OfficeSource PL231 User manual

CB D

Side Panel-R Hanging Rail-2Pcs Back Panel Bottom Panel

Housing Cap (Short)

10 Pcs

Cam Lock

10 Pcs

Klix Cam

10 Pcs

11 2 3

JCBC Screw

M6 x 35mm = 4pcs

Washer = 8pcs

M4 x 65

Allen-Key

1 Pc

1 OF 2

Before assembly, please remove all parts from carton, verifying that you have the correct quantities, and read all the instructions.

IN THE CARTON:

COMPONENTS

HARDWARE

Insert the cam with the arrow

pointing towards the hole in

the edge.

Line up Cam Lock,

turn clockwise.

1 2

Insert the Cam Lock into Klix

Cam. Turn Klix Cam to lock.

KLIX CAM INSTRUCTIONS

MODEL: PL 231

ASSEMBLY INSTRUCTIONS

Screw

3.5X30MM

4 Pcs

Side Panel-L

Last Updated: 02/2021

MODEL NO. PL231

OFFICESOURCE.COM

ASSEMBLY INSTRUCTIONS

Last Updated: 3/2023

Attach Side Panel (B) to Hanging Rail (C) and Back

Panel (D) by using Cam Lock (1) and Klix Cam (2).

Attach Hanging Rail (C) and Back Panel (D) to Side

Panel (A) by using Cam Lock (1) and Klix Cam (2).

1 2

2 OF 2

Before assembly, please remove all parts from carton, verifying that you have the correct quantities, and read all the instructions.

INSTRUCTION:

MODEL: PL 231

ASSEMBLY INSTRUCTIONS

2 OF 2

ATTENTION

Place all wooden parts on a clean, smooth surface to prevent them from being scratched.

Check to be sure that you have all parts and hardware. Remove all wrapping materials, including staples and packing straps before

you start to assemble. Do not tighten all screws/bolts until all completely assembled. Keep all hardware parts out of reach of children.

If any parts are missing, broken, damaged or worn, stop use of product until repairs have been made using factory authorized parts.

Failure to follow these warnings may result in injury.

Attach Bottom Panel (E) to Side

Panel (A) & (B) by using Cam Lock

(1) and Klix Cam (2).

Attach Housing Cap(3) to each Klix

Cam(2) by pushing the neck

thought the center of the Klix Cam.

Attach the PL231 to others PL231 by

using JCBC Screw & Flat Washer(1).

Attach the PL231 to

others PL231 by

using Screw(1).

Last Updated: 02/2021

MODEL NO. PL231

OFFICESOURCE.COM

ASSEMBLY INSTRUCTIONS

Last Updated: 3/2023
