see GREEN to ensure the mute button is off.
3. If the person on the other end can not hear you well, try adjusting you microphone
adjustment switch. This switch is on the side and adjusts your outgoing volume. You
may need a paperclip or pen to adjust it.
Internet Headset Online User Guides Page 5 of 13
Headset Settings for M214i:
For the best sound experience from your M214i, please check that:
1) Your talking volume is optimized
2) Your mute button is not on
3) Your listening volume is optimized
1. To adjust the volume that you hear the other person
at, adjust the rolling knob on the side of the pod. Make
sure it is on a higher volume setting if you are having
trouble hearing the other person.
2. If the person on the other end can not hear you, check
that the pod is NOT on mute. The mute switch is on the
side of the pod.
3. If the person on the other end can not hear you well,
try adjusting you microphone adjust switch. This switch
is on the side and adjusts your outgoing volume. You
may need a paperclip or pen to adjust it.
Internet Headset Online User Guides Page 6 of 13
Method 2:
Internet Calling Services Settings
This should be done regardless of which service provider you use.
Internet Headset Online User Guides Page 7 of 13
Settings for Skype:
(Ver 2.5.0.141)
The following adjustments are to make sure that Skype recognizes your internet headset:
Step 1: Open up Skype
Step 2: Click ‘tools’ > ‘Options’ (from the top navigation, Figure 1)
Step 3: Select ‘Sound Devices’ (from the left hand column)
Step 4: In ALL 3 drop down menus (Audio In, Audio Out, and Ringing) select ‘USB
Audio Device’ (Figure 2)
Step 5: Press SAVE. This button is located in the bottom right corner.
Internet Headset Online User Guides Page 8 of 13
Settings for Yahoo! Messenger with Voice:
(Ver 8.0.0.716)
The purpose of the following adjustments, are to make sure that Yahoo! Messenger
recognizes your Internet headset.
Step 1: Open Yahoo Messenger
Step 2: Choose ‘Actions’ > ‘Call setup’:
Step 3: Click ‘Next’ on the wizard:
Step 4: Speak into your headset and see if the bars light up. If not, select ‘USB Audio
Device’ from the drop down menu. Click next:
Internet Headset Online User Guides Page 9 of 13
Step 5: Listen for music. If you can not hear music, select ‘USB Audio Device’ from
the drop down menu. Click next:
Step 6: Click Finish
Internet Headset Online User Guides Page 10 of 13
Settings for Google Talk:
The purpose of the following adjustments, are to make sure that Google Talk recognizes
your Internet headset.
Step 1: Open Google Talk:
Step 2: Click ‘settings’ in the top right of the Google talk window:
Step 3: Click ‘audio’ in the left navigation of the settings window
Step 4: Select ‘USB Audio Device’ in ALL 3 of the drop down menus in the audio
screen. See picture above.
Step 5: Click OK.
