Overview

The HPQ3 is the latest innovation in RGA technology from MKS Instruments allowing operation far

beyond the 1e-4mbar of conventional RGA’s without the need for differential pumping.

The field proven analyser technology of the HPQ analyser coupled with the latest innovative

electronics technology derived from the Microvision2 family give data quality not previously seen in

this class of instrument. The resulting system is less complex, with reduced installation

requirements, offering a higher level of reliability at a substantially lower cost.

In addition, the HPQ3S uses application validated correction algorithms to compensate for the

sensitivity variation arising from ion-molecule interactions in the ion source at higher pressures.

This allows reliable data to be obtained for specific gas species including water, oxygen, nitrogen,

methane, helium and hydrogen in argon and other gas mixtures.

Features

Data acquisition through solid state, wide dynamic range, fast settling detector electronics.

Temperature stabilized critical components offering improved signal stability and drift.

Calibrations and configurations stored locally within the RGA.

Flexible I/O capability including a dedicated gauge port.

Further expandability of the I/O capabilities using add-in cards.

TCP/IP and ASCII protocol support

Operation

The HPQ3 is designed to be operated in several ways:

From a host computer –an IBM compatible PC or MAC running the MKS Process Eye

Professional or EasyView software package.

PC or MAC using a web browser such as Internet Explorer or Safari.

Integration into existing systems controlling through the use of the ASCII protocol command set.

MKS Instruments UK Ltd

HPQ3 Hardware Manual –SP101019.101 October 2012

This manual focuses on HPQ3hardware and should be used in conjunction with the relevant user

interface manual during installation.

Any required network communications cards should be installed and configured prior to installing

the HPQ3, or RGA software if supplied.

MKS Instruments UK Ltd

HPQ3 Hardware Manual –SP101019.101 October 2012

1. Specifications

1.1 Mechanical

HPQ3

Dimensions:

127mm wide x 127mm x 179mm deep, plus 46mm over analyser connector to face of CF flange.

Weight:

1.7 kg

24VDC Power Supply

Dimensions:

75mm wide x 45mm high x 146mm deep plus 30mm over strain relief.

Weight:

0.6 kg

Analyser

Max. Operating pressure

HPQ3 1e-3 Torr (1.3e-3 mbar)

HPQ3S 8e-3 Torr (1e-2 mbar) –Application

dependant

Maximum transient burst pressure

4e-2 Torr (5e-2 mbar) –gas dependant

MKS Instruments UK Ltd

HPQ3 Hardware Manual –SP101019.101 October 2012
