Aquarium environmental meter PCE-PHM 12

Aquarium pH meter with temperature compensation up to 50°C (122°F) / Detachable pH electrode universal

saturation device / Temperature unit switchable / Easy to use / For permanent installation and mobile use /

Single-point adjustment

The aquarium pH meter PCE-PHM 12 was specially developed for the pH measurement in aquariums. With the

included universal holder, the aquarium pH meter can be attached to any aquarium. The permanently installed

temperature probe on the aquarium pH meter is not only used for temperature indication but also for temperature

compensation. With the aquarium pH meter this guarantees a precise measured value even with a temperature

fluctuation. Depending on your needs, an adjustment on the aquarium pH meter can also be carried out with a pH 7

reference solution.

The aquariumpH meter has two power supply options. On the one hand, it is possible to operate the aquarium ph meter

with the supplied power supply. On the other hand, it is possible to operate the aquarium pH meter with four batteries.

Thus, the aquarium pH meter is suitable for permanent installation and also for mobile use.

- Temperature compensation up to 50°C / 122°F

- Universal mounting bracket

- Removable pH electrode

- Easy to use

- Switchable temperature unit

- Battery and mains operation possible

Specifications:

Function

Measuring range

0.00 ... 14.00 pH

Resolution

0.01 pH

Accuracy

± 0.1 pH

Function

Temperature

Measuring range

0 ... 55°C / 32 ... 122°F

Resolution

0.1°C / 0.18°F

Accuracy

± 1°C / 1.8°F

Power supply

6V DC (batteries or power supply)

Battery

4 x 1.5V LR44 AG13

Power adapter

Primary: 230 ... 240V AC, 50 Hz, 19 mA

Secondary: 6V DC, 100-mA

Environmental conditions

0 ... 50°C / 32 ... 122°F, <95% rh

Dimensions

75 x 55 x 25 mm

Weight

75 g / < 1 lb

Delivery scope:

1 x Environmental meter PCE-PHM 12

1 x pH electrode

1 x Screwdriver

1 x Suction cup

1 x Velcro closure

1 x Universal mounting bracket

1 x Power supply 6V DC 100-mA

4 x 1.5V LR44 AG13 batteries

1 x User manual
