Plantronics Discovery 975 User manual
Plantronics Discovery®975
User Guide
ii
Welcome
Thank you for purchasing the Plantronics Discovery®975 earpiece.
This guide contains instructions for setting up and using your new
earpiece.
Before using this product, please refer to the For Your Safety
guide for important product safety and charging information.
Getting Assistance
The Plantronics Technical Assistance Center is ready to assist
you. You can find answers to frequently asked questions, ask a
question using e-mail, receive service over the Internet, or speak
directly with a representative. Visit www.plantronics.com/support
or call 1-866-363-BLUE (2583).
NOTE If you are considering returning this earpiece, please contact
the Technical Assistance Center first.
Registering Your Product
Visit www.plantronics.com/productregistration to register your
product online so we can provide you with the best service and
technical support.
NOTE For pairing your Earpiece, your PIN code, or “Passkey,” is
0000.
iii
EN
Contents
Package Contents, Features and Accessories ........................... iv
Charging Your Earpiece................................................................1
Using the AC or USB charger.............................................1
Using the Charging Case ...................................................2
Checking the Battery Level ................................................3
Automatric Battery Status Alerts........................................4
Recharging the Charging Case ....................................................5
Pairing Your Earpiece ...................................................................6
Plantronics QuickPair™ Technology ..................................6
How to Pair Your Phone With Your Earpiece
for the First Time ................................................................7
Adjusting the Fit ...........................................................................8
How to Install a Different Gel Eartip ...................................8
Earpiece Controls.........................................................................9
Hands-Free Features..................................................................10
Range .........................................................................................11
Indicator Lights and Tones .........................................................11
Troubleshooting..........................................................................13
Using More Than One Bluetooth Phone ....................................15
How to Turn the Multipoint Feature On and Off ...............15
How to Initiate a Call ........................................................15
How to Answer a Call While Talking on the Other Phone 15
Product Specifications ...............................................................16
Limited Warranty ........................................................................17
Package Contents and Features
Product Name & Number Accessories*
Vehicle Power Charger
#xxxxx-xx
Clothing Clip
#xxxxx-xx
Earpiece
Charging Case
* Not included. To order, please contact your Plantronics supplier
or go to www.plantronics.com
AC Charger
100 – 240V
USB Charging Cable
Volume Control
Button
Charging Jack
Eartip
Stabilizing Eartips
(small, medium, and large)
Call Control
Button
USB Lanyard
#74948-01
iv
1
EN
Option A: Using the AC Charger
1 Plug the AC charger into a power
outlet.
2 Connect the AC charger to the
charging jack on the earpiece.
Charging Your Earpiece
Your new earpiece performs best when fully charged. While your
earpiece is charging, the indicator light slowly flashes red. When your
earpiece is fully charged, the indicator light turns off. This applies to
all charging options.
Never charge the battery where the temperature may fall below 0°C
(32°F) or rise above 40°C (104°F) – for example, in an unattended
motor vehicle. Do not use your earpiece while it is
connected to the charger. 1
2
Option B: Using the USB Charger
1 Connect USB charger to the USB
port on a computer or laptop.
2 Connect the USB charger to the
charging jack on the earpiece.
3 Turn the computer or laptop on.
1
2
3
CHARGING TIME
1.5 hours .....Full charge using
AC or USB
30 minutes...Minimum charge
before first use
2
Option C: Using the Charging Case
Open the cover of the case. Align the charging jack on the
earpiece with the micro USB connection in the case. Gently push
the earpiece onto the micro USB connection until you feel it click
into place.
IMPORTANT Incorrect removal of the earpiece from the case will
damage the micro USB port in the case. Gently press the ejection
button with your thumb to release the earpiece.
Charging Your Earpiece
EjectInsert
3
EN
Checking the Battery Level of Your Earpiece
Option A: With the earpiece on, simultaneously press and hold the
call control button and the volume button for about 2 seconds. The
indicator light flashes red to show the charge level.
Option B: The LCD display on the charging case will indicate battery
level of the earpiece when earpiece is inserted into case. The battery
icon (above the earpiece) flashes to indicate battery level.
Charging Your Earpiece
Volume Button
Call Control Button
CHARGE INDICATOR LIGHTS
Red Flashes Battery Level
SMore than 2/3 full
S S 1/3 to 2/3 full
S S S Less than 1/3 full
BATTERY LEVEL ICON
Bars Battery Level
3 Full battery
2 1/3 to 2/3 full
1 Less than 1/3 full
4
Charging Your Earpiece
LOW BATTERY WARNINGS
Battery Level Tone Voice Prompt
30 minutes of
talk time remaining
(this alert only
occurs during
an active call)
Double high
tone every
15 minutes
“Battery Low”
repeats every
30 minutes
10 minutes
of talk time
remaining
Triple high
tone every
30 seconds
“Recharge
Battery” repeats
every 3 minutes
Automatic Battery Status Alerts
When the battery charge is very low, a tone and voice prompt in English
will automatically occur.
5
EN
Recharging the Battery Inside the Case
The charging case provides two full charges to your earpiece before
the battery within the case requires charging.
1 To check the battery status of the charging case, refer to
the LCD display on the case.
The battery status may change if you insert the earpiece because
the battery will transfer power to the earpiece.
2 Plug either the AC charger or the USB charger to power
source before connecting to the charging jack on the side
of the case.
While the case is charging, the LCD battery icon (above the case
image) flashes to indicate charge level.
NOTE If you disconnect the power source from the case after 10
minutes of charging you must then wait at least 60 minutes before
reconnecting a power source to resume the charging cycle.
Recharging Your Charging Case
21
CHARGING TIME
3.5 hours. Full charge
using USB
1.5 hours. Full charge
using AC
6
Pairing Your Earpiece
Before using your earpiece for the first time, you must pair it with
your Bluetooth®wireless technology enabled phone.
Your new earpiece includes Plantronics QuickPair™technology to
simplify the Bluetooth setup process. The first time you turn your
earpiece on, your earpiece automatically enters pairing mode for 10
minutes. Once paired successfully, your earpiece stays on for instant
use.
If not successfully paired after 10 minutes, your earpiece automatically
powers off. When you turn the earpiece on again, it automatically
goes into pairing mode until successfully paired with a Bluetooth
phone.
NOTE This earpiece is equipped with Secure Simple Pairing (SSP).
If your phone supports SSP, you will not need to enter a PIN code or
Passkey.
