Enclosure
lip
Press down Pull away and lift
from two corners to
remove.
Converter Boot
NOTE
It is HIGHLY recommended that the
boot be utilized at all times when
the meter is not being read. The
boot adds protection to the meter and ensures
proper closure of the lid, ensuring the maximum
battery life.
IMPORTANT
The Dura Mag comes with a boot to help protect
the meter.
The boot simply slips over the electronics
enclosure. When installing the boot, ensure the
corners of the boot t snugly over the lip of the
enclosure.
To remove the boot, grip two corners and pull
them away from the lip of the enclosure and then
pull upwards.
Upon activating the display, the Dura Mag
automatically cycles through four display screens.
Alarm
Indicator
Alarm
Type
Battery life
remaining
Totalizer
Flow rate
Totalizer
Flow rate
Percent of
full scale
Display Descriptions
The Dura Mag comes pre-congured from the
factory based on the installation parameters
provided to McCrometer at the time of order.
Other than activating the display, there is nothing
required of the user for the basic operation of the
ow meter.
Operation
b. Battery life
The second screen display shows the battery life
remaining for both battery packs and the ow
totalizer. In the sample below, both battery packs
are at 99% and total ow is 500 kilogallons.
a. Active alarms
The rst screen display shows any active alarms.
In the sample below, there is one alarm active for
an empty pipe.
c. Flow rate and totalizer
The third screen display shows the ow rate and
the ow totalizer. In the sample below, ow rate
is 15 gallons per minute and total ow is 500
kilogallons.
d. Flow rate and percent of full scale
The fourth screen display shows the ow rate and
percent of full scale. In the sample below, the
ow rate is 15 gallons per minute and the meter is
running at 80% of full scale.
30122-61 Rev. 1.3 | 11MAY2020
Page 6
