User’s Manual of Patient Monitor
8
● 39—— remote control knob received through the window：Infrared remote control for
receiving a instructions.
●41—— battery status indicator：Used for the state of the storage battery charging and
discharging real-time instructions.
● 42——remote control receiving indicator light:Press the remote and accept to remote control
signal instructions.
Using Rotary knob to operate:
Cursor is moving when rotating the knob.The place where cursor located can be operated
accordingly.
When cursor is at the area of waveforms,users can modify current setting. When it is located at
parameter’s area, users can set information according to each parameter.
The operation are as follows:
◼Move cursor to items
◼Press the knob
◼Four conditions will occur
⚫It pops uo menu or measurewindow, or new menua replaced
⚫Cursor with color background truns to frame without color background
⚫Occur a “√” mark, which means choosing this item
1.4 Display of the screen
The screen is TFT colored LCD display with high resolution, which can show each parameter
and waveforms clearly. Other interface description：
(44) patient information area (45) demo tip information area (46) technology alarm
information area (47) physiological alarm information area (48) system time instructions area
(49) parameter information (50) waveform instructions area display (51) tip information
area
46---- Technology alarm information area
Show technical alarm information or indicating information, Report monitor’s screen
status. When without any information, it shows nothing
47---- Physiological alarm information area
Show physiologic alarm information, display circularly when one more information
48---- System time
Show current date and time
49---- Parameter information
Consisted of each small parameter area, it shows the measurement values according to
each parameter module. The upper left of each parameter is hot key. Through it, setting menu
for each parameter can be opened, for details, please refer to each parameter chapter. The
alarm information occurs regularly behind the area of each parameter. Showing menus
alarm is under off, and the sound of alarm is turned off until users cancel this operation. If
