Pinnacle MovieBox USB User manual
Pinnacle MovieBox USB
Professional Quality Movie Making
QUICK START GUIDE
КРАТКОЕ РУКОВОДСТВО
STRUČNÝ PRŮVODCE
PODRĘCZNIK SZYBKIEGO STARTU
41003781
© Pinnacle Systems 2003
All rights reserved.
No part of this manual may be reproduced or transferred to other media without explicit written
permission from Pinnacle Sysrems., Braunschweig, Germany.
All brand or product names are trademarks or registered trademarks of their respective holders.
© Pinnacle Systems 2003
Все права защищены.
Никакая часть настоящего руководства не может быть воспроизведена или перенесена на другой
носитель без специального письменного разрешения компании Pinnacle Systems, Брауншвайг,
Германия.
Все торговые марки или названия продуктов являются охраняемыми товарными знаками
соответствующих владельцев.
© Pinnacle Systems 2003
Všechna práva vyhrazena.
Žádná část této příručky nesmí být reprodukována ani převedena na jiný typ média bez výslovného
písemného souhlasu společnosti Pinnacle Systems., Braunschweig, Německo.
Všechny názvy značek nebo produktůjsou ochrannými známkami nebo registrovanými ochrannými
známkami příslušných vlastníků.
© Pinnacle Systems 2003
Wszelkie prawa zastrzeżone.
Żadna część tego podręcznika nie może byćkopiowana ani przenoszona na inne nośniki bez wyraźnej
pisemnej zgody firmy Pinnacle Systems., Braunschweig, Niemcy.
Wszystkie nazwy marek lub produktów sąznakami towarowymi lub zastrzeżonymi znakami
towarowymi odpowiednich właścicieli.
Pinnacle MovieBox USB
Professional Quality Movie Making
QUICK START GUIDE
English
Quick Start Guide 1
English
Before you begin
This chapter tells you which computer system components are required for
the operation of MovieBox USB and what is included in the MovieBox USB
package contents.
SYSTEM REQUIREMENTS
Please make sure your system meets the following requirements before
installing MovieBox USB:
Computer
Intel Pentium or AMD Athlon 800 MHz or higher
(1.5 GHz or higher recommended)
256 MB RAM (512 MB recommended)
Windows 98SE, Windows Millennium, Windows 2000, Windows XP
(Windows XP recommended)
USB 1.1 or USB 2.0 port (USB2.0 recommended)
DirectX compatible Graphics Card
(ATI Radeon or Nvidia Geforce recommended)
DirectX compatible Sound Card
(Creative Labs Audigy recommended)
500 MB of disk space to install software
Minimum 1 GB needed for project and temp files
Speakers
Mouse
CD-ROM drive
DVD drive required to install tutorial, electronic manual and some bonus
content. If you do not have a DVD drive you may order the tutorial,
electronic manual and bonus content separately on CD ROMs
Optional
yCD burner for creating Video CDs or Super Video CDs
yDVD burner drive for creating DVDs
yProLogic compatible audio system for preview of surround sound
mixes
yUse of some features requires product activation via internet
2Pinnacle MovieBox USB
English
Video equipment
MovieBox USB can capture from and output video to:
Any analog (8mm, Hi8, VHS, SVHS, VHS-C or SVHS-C) camcorder or
VCR.
Any DV, Digital8 or MicroMV camcorder with analog outputs (capture
only)
PACKAGE CONTENTS
Please make sure your MovieBox USB system is complete before you begin
the installation. The system includes*:
MovieBox USB USB-cable Power supply with
separate power cable
(no illustration)
Pinnacle Studio Manual This Quick Start Guide Pinnacle Studio “Programs”
and “Content”
disks
If any parts are missing, please contact your retailer.
*Depending on the delivery scope, the actual package contents may be different from the package contents listed in
the manual. Specifications are subject to change without notice or obligation.
Quick Start Guide 3
English
Installing the Software
1. Insert the Studio CD-ROM into your CD-ROM drive.
If you have Autorun enabled for your CD-ROM, Setup will run
automatically. If you do not have Autorun enabled, navigate to your CD-
ROM drive, and double-click on Setup.exe.
2. Select the language of your choice.
3. Check for previous version.
If a previous version of Studio is not found on your system you will be
asked to insert the CD-ROM of your previous version into your CD-
ROM drive.
4. Personalise your Studio installation by entering your name, country,
e-mail address (optional) and serial number.
5. Registration.
Next you will be given the opportunity to register your copy of Studio.
You can quickly and easily register using your Internet connection.
Registration is important for four reasons:
You will receive a free bonus effect pack upon registration.
Registration is required to receive technical support.
Registration allows Pinnacle Systems to inform you of free updates to
the Studio software.
Registration makes you eligible for special offers and promotions from
Pinnacle Systems.
6. Agree to the Studio software license terms (click I Agree).
If you do not accept or understand the terms, you should promptly return
this product to your dealer.
7. Choose Typical installation (recommended).
Only advanced computer users should choose Custom.
8. Click Next until the installation is completed.
9. Restart.
In some cases, you may be instructed to restart your PC.
10.Insert the Studio Content DVD into your DVD drive.
If you have Autorun enabled for your DVD drive, Setup will run
automatically. If you do not have Autorun enabled, navigate to your DVD
drive, and double-click on Setup.exe. If you do not have a DVD drive you
may order the tutorial, electronic manual and bonus content separately on
CD ROMs at http://www.pinnaclesys.com/studio9cd
11.Install additional software.
If you received any additional effects or content with your Studio
upgrade, install it now by inserting the CD-ROM(s) or DVD into your
CD-ROM or DVD drive. If you have Autorun enabled for your CD-ROM
or DVD drive, Setup will run automatically. If you do not have Autorun
enabled, navigate to your CD-ROM or DVD drive, and double-click on
Setup.exe.
4Pinnacle MovieBox USB
English
Connecting the MovieBox USB
and the Video Devices
The following chapter tells you how to connect your video devices to the
MovieBox USB. To do so you will need the appropriate cables.
Important Be sure your PC, MovieBox USB and video equipment are all
turned OFF before making any connections.
HOW TO CONNECT THE DEVICES
The following illustrations show how to connect MovieBox USB to your PC
and video equipment.
12345
6
7
8
Power supply
USB connector
Inputs Outputs
Video IN Video OUT
1Composite
2S-Video
5Composite
6S-Video
Audio IN Audio OUT
3Left
4Right
7Right
8Left
Quick Start Guide 5
English
Analog
Video Source
Power
Supply
Audio
Out
Audio
In
Composite or
S-Video Out
Composite or
S-Video In
USB
Video Monitor
Audio
Out
Audio
In
Composite
or S-Video Out
Composite
or S-Video In
Audio
Out Composite
or S-Video Out
Composite
or S-Video In
Audio
In
VCR
PC
Now, have some fun…
Now that you have installed the MovieBox USB, you can use it
immediately. We strongly recommend you take this opportunity to
experience Studio digital video editing.
6Pinnacle MovieBox USB
English
Technical Data
KEY PARTS
Hardware
External Video Capture and Output device
HiSpeed USB 2.0 (USB 1.1 compatible) -Interface
MPEG1/2 Video/Audio compression hardware
Composite, S-Video Right and Left Audio Inputs and Outputs
Power Supply
USB Cable
Software
Drivers for Windows XP, 2000, Me
Installation program
Studio Application
KEY FEATURES
Capture in MPEG2 ML@MP (4:2:0) program stream muxed with
MPEG1 Layer II audio
Capture in MPEG1 system stream muxed with MPEG1 Layer II audio
Playback to PC Monitor and/or to tape
